Product Specifications
| Prod Model: |
MR8-200R |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Packing Speed: |
20-50bags/Min |
| Frame Of Machine Material: |
304stainless Steel |
| Pouch Type: |
Zipper,Gusset,Spout Premade Pouch |
| Bag Size: |
W80-200mm L100-300mm |
| Waranty: |
One Year |
| Packaging Type: |
Bag |
| Automatic Grade: |
Automatic |
| Packaging Material: |
Plastic |
| Application: |
Hair Care Products |
| Type: |
Filling and Sealing Machine |
| Material Type: |
Bulk Solid |
Product Description
Main Features of packaging machines
1, Full automatic 8-staion intermittent rotay performed bags dispensing, opening and closing machine combines with automatic combination weigh scale filler, overhaed work platform and Z-elevator bulk feeder.
2, Safety guard protected for high speed and consistent production.
3, Heavy duty components and parts are selected for machine durability.
4, Hygienic construction and easy cleaning. Operator friendly design touch-screen control system.
5, Versatile in design, easy to link up with other down stream packaging equipment, such as liquid filler, powder filller, multiheads weigher, metal detector, checkweighter, case sealer etc.
6, Innovative and practical solution at reasonable costs.
7, Dust control and extractor system on special request.
Applications for this kind of packaging machines
Solid: Candy, peanut, green bean, pistachio, crystal candy, brown sugar, cookie, cake, dailycommodities, cooked food, pickles, puffed food, pet food, etc
Typical Flow Chart of packing machine
1, Giving bag
2, Hot Foil Coding
3, Bags Opening
4, Fill one consolidate
5, Fill two
6, Heat sealing one
7, Heat sealing two
8, Forming and output product
| Model | MR8-200R |
| Working Station | Eight |
| Size of bag | W:80-210mm L:100-300mm |
| Filling Scope | 5-2000g |
| Speed | 20-60bags/min(The speed depends on the product status and filling weight) |
| Package accuracy | Error≤±1 |
| Total Power | 3.6KW |
| Dimension | 1645*1450*1450mm |
| Weight | 1200KG |
| Application | candy, peanut, green bean, pistachio, crystal candy, sugar, cookie, cake, snack,dailycommodities |
