Multi-Spindle, Wood, Aluminum, Soft Metal CNC Router
| Price: |
US $ 4000-8000/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,Western Union,Money Gram |
Product Specifications
| Prod Model: |
DT1813-1-10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Engraving Router |
| Controlling Mode: |
CNC |
| Feed Mode: |
Mechanical |
| Spindle Layout: |
Spindle Over |
| Color: |
Customized |
| Condition: |
New |
| Customized: |
Customized |
| Spindle Number: |
10 |
Product Description
10 spindles CNC wood carving machine from professional CNC wood cnc router carving machine maufacturer.Feature: 1. DT1813-10 engraving machine is our company specially developed and
designed for small workpiece but mass production, high precision, high
speed and high cost performance.
2. The lathe bed is welded by steel structure seamlessly, has good stiffness
and non-deformation.
3. Using computer cabinet, the original Weihong control system has Stable
performance and high reliability .
4 .Automatic oil lubrication system, it is more convenient for maintenance.
5. With function about continued carving when it has breakpoint, power
recovery and processing time prediction
6. Imported ball screw rod and round rail, original screw, nut,imported linear
and square railApplication industry:1. Woodworking industry: The furniture of door, window, cabinet, craft
wood door, paint free door, folding screen, process window, wave board
processing,including the processing for wood art.
2. Stone industry: Natural marble, granite, artificial stone, tombstone,
milestone,ceramic tile, glass and other materials of 3D relief and line
carving, cutting,edge, drilling and 2D carving.
3. Advertising industry: Suitable for processing various design and colorful
mould, just like: Signs, architectural models, badges, badge, name plate,
exhibition board, indicator, craft decoration, furniture decoration, etc.
4. Handcraft industry: Can engrave in wood, bamboo, artificial marble,
organic board, double color boards, crystal and other material.
5. Also can carve and achieve all kind of effects for reliefs, movie, hollow
and plate engraving, cutting and valuable. such handiwork, graphic
engraving, cutting, the bottom of milling,etc.
What you see is what you get
| NO | Performance index | | | Optional |
| 1 | Working area | X | 1800mm | |
| | | Y | 1300mm | |
| | | Z | 150mm | |
| 2 | Table size | | 1800mm*1300mm | |
| 3 | Precision | Working precision | 0.02mm | |
| | | Repositioning precision | 0.02mm | |
| 4 | Drive mode | | Servo | |
| 5 | Speed | Max motion speed | 10000mm/min | |
| | | Max engraving speed | 8000mm/min | |
| 6 | Spindle | Spindle power | 1.5KW | 0.8KW_3KW |
| | | Spindle speed | 0_24000r/min | |
| 7 | Drive mode | | Servo | |
| 8 | Operating voltage | | AC220V/50HZ | |
| 9 | Command code | | G code | |
| 10 | Operating system | | NC studio | |
| 11 | | | 1500KG | |
| Optional | Vacuum table |
| Yaskawa servo, Panasonic servo, Estun servo |
| Control system |
| Air cooling spindle or water cooling spindle |
| |
OEM Service Available:1. Usually, we will manufacturer the machine as our regular design.
2. X Y Z Working Area could be customer-oriented designing.
3. Special configuration could be customer-oriented designing. Technical support:1. Technical support by phone, email or MSN/ Skype around the clock
2. Friendly English version manual.
3. Engineer available to service machinery overseas. but the buyer should
pay the fee.After-sale & guarantee service:1. Under normal usage, 1 year for the whole machine and 6 months for spindle
2. Normal machine is properly adjusted before dispatch.
3. You will be able to get free training advice towards our machine in our factory.
4. You will also get free suggestion and consulting, technical support and
service by email/fax/ tel and lifetime technical support If you have specific requirement for multi-spindle wood CNC router carving machine, customization is available.
