Product Specifications
| Prod Model: |
HBW-100 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| D-Maximum Scanning Depth: |
Max.250mm |
| Multi-Frequency: |
5 Segment Frequencies |
| Weight: |
Around 28kg |
| Certificate: |
CE ISO |
| Classification: |
Imaging Diagnostic Equipment |
| Type: |
Ultrasound Scanner |
| Certification: |
ISO13485 |
| Group: |
Adults & Children |
Product Description
FEATURE1, Full digital imaging technology
2, Crystal-clear Image
3, Computer platforms, Abundant functions
4, Powerful image and report management
5, 3D Image Function(optional)
6, DICOM display and transfer
7, 250G large Storage volume
8, Broadband Multi-frequency probes
9, Compatible with USB laser/inkjet printers
10, Pretty and new appearance
11, 15 inch touch screen color LCD monitor
12, Silica gel backlight waterproof keyboard
13, 8 segment TGC, 16 step zoom
14, Complete application software packages
15, Can work with external battery(option)
16, 2 probe connector
17, Can be fold, the transportation is convenient and lower freight
18, Multiple language: English, French, German, Spanish, Russian, Italian, Portuguese, etc.
SPECIFICATION1, D-Maximum Scanning Depth: max.250mm
2, Multi-frequency: 5 segment frequencies
3, Zoom: 10 ratio, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0
4, Image gray scale: 256 level gray scale
5, Cine Loop: max.1024 frames
6, Scanning mode: B, 2B, B/M, M, 4B, 9B, ZOOM; Real-time Zoom on B mode
7, Image processing: Pre-processing, after-processing, dynamic range, frame rate, line average, edge; enhancement, Black/White inversion; Gray scale adjustment, contrast, brightness, γ revision.
8, Gain: gain: adjustable between 0-100dB;
Time gain control (TGC): 8 segment adjustment, B, M adjustment separately.
9, Monitor: 15 inch touch screen color LCD monitor
10, Supported output apparatus: U-Disk, Laser/ink printer, video printer, VGA
Measurement and calculation(human):
1,B mode: distance, circumstance, area, volume, angle, ratio, stenosis, profile, histogram;
2,M mode: heart rate, time, distance, slope and stenosis;
3,Gynecology measurement: Uterus, cervix, endometrium, L/R ovary;
4,Obstetric: gestation age, fetal weight, AFI;
5,Cardiology: LV, LV function, LVPW, RVAWT;
6,Urology: transition zone volume, bladder volume, RUV, prostate, kidney;
7,Small parts: optic, thyroid, jaw and face.
Measurement and calculation(veterinary):
Cattle: BPD, CRL, TD; Horse: GA; Dog: GS; Cat: HD, BD;
Sheep: BPD, CRL, TD
Image store: by 250G hardisk or USB disk
Print: by USB laser/inkjet printers
DICOM3.0, medical digital imaging and communication
Probe Connector: 2
Weight: Around 28kg
Standard Configuration |
Optional |
| Host 1 unit | Linear, Trans-vaginal, Micro-convex, Rectal probe |
| Convex probe 1 pcs | Laser/ink printer |
| Ultrasound keyboard 1 pcs | Video Printer |
| Computer keyboard 1 pcs | 3D imaging function |
| Computer mouse 1 pcs | Battery |
We, Healicom is one of the leading professional suppliers in medical field in China. Our product range widely covers Surgical equipment, X-ray machine, Lab device, Patient Monitor, ECG, Ultrasound Scanner, Dental Equipment, Hospital Furniture, etc.
Established in 2002, as one of Chinese professional medical equipment companies, we specialize in manufacturing and marketing various hospital equipments (apparatus), medical disposable items and household medical appliances.
Our high efficient groups of professional technical and sales staff are able to provide you complete range of service at any time. Being approved by CE, ISO certificate, etc., our products are enjoying popularity in different countries and districts of Europe, America and Middle East, etc. With large exporting volume per year.
Products are manufactured either by ourselves or by cooperating with some reputed companies in China, so our prices are very competitive in international market. Meanwhile, excellent services and on-time delivery help us win great popularity among customers.
Please do not hesitate to contact us if you are interested in any of our products. We are looking forward to establishing business relationships with companies all over the world.
