Product Specifications
| Prod Model: |
MR8-200G |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material Of Packing Machine: |
Stainless Steel 304 or 316 |
| Food Filling And Sealing Packing Machine: |
Food Packaging Machinery |
| Food Rotary Packing Machine: |
Food Packing Machine |
| Packaging Machinery: |
Rotary Packing Machine |
| CE Certificate: |
Baccy Filling and Sealing Packing Machine |
| Albumen Powder Packing Machine: |
Chestnut Packing Machine |
| Gusset Pouch Packing Machinery: |
Nut Packing Machine |
| Type: |
Weighing-type Filling Machine |
| Automatic Grade: |
Fully Automatic |
| Material Type: |
Solid |
| Filling Valve Head: |
Multi-Head |
| Feed Cylinder Structure: |
Multi-Room Feeding |
| Dosing Device: |
Capacity Cup |
| Filling Principle: |
Pressure |
| Packaging Container Lifting Structure: |
Pneumatic Lifting |
| Structure: |
Rotary |
| Packaging Type: |
Bag |
| Packaging Material: |
Plastic |
Product Description
Main Features of packing machines
1, Full automatic performed bags packaging system suitable for large and medium size production industries.
2, Typical advantages of preformed pouch packaging system are minimum material wastages, easy product and bag size changeover, better sealing property especially for boil-in-bag and pasteurize bag products, excellent packaging presentation, versatile and suitable for all types of preformed bags packaging including sides seal bags, fin seal bags, gusseted bags, block bottom bags, zip-lock recloseable bags, stand-up pouch with or without spout etc. Only by quick adjustment without size parts change over.
3, Operators'friendly in design
4, Easy to clean and low in maintenance.
5, Complying with GMP standard, all product contact parts are in stainless steel and food grade materials
6, Sate of the-art PLC and touch screen electric control system Optional
7, Wash down and anti-rust construction
8. Possibility to lick-up and synchronize with other up and down stream packaging equipment
Applications for this kind of packing machines
1. Solid: Candy, peanut, green bean, pistachio, crystal candy, brown sugar, cookie, cake, dailycommodities, cooked food, pickles, puffed food, pet food, etc.
2. Granule: Grain, refined monosodium glutamate, capsule, seed, condiment, granulated sugar, chicken essence, melon seeds, nuts, granular drug, pesticide, fertilizer, feed, etc.
3. Powder: Spices, monosodium glutamate, salt, glucose, refined sugar, milk powder, washing powder, pesticidesfertilizers, chemical raw materials.
4. Liquid: Rice wine, soy sauce, ricevinegar, fruit juice, beverages, detergent and so on.
5. Thick liquid: Tomato sauce, peanutbutter, jam, chili sauce, bean paste and so on
| Model | MR8-200 |
| No. of working station | Eight |
| Function | Bags dispensing, Coding Opening, Dosing#1, Dosing#2, Heat sealing#1, Heat sealing#2 and Bag discharge |
| Pouch Type | All type of heat sealable preformed side seal bags, fin seal bags, gussetedbas, bloc bottom bas, zip-lock erecloseable bags, stand-up pouch with or withou spout etc. |
| Bags size | W100-205mm L: 100-300mm |
| Filling Volume | 5-2500g(depending on type pf product) |
| Capacity | 35-60bags/min(depending on type of product and packaging material used) |
| Total power consumption | 2.1Kw |
| Mahine Weight | Approx. 1200KG |
| Machine Dimension | Approx 1140*1500*1560mm |
