Product Specifications
| Prod Model: |
ZC-L60 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Operation System: |
PLC Touching Screen |
| Control System: |
Automatic Manual All-in-One |
| Coating Technology: |
Ion Coating Machine |
| Coating Colour: |
Gold,Rose Gold,Black Grey,Deep Black,Bronze,Ect |
| Name: |
Ceramic Vacuum Coating Equipment for Tile |
| Place Of Origin: |
Dongguan, China |
| Applied Industry: |
Ceramic |
| Businee Type: |
China Manufacturer/Factory |
| Brand: |
Zhicheng |
| Type: |
Coating Production Line |
| Coating: |
Vacuum Coating |
| Substrate: |
Steel |
Product Description
Ceramic Plate and Mugs PVD Ion Plating Machine
The main components of Domestic Ceramic and Crystal Lamp Plating Equipment are cathodic arc ion evaporators and also
bias power,magnetic control sputtering target.
| ZD1214 | ZD1215 | ZD1418 | ZD1618 |
| φ1200*H1400 | φ1200*H1500 | φ1400*H1800 | φ1600*H1800 |
| Matel film. translucent film. nonconductive film .electronmagnetism shield film. Dielectric film. Etc. |
| Resistance evaporation power. DC magnetron power. M magnetron power .RF power |
| Vertial single door. Pump system postposition. Horizontal single door. Pump system for side |
| 6.0×10-4pa |
| Diffusion pump+roots pump+mechanical pump+holding pump |
| The whole chamber clean and unload,From the atmospheric vacuum to 6×10-3pa≤8 minutes |
| Manual/ Automatic all in one mode. Touch screen +PLC |
Device feature :equipped with strong pumping system,quick airexhaust,high loading quantity.
mass production,low cost.
it can produce the coating with imitation gold color ,rose gold,silver ,black and other colors,
the adoption of decalcomania paper and coating watersoluble painting masking technology
can get various colored floral designs,we have been mature in the design and processing
for plating equipment and focused on tool plating and coating treatment of various superhard
ceramic thin film,including titanium nitride,titanium carbide ,titanium carbide nitride, zirconiumnitride,
chromium nitride,zirconiumnitride,chromium nitride and titanium aluminum nitride etc.
Our company can design the machine ,according to customer's requiremements and
types of vacuum pumping system,electric control system can be designed up to customers'
requirement as well.
Please feel free to contact us for further information!
Contact Person: Lily zhou
Mobile:0086-13925852241
Thanks for your time & Have a nice day!
