Product Specifications
| Prod Model: |
ZTS-320R |
| Markets: |
South America,Mid East,Eastern Asia,Western Europe |
| Magnification: |
30X |
| Reticle: |
Illuminated |
| Minimum Focusing Distance: |
1.5m |
| Field Of View: |
2.7m/100m |
| Accuracy: |
2" |
Product Description
Total Station ZTS-320R:
Features:
Absolute Encoding
The absolute encoding disk ensures high accuracy, efficiency and stable performance. Initialization is needless but to measure the angle immediately as the ZTS-320/R is turned on. The azimuth information won't be missed even the ZTS-320/R is power-off unexpectedly.
Dual-axis Compensation
The ZTS-320/R is configured with advanced dual-axis compensatorfor auto error elimination and auto accuracy compensation.
High-performance MCU
The STM32 MCU based on ARM Cortex™-M processor enables the ZTS-320/R has extra high processing speed and low-power consumption.
Bluetooth
The Bluetooth wireless technology makes ZTS-320/R accessible to any data collector for real-time communication. The third party field software such as Carlson SurvCE is fully compatible with the ZTS-320/R.
Data Storage
Diversified data transfer options such as SD card, USB pen drive, mini-B interface.
Backlight
The display and keyboard with backlight for working in the dark.
Diagonal Eyepiece
Support diagonal eyepiece for observations at steep line of sight.
Calibration Software
The proprietary Calibration software is accessible for real-time diagnosis to ensure trouble-free operation.
Data Transfer Software
The proprietary data transfer software supports different type of output data format, which can be used in AutoCAD or other brands' post processing software.
Specifications:
Angle Measurement
* Measurement Method: Absolute Encoding
* Minimum Readout: 1″/5″/10″(0.3mgon/1.5mgon/3mgon)adjustable
Accuracy1 : 2"
Distance Measurement (ZTS-320 with Reflector)
* Single Prism: 3000m (9,842ft.) under good condition3
* Three Prisms: 6000m (19,685ft.) under good condition3
* Reflective Sheet: 800m (2,624 ft.)
* Accuracy: 2 mm +2ppm
* Measuring Time (Fine/Quick/Tracking): 1.5s/1s/ 0.5s
Distance Measurement(ZTS-320R Reflectorless)
* Reflectorless2 Range: 350m (1,148 ft.)
* Single Prism: >7500m (24,606ft.)
* Accuracy: 3mm+2ppm
* Measuring Time: 1.5s
Telescope
* Magnification: 30X
* Field of View: 1°30′ (2.7m at 100m)
* Minimum Focusing Distance: 1.5m
* Reticle: Illuminated
Compensator
* System: Single-axis liquid tilt sensor/Dual-axis (optional)
* Working Range: ±3′
* Setting Accuracy: 1″
Communication
* Bluetooth
* Interface: Standard RS232, SD card4, USB pen drive, mini-B
* Internal Data Memory: Approx. 20,000 Points
* Data Format: ASCII
Operation
* Operation system: Real-time Operating System
* Display: High resolution backlight black and white display with contrast adjustment/ * Graphics: 192 x 96 pixels / Character: 6 lines x 25 characters
* Keyboard: 2 sides Alphanumeric backlit crystal keyboard
Laser Plummet
* Type: Laser point, 4 brightness levels adjustment / Optical plummet (optional)
* Centering Accuracy: 1 mm at 1.5m instrument height
Power Supply
* Battery Type: Rechargeable Li-ion battery
* Voltage/Capacity: ZBA-400: 7.4V (DC) / 3000mAh
* Operating Time With ZBA-400: Optimal 16 hours5 (Continuous angle measurement every 30 seconds) / 10 hours (typical)
* Measuring Times: Approx. 12000 times
Weight
* Weight (Incl. Battery & Tribrach): Approx. 5.5kg (12.1lb.)
Environmental
* Operating Temperature: -20ºC ~+50ºC( -4ºF to +122ºF)
* Storage Temperature: -40ºC ~+70ºC(-40ºFto + 158ºF)
* Dust &Water Proof (IEC60529 Standard)/Humidity: IP65, 95%, non-condensing
