Product Specifications
| Prod Model: |
TSM100WC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Applied Material: |
Plastic, Alloy ABS, MDF Plywood, Epoxy |
| Marking Range: |
100mmx100mm |
| Laser Power: |
100W |
| Graphic Format: |
Ai, BMP, Plt, Dxf, Dst |
| Tag Line Speed: |
7000mm/S |
| Repeat Accuracy: |
+0.003mm |
| Laser Repeat Frequency: |
20kHz-80kHz |
| Min Line Width: |
0.012mm |
| Guarranty: |
One Year Free Maintanence |
| Certification: |
Ce, Rhos, SGS, ISO |
Product Description
Feature:1. CO2 laser source, free of maintenance, servicetime up to 450,000 hours.
2. High speed galvo scanner (Made in Germany or China,optional for choice)
3. Higher precision,faster speed,Easy to Operate by first trial with manual
4 Air cooling,low power consumption.
5. Red light preview, focusing on the marking position before marking
6. Up and Down Lifter laser head work table easy to marking engraving different workpiece .
7. Rotary attachment optional, can engrave and mark inside and outside for jewellery,pen,crafts,cup,etc
8. High temperature resistance, good for marking medical equipment etc that requires sterilization
9. Permanent & fine marking quality, widely use in jewelry, mobile phones, and other high value items.
Technical parameters:
| Laser type | CO2 laser tube | Min line width | 0.012mm |
| Output power | 100W | Min Character | 0.15mm |
| Laser wavelength | 1064nm | Electrical Voltage | AC220V+-5% 50/60hz |
| Marking area | 100mmx100mm | Supported file format | AI,BMP,PLT,DXF,DST,AI,BMP,PLT,DXF |
| Tag line speed | <7000mm/s | Optional accessories | Rotary system |
| Position accuracy | plus 0.003mm | PC |
Applied tips:
1, Marking content: any text or icon in English, Arabia digital, serial number, VIN number, two-dimensional code, logos, etc.;
2, Character arrangement: horizontal, inclined, arc, arbitrary permutation;
3, Any optional font;
4, The character size, spacing can be adjusted freely;
5, Applicable materials: fabric,textile,plastic,rubber,acrylic,leather, ceramic, wood,etc
Demos:
Repair tips:| Line# | Problems arised | Root cause | Solving method |
| 1 | No singal for power light | The power is off | Open the power button |
| The power line isn't connected | Connect the power line |
| The power is broken down | Change a new power indicator |
| 2 | No singal for the laser light | The laser light is broken down | Change a new power indicator |
| 3 | laser light is ON | The lens head is covered | take off the lens head |
| No laser beam | The power rate is too low | enhance the power rate |
| 5 | Laser light is off | | |
| No laser beam | no connection to the singal line | re-connect the singal line |
| 6 | Laser light is OK | laser light is broken | Change a new one |
| Laser light is Off | laser light is loose weld | weld the laser light |
| 7 | The etch is uneven | the workpiece is not in the field lens surface | Put the workpiece on the field lens |
| 8 | Some are clear but some are not for the texts,images | Marking surface is not paralleled with the field lens | adjust the workpiece |
FAQ:Q1.What's the guarantee for the product quality? We offer one-year free maintenance services for our customers. Generally speaking, our technician will figure out what the cause may be one the problems arise according to clients' feedback. Fault parts with the valid period will be replaced for free except for consumable parts. Q2. Is it easy to operate for the new user ?A: It is very easy ,we offer you operating manual in English ,also our technician can help you via MSN ,Skype or other instant communication tools.
Q3. What i need to do when the machine suffer trouble? A: Make sure all the wires be connection well ,and keep your lens and mirrors be clean ,then check your laser tube and talk details to us. Q4. How to maintain the machine?A: After 3 hours working, it's better close 10 minutes. B, Keep lens and mirrors clean. C, The water for laser tube should keep clean and lower temperature, in winter you need input antifreeze. Q5 .How about the life-span of the laser tube ?A: If you operate the machine rightly, it can reach to 1500 or 3000hours.(RECI laser tube can max to 10000hours),It depends on your usageFor example, if it works 8 hours per day, the detailed data as follows:1, If you set the power at 20%-30% of the total power, the service life is about 1-2years2, If you set the power at 40-50% of the total power, the service life is about 1 year3, If you set the power at 70%-80% of the total power, the service life is about 6-8 months Q6: How can I know the power of the laser tube has been exhausted?A: you can check the color of the laser beam ,new and strong laser tube is purple when working, otherwise it will be white color. Q7:Is it better to increase blow system to improve laser processing performance?A: It works for some kind materials,it can stop firing Q8: How long time does it take for a learning of the laser machine operation ?A: If you are able to use some basic graphic design software, it will only take a few hours to master the operation, You just need to do some simple tests on different processing materials to learn how to adjust the speed and laser power. Q9: Is it harmful to human body when in operation ?A: It is not harmful, as long as the laser don't direct shoot the skin and eyes. Q10: Does it need to be connected by a laptop or computer ?A: Yes, either is ok, It supports Windows 2000, Windows XP, Win 7 and other operating systems. Q11:How to distinguish laser tubes with different powers and applications?A: 1. Laser tube length(relatively speaking, the longer, the bigger/stronger)2. Laser tube diameter(relatively speaking, the thicker,the stronger)3.The machine with bigger laser tube can cut deepermore quickly, also its light spot is bigger, So, it is better to choose low-power for engrave, such as 40w, 50w, or 60w and strong power for cutting.Please let us know following informations:
