| Price: | US $ 7000-12000/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | FM2513 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: | Metal Laser Cutting Machine |
| Control Software: | Rd Control System |
| Driving System: | Leadshine Stepper Motor |
| Guide System: | Taiwan PMI Rail |
| Resetting Positioning Accuracy: | 0.01mm |
| Cooling Mode: | Water-Cooling and Protection System |
| Working Table: | Blade Table |
| Laser Head: | with Ruida Follow up System |
| Transmission: | Belt and Ball Screw Transmission |
| Suitable Materials: | Metal Materials |
Application:
This co2 laser cutting machine can use for cutting metal&nonmetal meterial.
Metal materail: This machine can cut carbon steel, stainless steel, According to different metal materials and thickness, we will adjust the pluse width, current, frequency, cutting speed.
Non-metallic materails :Wood, Bamboo, jade articale, stone(only can engraving), organic glass, crystal(only can engraving), rubber, plastic, cloth, leather, etc.
Technical parameters:
Product name | metal laser cutting machine price |
Working area | 1300mmx900mm |
Laser Types | Sealed CO2 Laser Tube |
Laser power | 150W Reci laser tube (optional: 180W, 280W) |
Engraving speed | 100-600mm/s |
Cutting speed | 0-300mm/s |
Location precision | ≤0.01mm |
Resetting positioning accuracy | 0.01mm |
Power supply | AC110- 220V/50-60HZ |
Controlling software | RDCAM |
Operating temperature | 0 - 45° |
Operating humidity | 5-95% |
Minimum shaping character | English 1 x 1mm |
360°slope engrave | Yes |
Driving system | Leadshine Stepper motor (optional: Panosanic servo motor) |
Cooling mode | Water-cooling and protection system |
Auxiliary Devices | Exhauster and the Exhaust Pipe |
Graphic format supported | BMP, CIF, JPEG, TGA, TIFF, PLT, AI, DXF, DWG,etc |
Optional | Automatic feeding system,Red light pointer |
Option | Red dot pointer position, working table,rotary,auto-focusing |
All laser cutting machine accessory parts are original, such as Reci laser tube, leadshine stepper motor and drivers etc. welcome to our factory to check the machine if possible.
Samples were produced by laser cutting machine, no matter what materials, the samples can be produced for you according to your requirements.
Packaging & Shipping
Firstly, packed the laser cutting machine with plastic sheet for clearing and damp proofing.
Secondly, then put the cnc router in the plywood case for safety and clashing.
Thirdly, transport the plywood case into the container.
After sale service:
1. 24 hour Technical support by phone, e-mail or MSN around the clock.
2. Friendly English version manual and operation video CD disk.
3.7-15 working days after down payment or full payment.
4. Machine will be adjusted before it is delivered; operation disk/CD was included.
5. Our technician can give you remote guide online (Skype or MSN) if you have any question.
6. Engineers available to service machinery overseas, seller and buyer discuss the charges.
Company information:
Jinan Firm CNC Equipment Co., Ltd is located in Jinan,Shandong PR, Founded in 2003. Loader of laser cutting machine appliance manufacture. We are an all-round enterprice, which is comprehensive in R&D, manufacture, and sales on laser cutting machine appliances.
