| Price: | US $ 5300-7500/Piece |
|---|---|
| Trade Terms: | FOB,EXW,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | FCT-9060L-CCD/FCT-1290L-CCD/FCT-1512L-CCD |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Control Mode: | CNC |
| Cutting Mode: | Laser |
| Type: | Laser |
| CO2 Laser Tube: | 80W, 100W, 130W |
Application:
The machine suit for engraving and cutting fabric,leather, wollens,organic glass,wooden item,bamboo item,plastic,rubber,ceramic tile,crystal,jade,etc.
Machine's main features:
1.Sopport many design softwares,such as CAD,CORELDRAW,etc., easily operate., CCD camera makethe position more accurate.
2.The aluminum bar table largely reduce the damage to object from reflecting light.
3.The honey comb table ensure light and soft object be cut in high accuracy.
4.Water chiller with alarming function make the machine work more safely.
5.Hot plugging USB data interface, data transferred easily and fastly.
6.Stable parallel laser make sure the cutting effectiveness the same in different area of the table.
Optional Configuration:
Servo motor and driver,red dot system,sate switch system,rotating axis,up-down table,multi laser heads,etc.
Our service:
1.The machine comes with 1 year warranty;
when it exceed warranty period,if the machine's part need to be changed,we can sell to you at our cost price
2. our technican could provide remote guide online if you need.
3. We are manufacturers specialized in CNC engraving and cutting machine,welcome to customize or distribute our machines.
if you have any question,pls contact with me:
| Model | FCT-9060L-CCD | FCT-1290L-CCD | FCT-1512L-CCD |
| Working size | 900*600mm | 1200*900mm | 1500*1200mm |
| Machine size | 1600*1100*1100mm | 2100*1400*1100mm | 2200*1700*1200mm |
| Laser tube power | 80w | 80w | 80w |
| Laser intensity control | Analogue or PMW | ||
| Mirror | imported | ||
| Focus lens | imported | ||
| CCD type | imported CCD camera | ||
| CCD interface | USB | ||
| Laser table | Knock down aluminum bar or honey comb table | ||
| Water chiller | Water pump or CW3000 | CW3000 | |
| Air compressor | Optional | ||
| Exhaust fan | Big power exhaust fan | ||
| Working speed | 0-24000mm/min | ||
| Max. scan accuracy | 2500dpi | ||
| Min. character | Chinese 1mm*1mm,English 0.8mm*0.8mm | ||
| Positioning accuracy | ±0.01mm | ||
| Supported format | BMP,GIF,JPG,PCX,TGA,TIFF,PLT,CDR,DMG,DXF | ||
| Motor driver | Stepper | ||
| Cutting thickness | 0-20mm depends on different material | ||
| Net weight | 500kg | 600kg | 800kg |
