China 1290 Reci CO2 CNC Laser Engraving Machine for Wood
| Price: |
US $ 1-4150/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal,Money Gram |
Product Specifications
| Prod Model: |
FMJ1290 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
Rubber |
| Engraving Machine Type: |
Laser Engraving Machine |
| Power: |
Small Power |
| Drive Type: |
Stepper Drive |
| Control: |
CNC |
| Certification: |
CE |
| Laser Type: |
CO2 |
| Current: |
AC |
| Condition: |
New |
| Suitable Materials: |
Non-Metal Materials |
Product Description
China 1290 Reci CO2 CNC Laser Engraving Machine for Wood
1.Advantage of Machine
1) CE Standard.
2) Fully enclosed new appearance.
3) Front and back run-through design for large materials processing.
4) Leetro control panel, famous brand, English subtitles, easy to operate and learn.
5) USB interface can support data transmitting to be quickly finished.
6) Liquid crystal display panel, which is more convenient for clients using.
7) Can both engraving and cutting, very suitable for non-metal materials.
2.Descriptions of Machine:| Model | FMJ1290 |
| Engraving Area (mm)W*L | 1200*900mm |
| Laser tube power | Wegiant:40W 60W 80W
RECI:90W 100W 130W |
| Laser Type | CO2 sealed laser tube |
| Engraving Speed | 0-64000mm/min |
| Cutting Speed | 0-36000mm/min |
| Resetting positioning accuracy | ≤±0.01mm |
| Cutting Platform | Blade table ( Honeycomb table can be choose) |
| Control system | Leetro 6525 control system |
| Machine control and drive | Stepper motor and 3ND583 driver Leadshine |
| Lens and Mirrors | Singapore Lens and mirrors |
| Transmission Way | Shanghai Fulong Belt |
| Guide Rail | Taiwan Hiwin linear square guide rail |
| Auxiliary equipment | Water pump, air pump and dust collector |
| Cooling mode | Circulating-water-cooling and protection system |
| Data transmission | USB off-line |
| Software | LaserCut5.3 |
| Power Supply | AC220V 50Hz |
| Graphic format supported | BMP, PLT, DST, DXF, AI |
| Software supported | CorelDraw, PhotoShop, AutoCAD, TAJIMA |
| Min.Shaping character | Chinese Character:2.0mm×2.0mm,
English Letter:1.0mm×1.0mm. |
| Operating Temperature | 5°C-45°C |
| Operating Humidity | 5-95%(Free of Condensed Water) |
| Optional Spare Parts | Industrial Chiller, Rotary system, Up-down table,
Auto focus system |
| Recommended Spare Parts | Another Laser Tube for Reserve |
| Laser tube working lifetime | Weegiant:3000-6000h;6 months warranty
RECI:8000h-10000h ;10 months warranty
(Counted from the date of produced) |
3.Applicable materials of Machine
Materials |
Cut |
Engrave |
Acrylic/Plexiglas/Perspex |
Yes |
Yes |
Organic board/Matte board/Double color plate |
Yes |
Yes |
Wood/Bamboo/Veneer/MDF |
Yes |
Yes |
Leather/Pig leather/Cow Leather/Sheep leather |
Yes |
Yes |
Fabric/Cloth/Textile |
Yes |
Yes |
Wool Felt |
Yes |
Yes |
Paper/Cardboard/Chipboard press board |
Yes |
Yes |
Plastic ABS/PVC/rubber/plastic |
Yes |
Yes |
Ceramic/Tile/Marble/Stone/Granite/Tombstone |
No |
Yes |
Fiber glass crystal/Glass |
No |
Yes |
Others non-metal materials | |
Yes |
4.How to Order Our Machine?
Before we can recommend you the best suitable machine, please kindly tell us:
1) What materials will you work on?
2) What is your Max.Size of your processing materials?( Length & Width )
3) Do you mainly engrave or cut?If cut,What is your Max.Cutting thickness?
4) Does your materials are cylinder?If YES, what's the Max.Diameter of it?
5) If it is possible, could you send us your product samples' picture?It will help us better to
Understand.
5.Trade Items of Machine
MOQ |
1 set |
Package |
Standard Plywood Box |
Delivery Terms |
FOB, CIF, EXW, Door to Door ect. |
Delivery Time |
15 working days after receiving payment |
Payment Type |
T/T, Paypal, Western Union and others |
Supply Ability |
200 sets/month |
Port |
Qingdao, China. |
6.Packing&shipping:
Water-proof plastic film package with foam protection in each corner.
Solid Seaworthy Wood Box Package with Steel Belt.
Save space as much as possible for container loading.
7.Guarantee & Service of Machine
Guarantee:
1) The whole machine has 1 year warranty.During the warranty, if any parts damage ( not
Human damage ), we will send a new part for you, free charge for part & express.
2) Laser tube is the wearing part ( consumables ):
For Weegiant:We provide 6 months warranty;
For Reci:We provide 10 months warranty.( Counted from the date of produced )
Service:( Provide whole life technical support, 24h online )
Before sale:
We would always be here to provide any information you need at the first time,and give
Professional suggestions according to your real needs for free;
During sale:
We would deal with all the production and shipping affairs, after everything is ready, we
Would tell you everything goes well here;
After sale:
1) We would provide English Version working manual.
2) If you have any questions during using and maintaining, our engineers who could speak
Very good English would answer you online or by calls.
3) Machine warranty is one year.So if your machine has any unintentional damages, we would
Provide parts for free.
4) If your machine has big problems if by any chance, our engineers would arrive there to debug
And fix.
5) Could be remote control if needed
