Print Technology: | Dye Sublimation (Direct-to-card) |
Print Capability: | Edge-to-edge printing
One-sided or dual-sided printing
Full color (YMCKO) and monochrome printing |
Print Resolution | 300dpi |
Display | LCM (Liquid Crystal Monitor) |
Memory | 32MB |
Print Speed | Full color printing (YMCKO) up to 180 cards per hour
Monochrome black printing up to 1400 cards per hour |
Card Format | Windows 2000/XP/2003; Mac driver |
Input Capacity: | 100 cards (0.76mm / 30mil) |
Output Capacity: | 50 cards (0.76mm / 30mil) |
Supported OS | Windows 2000,XP,Visa,Windows 7 (32/64-bit) |
Bundled Software | Card Desire CS |
Printer Dimension | 197.8mm(W) x 354mm(L) x204(H)mm |
Printer Net Weight | 4.9kg / 10.8Ibs (print media excluded) |
Operating Condition | 15~32ºC (59~ 89.6°F),20~75% RH non-condensing |
Print Media | Full panel YMCKO 400 roll (Ribbon only) ,16 rolls in a carton
1/2 panel YMCKO 560 roll (Ribbon only) ,16 rolls in a carton
Monochrome Resin Black 1000 roll (Ribbon only) ,16 rolls in a carton |
Operating Encoding Modules | Contact smart IC chip encoding module
Contactless (RFID) encoding module (ISO 14443A & B, ISO 15693)
Magnetic stripe card encoding module (ISO7811 Hi-co / Low-co) |
Other Options & Accessories : | Flipper module
High capacity input hopper (400 cards loader)
Ethernet TCP-IP connection module - Availability to be updated
Cleaning roller (Dust arrester excluded) - Availability to be updated |
SHENZHEN SEAORY TECHNOLOGY CO., LTD is a hi-tech company dedicated to smart card field since 2002.
We are specialized in manufacturing, researching, developing and selling of smart card, personalization card printer and smart card application system. Our headquarters is in Shenzhen. We have branch offices in Hongkong, Beijing, Shanghai and USA.
We produce PVC card, magnetic strip card, contact Memory/CPU IC card, contactless Memory/CPU IC card and dual interface CPU IC card.
FAQQ1. How to get faster feedback from us?1. Please describe the matter in short in the email subject and add "!".
2. Please add our sales skype or whatsapp from email signature to chat online.
Q2. Need a sample?1. Blank pvc card samples are free.
2. If you need printed samples with sophisticated printing, $30~$80 sample printing fee is required.
3. All the freight cost will be charged.
PS: The sample delivery time depends on the sample card type.
Q3. Product Catalog?- PVC card
- Magnetic stripe card
- Contact IC card
- Contactless IC card
- Dual frequency smart IC card
- RFID Wristband
- RFID Keyfob
- Card printer
- Ribbon
- RFID Reader&writer
Q4. What chip should I use?We have LF, HF and UHF chips with various memory and reading distance. If you are not sure, please inform our sales with project details.
PS: LF (125khz):EM4100,EM4102,EM4200,TK4100,T5577,EM4305 etc
HF (13.56mhz):Ultralight,ultralight C,S50,S70,FM11RF08,I CODE,QR2217,TKS50 etc
UHF (860~960mhz):Impinj M4,Monza 4E,Alien H3 etc.
Q5. What kind of personalization do you have?Printing Option:
1)4 color off-set printing
2)Silk-screen printing
3)Silver/Gold silk-screen printing background
4)Customer's designs are available
Available Crafts:
1)magnetic stripe
2)print barcode
3)embossing number
4)series number punch
5)signature panel
6)thermal printing
7)UV printing
8)hole punch
9)gold/silver color scratch-off
10)Customer's designs are available
Q6. What file of printing image should I offer to you?Design Files of AI, PDF, Corel Draw, Photoshop, CAD format are supported. If no, then send us JPG or BMP, we can design for your confirmation, it takes more time.
Q7. What about sizes?Standard size:CR80,85.5*54mm Or Customized as your request.
Q8. PVC Card thickness?Normal pvc card/magnetic strip card
0.76mm,250 pcs/inner box;
0.6mm,300 pcs/inner box;
0.46mm,400 pcs/inner box;
Contact/contactless card
0.81mm/0.86mm/0.9mm,200 pcs/inner box,2000 pcs/carton
TK4100 Thick card:1.8mm,100 pcs/inner box,2500 pcs/carton
Q9. What packing may I choose?Netural packing
For PVC card,250 pcs/box,20 box/carton,carton size:485mm*230mm*245mm;
For Smart card,200 pcs/box,25 box/carton,carton size:485mm*230mm*305mm;
For card printer,carton size:500mm*285mm*290mm;
For ribbon,carton size:265mm*240mm*215mm
Seaory brand packing
Seaory white card:500 pcs/box,6 box/carton,carton size:200mm*190mm*400mm;
Ps: We will use green woven bag out of the packing cartons to protect the carton damaged during the shipping.
Q10. Payment terms?We accept T/T and Western Union.
Ps: Usually TT in advance,also accept deposit,but balance should be paid before shipment.
Q11. What about shipping?We support all the international Express and we will provide you tracking number for every shipment.Large quantity we can ship by air or sea.
Q12. May I visit your company during my order production?Of course. Welcome to visit our factory! Please contact our sales for support.
