| Price: | US $ 3900-4500/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Western Union,Money Gram |
| Prod Model: | VC15 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Structure: | Stainless Stee 304 |
| Weight Zone: | 270*110 |
| Reject Optional: | Push Rod Air Balst and So on |
| Customized: | Accept |
| Accuracy: | ＜±2g |
| Check Weight Range: | 1000-4999g |
| Application Area: | Fruit, Vegetable & Poultry Industry |
| Type: | High Precision Series |
| Touch Screen: | Touch Screen |
| Sorting Method: | Pusher-bar |
Checkweighers are systems used to assure compliance with label weight regulations and to minimize product giveaway.
Our checkweighers will help you make sure items are not missing from packaging, reducing customer complaints, speeding up
production and minimizing your giveaway.
Function and structure characteristics of check weigher
1. apply advanced digital signal processing and realize high speed and stable weighing.
2. with liquid crystal and tangibly screen, it is easy to operate.
3. self-diagnosis function, when Rom/Ram, A/D light electric tube.
Scope of application of check weigher
Use in detecting the single product weight and setting target value which is accordingly or not. And the
sorting device will eliminate the unstandard product.
Features:
Solid SUS304 stainless steel structure enable for good performance
Belt disassembling without tools, which is easier to clean
Rejecter system choose :automatic stop by sound and light .air blast. or penumatic push rod
emergency stop button for safety working condition
Model Name | VC-10 | VC-15 | VC-22 | VC-15 | VC-25(Two belt) | VC-100 |
Weight range (g) | 3-100 | 3-300 | 10-1200 | 30-3000 | 50g-25kg | 1kg-100kg |
Mini weight accuracy (g) | ±0.1 | ±0.3 | ±0.5 | ±1 | ±5g | ±10g |
Mini screen value (g) | 0.01 | 0.1 | 0.1 | 0.1 | 0.5 | 1g |
Max weigh speed (Bags /Minute ) | 20 | 330 | 210 | 180 | 50 | 20 |
Belt speed | 0 | 16-118 | 13-96 | 13-96 | 13-78 | 3-15 |
Suitable product length (mm) | - | 60-180mm | 60-300mm | 60-420mm | 60-420mm | - |
Suitable product width (mm) | - | 30-150mm | 30-200mm | 30-250mm | 30-380mm | - |
Packaging & Shipping
we takes of plasti bas for prepackag
Then takes of ploywooden case for export
sales team can give you feedback within 12 hours after receive your inquiry
after sales service can give technical support within 48 hours after receive you need
our engineer team can go aboard for product line guidance and design
DongGuan V finder electronic&technology co;ltd is a professional metal detector and check weigher machine manufacture
