Integrated Circuit Tms320f28034pnt of Embedded - Microcontrollers IC

Product Specifications

Prod Model:	TMS320F28034PNT
Core Size:	32-Bit
Speed:	60MHz
Connectivity:	Can, I²c, Lin, Sci, Spi, Uart/Usart
Number Of I/O:	45
Program Memory Size:	128kb (64k X 16)
Operating Temperature Range:	-40 to 105 Deg. C

Product Description

Description
The F2803x Piccolo family of microcontrollers provides the power of the C28x core and Control Law Accelerator (CLA) coupled with highly integrated control peripherals in low pin-count devices. This family is code-compatible with previous C28x-based code, and also provides a high level of analog integration.

An internal voltage regulator allows for single-rail operation. Enhancements have been made to the HRPWM to allow for dual-edge control (frequency modulation). Analog comparators with internal 10-bit references have been added and can be routed directly to control the PWM outputs. The ADC converts from 0 to 3.3-V fixed full-scale range and supports ratio-metric VREFHI/VREFLO references. The ADC interface has been optimized for low overhead and latency.


Categories	Integrated Circuits (ICs)
	Embedded - Microcontrollers
Manufacturer	Texas Instruments
Series	C2000™ C28x Piccolo™
Packaging	Tray
Part Status	Active
Core Processor	C28x
Core Size	32-Bit
Speed	60MHz
Connectivity	CAN, I²C, LIN, SCI, SPI, UART/USART
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Number of I/O	45
Program Memory Size	128KB (64K x 16)
Program Memory Type	FLASH
RAM Size	10K x 16
Voltage - Supply (Vcc/Vdd)	1.71 V ~ 1.995 V
Data Converters	A/D 16x12b
Oscillator Type	Internal
Operating Temperature	-40°C ~ 105°C (TA)
Package / Case	80-LQFP
Supplier Device Package	80-LQFP (12x12)


Features
High-Efficiency 32-Bit CPU (TMS320C28x)
60 MHz (16.67-ns Cycle Time)
16 × 16 and 32 × 32 MAC Operations
16 × 16 Dual MAC
Harvard Bus Architecture
Atomic Operations
Fast Interrupt Response and Processing
Unified Memory Programming Model
Code-Efficient (in C/C++ and Assembly)
Programmable Control Law Accelerator (CLA)
32-Bit Floating-Point Math Accelerator
Executes Code Independently of the Main CPU
Endianness: Little Endian
JTAG Boundary Scan Support
IEEE Standard 1149.1-1990 Standard Test Access Port and Boundary Scan Architecture
Low Cost for Both Device and System:
Single 3.3-V Supply
No Power Sequencing Requirement
Integrated Power-on Reset and Brown-out Reset
Low Power
No Analog Support Pins
Clocking:
Two Internal Zero-Pin Oscillators
On-Chip Crystal Oscillator and External Clock Input
Watchdog Timer Module
Missing Clock Detection Circuitry
Up to 45 Individually Programmable, Multiplexed GPIO Pins With Input Filtering
Peripheral Interrupt Expansion (PIE) Block That Supports All Peripheral Interrupts
Three 32-Bit CPU Timers
Independent 16-Bit Timer in Each Enhanced Pulse Width Modulator (ePWM)
On-Chip Memory
Flash, SARAM, OTP, Boot ROM Available
Code-Security Module
128-Bit Security Key and Lock
Protects Secure Memory Blocks
Prevents Firmware Reverse Engineering
Serial Port Peripherals
One Serial Communications Interface (SCI) Universal Asynchronous Receiver/Transmitter (UART) Module
Two Serial Peripheral Interface (SPI) Modules
One Inter-Integrated-Circuit (I2C) Module
One Local Interconnect Network (LIN) Module
One Enhanced Controller Area Network (eCAN) Module
Enhanced Control Peripherals
ePWM
High-Resolution PWM (HRPWM)
Enhanced Capture (eCAP) Module
High-Resolution Input Capture (HRCAP) Module
Enhanced Quadrature Encoder Pulse (eQEP) Module
Analog-to-Digital Converter (ADC)
On-Chip Temperature Sensor
Comparator
Advanced Emulation Features
Analysis and Breakpoint Functions
Real-Time Debug Through Hardware
2803x Packages
56-Pin RSH Very Thin Quad Flatpack (No Lead) (VQFN)
64-Pin PAG Thin Quad Flatpack (TQFP)
80-Pin PN Low-Profile Quad Flatpack (LQFP)
