Ql1325 Stone Cutting Machine Made in China and High Quality

Product Specifications

Prod Model:	QL-1325
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Usage:	Stone
Engraving Machine Type:	CNC Engraving Machine
Power:	High Power
Drive Type:	Stepper Drive
Control:	CNC
Certification:	SGS, CE
Current:	AC
Working Area:	1300*1800mm
Transmission:	Square Guide Rail, Rack and Gear

Product Description

1325 jinan factory supply stepper motor aluminum table 5.5 kw water cooling spindle cnc stone carving/engraving  machine
 Features

 1. The whole bed welded steel strong, forceful, smooth rotation , making high speed operation for a long time without deformation , no jitter

2. Big Power inverter spindle , continuously variable transmission , low noise .
3. The machine with double water circulation system , can protect the tools better .
4. PC control system , three dimensional dynamic tracking display features automatic knife , three-dimensional simulation .

5. can save 10 breakpoints, with a function that continue carving even if it has breakpoint.

After stopping the electric, it can still working later, it can reduce the rate of rejection.

 Specifiction and Parameters


Description	Standard Configurations	Options
Machine structure	Steel structure  Lathe Bed
Working table	T-slot	Vacuum table
Spindle	5.5kw water-cooling	Customization power ,air-cooling
Transmission	Rack
Guides type	round guides	Square guides
Drive motor	Stepper	Servo
Drive	Leadshine 860
Head quantity	Single head	Multi-heads
Control system	NCSTUDIO system	DSP




Model	QL-1325
X,Y,Z-axis working area	1300*2500*400mm
Max. Feeding height	400mm or bigger
Cut thickness of material	150mm
Max. Speed	8000mm/min
Working speed	0-3000mm/min
Mechanical precision	0.04mm/300mm
Compatible Software	TYPE3 software, Artcut software, Artcam software
Max. Power consumption	5.5KW
Power source	AC380V/50HZ
Driver type	Leadshine 860 prime mover
Memory	DSP control
Spindle	5.5KW(option), water-cooling
Spindle speed	0-24000rpm
Blade diameter	3.175mm, 4mm, 6mm, 12.7mm
Control system	DSP or NSTUDIO control systerm
Command	G code
The optional accessories	Rotary axis, servo motor, air-cooled spindle,heads quantity



 Applicable materials and field

 Marble, granite, China black, bluestone, jade, ceramic, crystal, glass, plastic, chemical synthesis of plate glass, PVC board, wood, aluminum panels, metal, plastic and other materials for line engraving, 2D sculpture, 3D sharp sculpture, three-dimensional relief, cutting, drilling.
 Stone, tombstone processing, advertisement, decoration, and crafts industry, etc
 Usage: stone carving, tombstone processing, advertisement , decoration and craft industry, etc.

Samples



Company Information
 Our company:

Jinan Hongye cnc machine  is a high-technology enterprise which is specialized in developing

andmanufacturing advanced high grade CNC Router.Having around 12 years' experience, our company ranks in the front of the fields and enjoys good honor from worldwide.

Meanwhile, our products has been granted CE and SGS certificate. Now we have three main series machines and around 50 models: CNC engraving machine, 3D woodworking machine and laser engraving machine.

And we wish you knew that perfect quality and good after-sales service is our specialty.

Training and Use

 1. We will supply with the machine operation manual in English version for installing and operation.
  2.Customer can come to our factory  training .

 Warranty and After service

1. Our warranty is 12 months counting from the date when the Machine arrives at the port of destination.
 2. We will supply  after service 24 hours,customer can contact us any time.
 3.When some problems can't be solved by customers, our engineer  can go to door to help.

FAQ

1) This is the first time I use this kind of machine, is it easy operate?
There are english manual or guide video that show how to use machine.

 If there is still have any question, we can talk from phone or skype.

2)Can you recommend a CNC ROUTER MACHINE to me,thanks?

 Yes, In order to give you a suitable router machine, pls tell me the max working area, materials

 for processing and the thickness for materials processing engraving or cutting. Then perfect suitable cnc router will be recommended

3) If machine have any problem after I ordered it, how could I do?
Free parts send to you in machine warranty period if machine have any problem.

Free after-sales service life for machine, please feel free contact us if your machine have any problem. we will give you 24hours service from phone and skype.

4) MOQ ?
Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will be best shipping freight and machine price send to you

5)Payment terms

 a. 30% by T/T in advance,70% bY T/T before shiping

 b. L/C is acceptiable ,if the amount is big,please issue the draft for our confirmation at first.

 6)Delivery terms

 We will arrange the delivery as the terms we both agreed with after the confirmation by the buyer.
Looking for agent around the world,further informationss,pleases do not hesitate to contact me,hope to build cooperation with you.24hours service, your inquiry will be replied very soon.
