Product Specifications
| Prod Model: |
ZTS-360R |
| Markets: |
North America,South America,Eastern Europe,Western Europe |
| Magnification: |
30X |
| Field Of View: |
2.7m @ 100m |
| Minimum Focusing Distance: |
1.5m |
| Accuracy: |
3mm+2ppm |
Product Description
Total Station ZTS-320R:
ZTS-360R Total Station
Compact and Lightweight Designed, easy to carry and setup. With powerful measurement module, Stable Dual-axis Compensation system, and Intelligent Calibration Software, ZTS-360R improves the speed and distance of measurement efficiently. Using STM32 architecture and high-grade dustproof and waterproof structure design, Comprehensively enhance the overall performance of ZTS-360R.
Features:
1. Compact, Lightweight Design
* Rugged, compact design ensures the stability of every indicators of equipment and protect you from data loss on the harsh conditions.
* Small size and light weight body make your work easily.
2. Quick Trigger Button
Measurement and record by pressing one quick trigger button, fast and convenient.
3. Stable Dual-axis Compensation
* Simultaneous tilt compensation from horizontal and vertical angle makes sure the accurate measuring result, even when the body is rotating.
* Vivid graphic electronic bubble display is available.
4. Upward Laser Pointing
Deviation from centre handle design makes upward laser pointing fast and easy, and no dead angle exists in upward measurement, which is significant for mining or tunneling application.
5. Powerful and Fast EDM Capability
* 600m Non-prism ranging.
* Fine 0.8s, Track 0.3s in prism mode.
6. IP66 Dust and Water Protection
High standard IP66 performance provide protection from dust penetration and water driving.
7. Intelligent Calibration Software
The proprietary Calibration software is accessible for real-time diagnosis to ensure trouble-free operation.
8. Software Compatibility
Compatible to the 3rd party data processing software, satisfying users' requirements for different data format.
Specifications:
1. Angle Measurement
* Measurement Method: Absolute Encoding
* Minimum Readout: 1″/5″/10″(0.3mgon/1.5mgon/3mgon)adjustable
* Accuracy : 2"
2. Distance Measurement (ZTS-360 with Reflector)
* Single Prism: 3000m (9,842ft.) under good condition3
* Three Prisms: 6000m (19,685ft.) under good condition3
* Reflective Sheet: 800m (2,624 ft.)
* Accuracy: 2 mm +2ppm
* Measuring Time (Fine/ Tracking): 0.8s/0.3s
3. Distance Measurement(ZTS-360R Reflectorless)
* Reflectorless2 Range: 0.3 ~ 600m(0.98 ~ 1968 pies)
* Single Prism: >7500m (24,606ft.)
* Accuracy: 3mm+2ppm
* Measuring Time: 1.5s
4. Telescope
* Magnification: 30X
* Field of View: 1°30′ (2.7m at 100m)
* Minimum Focusing Distance: 1.5m
* Reticle: Illuminated
5. Compensator
* System: Dual-axis
* Working Range: ±3′
* Setting Accuracy: 1″
7. Communication
* Bluetooth
* Interface: Standard RS232, USB, mini-B
* Internal Data Memory: Approx. 20,000 Points, default 8G USB pen drive
* Data Format: ASCII
8. Operation
* Operation system: Real-time Operating System
* Display: High resolution backlight black and white display with contrast adjustment/ * Graphics: 192 x 96 pixels
* Keyboard: 2 sides Alphanumeric backlit crystal keyboard
* Trigger key: On right instrument support
9. Laser Plummet
* Type: Laser point, 4 brightness levels adjustment / Optical plummet (optional)
* Centering Accuracy: 1 mm at 1.5m instrument height
10. Power Supply
* Battery Type: Rechargeable Li-ion battery
* Voltage/Capacity: ZBA-400: 7.4V (DC) / 3400mAh
* Operating Time With ZBA-400: Optimal 20 hours4 (Continuous angle and distance * measurement every 30 seconds) / 10 hours (typical)
* Measuring Times: Approx. 12000 times
11. Physical
* Weight (without battery): Approx. 3.7kg (8.38lb.)
* Size: 300mm x 150mm x150mm(HxWxD)
12. Environmental
* Meteorological parameter modification: Manually(T-P senser is optional)
* Operating Temperature: -20ºC ~+50ºC ( -4ºF to +122ºF)
* Storage Temperature: -25ºC ~+70ºC (-13ºFto + 158ºF)
* Dust&Water Proof (IEC60529 Standard)/Humidity: IP66, 95%, non-condensing
