Golden Color PVD Coating Machine (LH-SERIES)
| Price: |
US $ 1/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,Western Union |
Product Specifications
| Prod Model: |
LH-series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Coating Technology: |
Arc Cathode Sputtering, Ion Plating, Plasma Sputte |
| After Sales-Service: |
Engineers Available to Service Machinery Overseas |
| Control System: |
PLC+ Touch Screen, Automatic+ Manual |
| Application: |
Decorative Coating, Widely Use in Get Gold Color |
| Business Type: |
Manufacture+Trading |
| Name Of Our Company: |
Dongguan Huicheng Vacuum Technology Co.,Ltd |
| Coating Color: |
Gold, Silver, Rose Gold, Copper, Coffee, Blue, etc |
| Type: |
Coating Production Line |
| Coating: |
Vacuum Coating |
| Substrate: |
Glass,Metal,Ceramic,Alloy,Crystal,Mosaic |
Product Description
Golden Color PVD coating equipment integrated three technology of DC magnetron sputtering, middle frequency sputtering and electric arc ion evaporation, combining the linear ionize source and pulse bias coating to thin the deposition particles. The various film performance are improved, and be able to coat alloy film, compound film, multilayer composite film on the surface of metal as well as nonmetal. After years of dedicated R&D by our engineer, through unique cathode electric arc ion and unbalanced magnetron systems, we develop a package of PROPOWER series of computer automatic control system. It makes the coating film adhesion density as well as good complex consistency, and solve the problems of the complexity of the manual operation, film color inconsistencies, etc.
Characteristic:
1. The principle of magnetron sputtering is based on the cathode glow discharge theory, expanding the cathode surface magnetic field close to the surface of workpiece, to increased the ionized rate of sputtering atoms. It retains the delicate of the magnetron sputtering and increased the glossiness.
2. The performance of electric arc plasma evaporation source is reliable, be able to work under the current 30A when optimize the cathode and magnetic field structure coating, and the coating film and substrate interface produce atomic diffusion, plus the feature of the ion beam assisted deposition.
Applied industry: The equipment is widely used in IPG clocks, IPS watches and clocks, guns IP, mobile phone shell, hardware, sanitary ware, cutters, anti-friction tools, dies and mould, etc. It can coat TiN, TiCN, CrN, TiALN, TiNbu, TiCrN, ZrN, and various kinds of diamonds film (DLC).
Mode
Dimension | LH-800 | LH-1250 | LH-1416 | LH-1618 |
| 800*1000mm | 1200*1500mm | 1400*1600mm | 1600*1800mm |
| Coating mode and main confirguration |
Eight multi-arc targets |
Twelve multi-arc targets |
Fourteen
multi-arc targets |
Twenty
multi-arc targets |
| Power source | Electric-arc power, Filament power, Pulsed bias power supply |
| Process gas control | Mass flowmeter + Electromagnetic ceramic valve |
| Vacuum chamber structure |
Vertical side opening door, pump system postposition, double water cooling |
| Vacuum system | Molecule pump +Roots pump +Mechanical pump(5.0*10 -5 Pa)
Diffusion pump +Roots pump +Mechanical pump(5.0*10 -4 Pa) |
| Workpiece baking temperature |
Normal temperature to 350 centi-degree PID control, radiation heating. |
| Workpiece motion mode | Public rotation Frequency control: 0-20 rotation per minute |
| Measure mode | Number display composite vacuum gauge: from atmosphere to 1.0*10 -5 Pa |
| Control mode | Manual/Automatic/PC/PLC + HMI/PC four choice of control mode |
| Remark | We can design the dimension of the equipment according to customer's special technique requirement. |
