Product Specifications
| Prod Model: |
TSM30WF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Laser Type: |
Fiber Laser |
| Model No: |
Tsm30wf |
| Laser Power: |
10W/20W/30W |
| Max.Marking Area: |
110*110mm |
| Cooling Way: |
Water Cooling |
| Marking Depth: |
0.01~1mm |
| Minimum Character: |
0.15mm |
| Engraving Speed: |
0-7000mm/S |
| Minimum Line Width: |
0.01mm |
| Type: |
Laser Type |
| Color & Page: |
Multi-Colour Printing Press |
Product Description
Features of the machine
1.The fiber laser marking system adopts the integrated design, with compact size, low consumption, long life-span, high efficiency, free from maintenance, with superior laser beam, and precise light spot, it is no need of consumable items.
2.The scanning galvanometer is imported with original packaging, with good seal, capable to prevent dust and water, small volume, compact and solid, and the performance is superior and power is excellent.
3.With German marking machine software and controlled USB interface, the transmission is swift, stable, with digital transmission function and the software operation is easy and of strong functions
Applicable Industry
It is widely used in the electronics separation components, integrated circuit, electrical engineering circuit, mobile communication, hardware, tools, kitchen wares, tool fittings, precise apparatus, eyeglasses and clock, computer keyboard, jewelry accessories, plastic buttons, water heating fittings, sanitary ware, PVC pipelines, medical apparatus and packing container, etc.
Applicable Materials
It is capable to curve the metal materials and partial non-metal materials, especially suitable for some fields required more precise and higher smoothness.
Advantages
1) Superior laser beam: the definition is 1 micron, ten times as that of traditional products.
2)Low consumption <400W
3) Long life-span of laser module 100,000hours.
(Comparison: several hundred hours for light pumping YAG and 10000 hours for semi-conductior)
4) Fast speed: 800 standards charaters / second, is 3 to 5 times above that of traditional products.
Technical parameter
| Laser power | 10W/20W |
| Laser Wavelength | 1064nm |
| Light beam quality | <2 |
| Repeating precision | ±0.002 |
| Marking range | 110x110mm(customize) |
| Marking depth | 0.01~1mm |
| Marking speed | 7000mm/s |
| Minimum character | 0.15mm |
| Minimum line width | 0.01mm |
| Repeating frequency | 20KHz~30KHz |
| Marking content | Graphics, text, bar codes, two-dimensional code,
date, batch number, serial number |
| Graphic format supported | bmp,png,ai,dxf,dst,plt |
| working voltage | 220V±10%/50Hz/4A |
| Size | 770mmx650mmx1450mm |
| Gross Weight | 80kg |
| Control interface | standard USB port |
| Working environment | Clean and dust free or dust less |
Taishun laser equipment Co., Ltd has been in the field of laser technology development and production for more than 20 years since the company was established, and always stand in the fore front product research and development.
Taishun company has strong Technical force and established set of perfect quality Management system, passed ISO9001: 2008 Quality Management System Certification, BV authentication, SGS and National Mandatory Product "3C" certification, which has reliable quality.
We developed 6 series of more than 10 types laser products which adopt international advanced technology. Such as, fiber laser metal cutting machine, YAG laser metal cutting machine, CO2 laser cutting and engraving machine, Fabric Flatbed laser cutting machine, Conveyor working table machine, laser marking machine and so on.
Taishun laser are good at produced medium and small laser power laser cutting machine, specially to supply one whole sets of laser processing solution scheme and related facilities for customers in plush toys, leather cutting, plush fabrics, automobile, textile, textile clothing, advertising handicrafts, electronics, medical equipment and etc. These laser equipment were widely applied in electronic circuit, auto spare parts, hardware tool, medical instrument, digital products, apparatus and instrument, optic communication component, packing and printing etc. To create a new Second-Generation small power laser cutting machine with more rapid and refinement manufacturing.
