Product Specifications
| Prod Model: |
Low-Iron Glass |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| 914mm: |
1000mm |
| Technique: |
Tempered Glass |
| Thickness: |
3.2-22mm |
| Shape: |
Flat |
| Structure: |
Solid |
| Color: |
Clear |
| Type: |
Float |
| Usage: |
Solar Panel, Building |
Product Description
Product Description:
Low Iron Glass is a kind of plate glass with highly clears, highly transmissive, highly smooth. And it is a new type of deeply processed glass, also it is a new type advanced structural glass with environment protection, economic on energy.FEATURES:
1. Excellent clarity ensures true colors are seen and optimum vision quality is achieved when looking through the glass.
2. Offers a high level of light transmittance.
3. Creates maximum light inside rooms due to the products high level of transparency.
4. Particularly beneficial for thicker laminated products, affording a high level of transparency.
5. The edges of the glass remain white, unlike other glass making it ideal for use in furniture.
Dimension is normally:
Thickness: 3-19mm, Width x Height: 12000x3300mm9. Tensile Strength: 42MPa
10. Hemispherical Emissivity: 0.84
11. Expansion Coefficient: 9.03x 10-6/º C
12. Softening Point: 720º C
13. Annealing Point; 550º C
14. Strain Point: 500º C
Standards and Certificates:
1. JIS B7502/B7512/R3106
2. ASTM-E-903-96/C1048.04
3. EN12150/DIN1249D
4. GB15763.2-2005
5. ISO9050
6. IEC61215
7. UL1703
8. SPF/u1
9. RoHS.
APPLICATION:
Low Iron Glass is a glass that is designed for applications where its unique appearance and optical qualities are of particular advantage such as:
*Display cabinets
*Shelves
*Glass furniture
*Table tops, bars and desk tops
*Shower screens
*Solar energy industries
| Thickness | Visible Light Transmittance | Visible Light Reflectivity | Solar Radiant Heat | Shading Coefficient | U Value | Sound Insulation | UV Penetration |
| Direct Penetrate | Reflect | Absorb | Total Penetrate | Short Wave | Long Wave | Total | (W/m2K) | Rm (dB) | Rw (dB) |
| 3 mm | 92.0% | 8.0% | 91.0% | 8.0% | 1.0% | 91.0% | 1.05 | 0.01 | 1.05 | 5.8 | 26 | 30 | 85 |
| 3.2 mm | 91.8% | 8.0% | 91.0% | 8.0% | 2.0% | 91.0% | 1.03 | 0.01 | 1.05 | 5.8 | 26 | 30 | 84 |
| 4 mm | 91.6% | 8.0% | 90.0% | 8.0% | 2.0% | 91.0% | 1.03 | 0.01 | 1.05 | 5.8 | 27 | 30 | 82 |
| 5 mm | 91.5% | 8.0% | 90.0% | 8.0% | 2.0% | 90.0% | 1.03 | 0.01 | 1.03 | 5.8 | 29 | 32 | 81 |
| 6 mm | 91.4% | 8.0% | 89.0% | 8.0% | 3.0% | 90.0% | 1.02 | 0.01 | 1.03 | 5.7 | 29 | 32 | 79 |
| 8 mm | 91.0% | 8.0% | 88.0% | 8.0% | 4.0% | 89.0% | 1.01 | 0.01 | 1.02 | 5.7 | 31 | 34 | 76 |
| 10 mm | 91.0% | 8.0% | 88.0% | 8.0% | 4.0% | 89.0% | 1.01 | 0.02 | 1.02 | 5.6 | 33 | 36 | 74 |
| 12 mm | 91.0% | 8.0% | 87.0% | 8.0% | 5.0% | 88.0% | 1 | 0.02 | 1.01 | 5.5 | 34 | 37 | 72 |
| 15 mm | 90.0% | 8.0% | 86.0% | 8.0% | 6.0% | 87.0% | 0.99 | 0.02 | 1 | 5.5 | 35 | 38 | 71 |
| 19 mm | 90.0% | 8.0% | 84.0% | 8.0% | 7.0% | 86.0% | 0.97 | 0.02 | 0.99 | 5.5 | 37 | 40 | 70 |
| Thickness: | 3-22mm |
| Sizes: | 1830x2440mm, 2134x3300mm, 2134x3660, 2250x3300mm, 2250x3660mm etc. maximum 3660x8000mm |
| Delivery Time: | In two weeks after order confirmation |
Beijing Northglass Technologies Co. Ltd, a leader in glass industry, has been engaged in the research, development, processing glass since 1987. Produce range includes: Laminated safety glass, tempered safety glass, low e insulated glass, reflective glass, silk screen printed glass(ceramic frit glass, enamalled glass), tempered glass, curved tempered glass, hot curved glass, heat strenghened glass, fire proof glass, bullet proof glass, ultra clear glass(low iron glass), etc for curtain wall shower doors, windows, facades and furniture applications.
By far, we have asset USD50 million. Our head quarter is in HongKong, and our 3 fabrication companies are in China mainland having more than 1, 000 employees, of whom over 46% is specialized techical personel. Our company covers more than 390.000sqm. We have massive elites working at each process of working, among whom, professional technicians are over 26% and employees with Bachelor's degree are over 93%.
Our glass pass Australian CSI certificates, US IGCC SGCC certificates, European CE certificates and Chinese national certificates. Now we are working with customers in over 100 countries. To help customer to better achieve their success is our aim. Welcome you work with us, and establish long term cooperation!
