Qinhuangdao Intrinsic Crystal Technology Co., Ltd. >> 30mm Diameter 3mm Thickness Laser Si Reflective Mirror

30mm Diameter 3mm Thickness Laser Si Reflective Mirror

30mm Diameter 3mm Thickness Laser Si Reflective Mirror
Price: US $ 20-60/Piece
Min Order: 1/Piece
Pay Type: T/T,Western Union,Paypal

Product Specifications


Prod Model: D5~D300mm
Type: Flat Lens
Shape: Round
Material: Silicon
Coating: Gold Aluminime

Product Description


Si Laser Reflecting Mirror 30mm
 MaterialSilicon, Molybdeum mirror reflecting
Diameter Tolerance+0.0/-0.1mm
Thickness Tolerance+/-0.1mm
Clear aperture>= 90% Diameter
Surface flatnessLamda/4 @ 632.8nm
Scratch/dig40/20
parallelism< 1 min
Bevelling< 0.2*45 Deg

modelDiameter mmE.T mmmaterialcoatingspeciality
ICC1903193



silicon




Gold-plated




Highly reflective coating
ICC2003203
ICC2503253
ICC3003303
ICC38.10338.13
ICC38.10538.15
ICC50.80550.85
ICC50.81050.810
ICC1903193



silicon




Dielectric-plated




Highly reflective coating
ICC2003203
ICC2503253
ICC3003303
ICC38.10338.13
ICC38.10538.15
ICC50.80550.85
ICC50.80550.810

Qinhuangdao Intrinsic Crsytal Technology Co., Ltd, based in China, is a recognized leader in high-performance optical solutions across a broad infrared spectrum. Combining adequate IR material supply, extensive fabricating experience, and the standardized service, U-Optical specializes in producing high-precision IR optical components for the Medical/Life Sciences, Defense & security, Semiconductor, and Industrial OEM markets. From optics designing, to material purchase, to volume production, our company endeavor to optimize your IR products for performance, cost, quality and delivery.

Our Strengths

Ample, stable and cost-efficient supply of IR materials.

ICC also offers the ability to combine infrared material supply, precision optical processes, various coating, reliable inspection and commercial service into a complete procedure, providing full professional support for both optics and trades. This enables our customers to obtain the highest level of optical integration and business advantage, minimizing time and cost while ensuring quality, performance and manufacturability.

Consistent and high-performance manufacturing

During its years of operational experience, ICC have developed unique techniques of micro-polishing which enable to easily produce elements needed for high transmission and low scattering and absorption applications.

The accumulated experience in the IR optics market, in addition to the high qualifications and strong optical background of the company's leading staff allow U-Optics to be a reliable supplier to many OEM customers and R&D institutions around the world.

Excellent quality and efficient service

From design to delivery, our material control, in-process testing and final inspections assure that our products meet your highest specifications and quality standards.

Our sales team possess a wide range of experience of not only optics, but also the international business services. By staying close to our customers and giving straightforward honest advice, we are confident to provide our overseas customers with the excellent IR products from China.

Competitive Prices

ICC can offer the customers with most competitive prices and high quality of products, supported by the close associations with the domestic suppliers, its comprehensive optical manufacturing capabilities, as well as its strong ability in exploring overseas markets.

Stable and reliable business partner

We place equal focus on processing technique, customer service and innovative research. Meanwhile, we create customer value by understanding customer needs, by unconditionally guaranteeing our work and by keeping abreast of customer developments.

Contact us today to discuss your needs. To my email: Optics@intrnsiccrysal. COM Tel: 18833844340
