Product Specifications
| Prod Model: |
ZC-T33 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Operation System: |
PLC Touching Screen |
| Name: |
Glass Tube Metalizing Coating |
| Sample: |
Available |
| Coating Color: |
Gold and Silver |
| Technic: |
Vacuum Coating Technology |
| Applied Industry: |
Automotive, Audio and Varinous Small Appliances |
| Brand: |
Zhicheng |
| Place Of Origin: |
Dongguan, China |
| Businee Type: |
China Manufacturer / Factory |
| Machine Control System: |
Automatic Manual All-in-One |
| Type: |
Coating Production Line |
| Coating: |
Vacuum Coating |
| Substrate: |
Steel |
Product Description
Glass tube metalizing coating
1.Brief Introduction
Glass tube metalizing coating adopts the resistance heating in the vacuum chamber,And then meltdown and vaporization the coating metal materials and. The vaporized metal molecule deposit on the substrates to gain the smooth as well as high reflectivity film. Thus the surface of the items can be beautiful.
2.Characteristic
Glass tube metalizing coating has Reasonable Structure,quick Pumping speed, short work efficiency and easy operation, low energy consumption and performance advantages of stability.
3.Applied industry
Crystal Glass Mosaic Surface Decorative vacuum coating machines is Widely used in automotive, audio and varinous small appliances, computers, clocks and watches, toys cell phones reflective Cup, cosmetics toys tableware sanitary shoe heel, ABS, PS, PP, PC, PVC, PET, nylon,metal, Boli, glass, ceramics, TPU, etc.
4.Electroplating effects
Glass tube metalizing coating General electroplating-face, dumb-(semi-mute, all dumb), the electroplating process wrinkles, wiredrawing,raindrop ect.
5.Parameter of the machine
| Mode | JTL-0910 | JTL-1110 | JTL-1311 | JTL-1612 |
| Dimension | Φ 900Χ 1000mm | Φ 1100Χ 1000mm | Φ 1300Χ 1100mm | Φ 1600Χ 1200mm |
| Main confirguration | 3 electric-arc+2 pairs of plane rectangular cathode | 6 electric-arc+2 pairs of cylindrical cathode+a pairs of plane rectangular cathode | 5 electric-arc+4 pairs of cylindrical cathode+a pairs of plane rectangular cathode | 6 electric-arc+8 pairs of cylindrical cathode+a pairs of plane rectangular cathode |
| Film type | Metal films, Dielectric films, Compound films, Reaction films, Muti-layer function films |
| Power source | Electric arc power supply, DC magnetron power supply, MF magnetron power supply. Pulse bias voltage power supply. ion source power supply. |
| Process gas control | Quality flowmeter + electromagnetism ceramic valve |
| Vacuum chamber structure | Vertical single(side) door, pump system postposition, double water-cooling |
| Vacuum system | Molecule pump(diffusion pump)+Roots pump +Mechanical pump (8.0*10 -4 Pa) |
| Pump speed | Pumping time less than 15 minutes, from atmospheric pressure to 3Χ 10 -3 Pa |
| Workpiece motion mode | Public rotation Frequency control: 0-20 rotation per minute |
| Control mode | Full automation control system PC+PLC/PC+HMI |
Company Introduction:
The coating experts of your own company:Full set solution for the coating production
ZHICHENG can help you to enter the PVD coating easily by our vacuum coating machine and full range service. We will provide most suitable technology according to your requirements.
Moreover We will make the unique coating solution for each customer; combine with the full set production technics to meet your requirements, and ensure high efficiency of production.
We developed a complete after-sales system and effective service measures. Company owns a professional after-sales service team with experienced engineers.
