Product Specifications
| Prod Model: |
LH- |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product: |
Gold Chain PVD Vacuum Coating Machine Equipment |
| Business Type: |
China Manufacturer/Supplier |
| Brand: |
Hcvac |
| Structure: |
Vertical,Single Door |
| Technology: |
Plasma Coating |
| Control System: |
Manual Automatic All-in-One |
| Operating System: |
PLC Touching Screen |
| Coating Color: |
Gold,Rosegold,Silver,Black,Blue,Brown etc |
| Coating Effect: |
Metallized and Colorful |
| Chamber Material: |
Stainless Steel or Carbon Steel |
| Type: |
Coating Production Line |
| Coating: |
Vacuum Coating |
| Substrate: |
Metal,Ceramic,Mosaic,Glass,Crystal etc |
| Certification: |
TUV |
Product Description
Gold chain pvd vacuum coating machine equipment
1. Vacuum process;
2. Non-pollution
3. Get metallized and colorful film
4. Full automatic
Arc ion coating system is an ion coating machine of efficiency, harmless and pollution-free. It has the features of fast deposition rate, great ionization rate, big ion energy, easy operation, low cost, large productive capacity, etc.
Characteristic: The principle of the electric arc is intergrating cold cathode arc discharge self-sustained light unite pulse technique and magnetron sputtering technology, thinning the particles to improve the properties of the film. It can coat on the surface of the metal as well as nonmetal.
Applied industry: It can be used to coat metal film, titanium nitride, titanium carbide, and zirconium nitride, chromium nitride and titanium, nickel, chromium, copper, and other compounds film, multi-layer super-hard film, nitrogen-doped titanium film and the alloy film, and in a very short time to complete all the machining process, it is a highly efficient multi-functional coating equipment
This machine is extensively used in the fields of ultra-hard coating about the tools and mould, decorative coating about car wheels, ceramics, golf, watches making, hotel product, sanitary ware, luminaires, optical frame, hardware, etc.
Company introduction:
The coating experts of your own company: Full set solution for the coating production.
HCVAC can help you to enter the PVD coating easily by our vacuum coating machine and full range service. We will provide with most suitable technology according to your requirements.
We will make the special coating solution for each customer; Combine the full set production technics to meet your requirements, to ensure high efficiency of production.
We developed a complete after-sales system and effective service measures. Company now owns a professional after-sales service team with more than ten experienced engineers.
| Dimension | Φ 1100× H1000mm | Φ 1250× H1500mm | Φ 1600× H1800mm | Φ 1800× H1800mm |
| main configuration | 10 multi-arc targets | 12 multi-arc targets | 20 multi-arc targets | 22 multi-arc targets |
| power source | Electric-arc power, Filament power, Pulsed bias power supply |
| Process gas control | Mass flowmeter+Electromagnetic ceramic valve |
| Vacuum chamber structure | Vertical side opening door, pump system postposition, double water cooling |
| Vacuum system | Molecule pump+Root pump+Mechanical pump(8.0*10-5Pa) Diffusion pump+Root pump+Mechanical pump(8.0*10-4Pa) |
| Workpiece baking temperature | Normal temperature to 350 centi-degree PID control, radiation heating |
| Workpiece motion mode | Public rotation frequency control: 0-20 rotation per minute |
| Measure mode | Number display comosite vacuum gause: from atmosphere to 1.0*10-5Pa |
| Control mode | Manual/Automatic/PC/PLC+HMI/PC four choice of control mode |
| Remark | we can design the dimension of the vacuum equipment according to customer’ s special technique requirement. |
More information about our vacuum coating machine, pls do not hesitate to contact:
Contact person: Mandy Liu
Phone No.: +8613825755941/+8615989615980
