| Price: | US $ 7.53/Piece |
|---|---|
| Min Order: | 100/Piece |
| Pay Type: | L/C,T/T,D/P |
| Prod Model: | MSP430F4250IRGZT |
|---|---|
| Category: | Mixed Signal Microcontroller |
| Low Supply-Voltage Range: | 1.8V to 3.6V |
| Active Mode: | 250 μa at 1 MHz, 2.2 V |
| Standby Mode: | 1.1 Ua |
| Off Mode (RAM Retention): | 0.1 Ua |
Mixed Signal Microcontroller
Low Supply-Voltage Range, 1.8 V to 3.6 V
Ultralow-Power Consumption:
Active Mode: 250 μA at 1 MHz, 2.2 V
Standby Mode: 1.1 μA
Off Mode (RAM Retention): 0.1 μA
Five Power Saving Modes
Wake-Up From Standby Mode in Less
Than 6 μs
16-Bit RISC Architecture
125-ns Instruction Cycle Time
16-Bit Sigma-Delta A/D Converter With
Internal Reference and Five Differential
Analog Inputs
12-Bit D/A Converter
16-Bit Timer_A With Three
Capture/Compare Registers
Brownout Detector
Bootstrap Loader
Serial Onboard Programming,
No External Programming Voltage Needed
Programmable Code Protection by Security
Fuse
Integrated LCD Driver With Contrast
Control for Up to 56 Segments
MSP430x42x0 Family Members Include:
MSP430F4250: 16KB+256B Flash Memory
256B RAM
MSP430F4260: 24KB+256B Flash Memory
256B RAM
MSP430F4270: 32KB+256B Flash Memory
256B RAM
For Complete Module Descriptions, See
The MSP430x4xx Family User's Guide,
Literature Number SLAU056
For Additional Device Information, See The
MSP430F42x0 Device Erratasheet,
Literature Number SLAZ022
Description
The Texas Instruments MSP430 family of ultralow-power microcontrollers consist of several devices featuring different sets of peripherals targeted for various applications. The architecture, combined with five low power modes, is optimized to achieve extended battery life in portable measurement applications. The device features
a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to maximum code efficiency. The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 6 μs. The MSP430F42x0 is a microcontroller configuration with a 16-bit timer, a high performance 16-bit sigma-delta A/D converter, 12-bit D/A converter, 32 I/O pins, and a liquid crystal display driver.Typical applications for this device include analog and digital sensor systems, digital motor control, remote controls, thermostats, digital timers, hand-held meters, etc.
