Product Specifications
| Prod Model: |
KBF |
| Product Name: |
Automatic Laser Marking Machine for Sale |
| Scan Field: |
140mm X 140mm(Customized) |
| Marking Character Per Second: |
>500/S(1mm Height, Single Line Word) |
| Defined According To The Information: |
<300m/Min |
Product Description
Product informationFeatured with the dedicated type, the quipment is of compact size and applied to the production line for flying marking. According to the different requirements of the customers, fiber, semi-conductor, YAG, CO2 machines are available for combining with the automatic production line, achieving the flying marking system as required of customers, realizing the production line operation, as well as improving the production efficiency.
Different type laser marking machineFiber laser marking machine: Low cost and Widely used for lot kinds of metal or nonmetal materials;
Pump laser marking machine: Less used and only for some special materials or deep marking or wire stripping;
CO2 laser marking machine: Mainly used for non-metallic (wood, Akley, paper, leather,etc.);
Green laser marking machine: Very fine marks, mainly used for high-end metal, plastic and other low demand products;
UV laser marking machine: Most fine marks, Mainly for high-end products, such as IC and precision work pieces.
Metal Tube (R-F Tube) CO2 Laser marking machineRF Series Co2 Laser Marking Machine installed RF Metal Co2 Laser Tube, is the new generation Laser Marking System, adopt industrial standardization module design, full set of imported metal sealed radiation frequency co2 lasers, high speed scanning vibrating lens and extending focusing system, high stability, anti-intervention industrial computer system, high precise vertical up-and-down working table. The machine can work on a continuous 24 working hours in high stability, high precision, high speed. . Co2 Laser Marking Machine can adjust the focus length by electronic motor and easy to operate and Laser Marking Service has won good feedback from our customers.
Production IntroductionAdopting USA original Synrad or Coherent R-F metal tube laser source, high-speed scanner imported originally from USA, this series laser machine obtains high speed and high accurancy with laser focusing solution in the rear part.By using Window interface, the software of the machine is compatible with different output formats,CorelDraw,AutoCAD,photoshop.illustrator,etc. The power, which controlled by software is continually adjusted.Due to no consumable material existing, the fabrication cost is lower. It has high effectiveness with large marking area and fine marking laser beam. Besides,the engraving depth can be controlled and adjusted for purpose. It is suitable for all kinds of products of non-material.
Applicable MaterialsApplicable toon-metal materials, such as paper, leather, cloth, organic glass, resin,acrylic,wool, plastic,rubber,ceramic,crystal,jade,bamboo and wood crafts.
Widely apply to different kinds of consumer commodities,food beverage packaging, medicine packaging,architecture ceramic,costume and accessories,leather and wool,gift and crafts, nameplates, jeans, furniture,etc.
Production Destription Details introductionTechnical Parameters | Type | KBF-F30 | KBF-F50 | KBF-CO2-10 | KBF-CO2-60 | KBF-UV-5 | KBF-UV-7 |
| Laser Source | Fiber Laser |
| Output Power | 50W30W/20w/10w |
| Wavelength | 1060nm |
| Beam Quality | <2 |
| Repeat Frequency | 10khz--- 100khz |
| Pulse Energy | 2mJ |
| Beam Divergence | -0.3 to +0.3mrad |
| Laser Class | IV |
| Resolution | 18μ |
| Repeatability | 50μ |
| Marking Scope | 140mmx 140mm (optional) |
| Linear Speed | 800 character/ s |
| Marking Linear Speed | ≤12,000mm/s |
| Marking Depth | Max. 1.0- 1.5mm (hard steel) |
| Min. Line Width | 0.012mm |
| Min. Character Size | 0.15mm |
| Repeat Accuracy | ±0.003mm |
| Input Power | 0.5kw |
| Electrical Source | 220v/50hz or 60hz |
Company information Shenzhen KBF Laser Technology, founded in 2012, is a high-tech enterprise that dedicated to industrial laser equipment and customized laser solutions. We have a good cooperation with some famous international laser companies, such as IPG, COHERENT, SPI, SYNRAD. At the same time, we also share information and technology with Chinese scientific research institutions. We commit to supply products with advanced technology and reliable quality. Products of our company can be divided into three categories by application: marking, welding and cutting. Laser marking machine mainly include MOPA fiber laser marking machine, CO2 glass tube laser marking machine, 3D dynamic marking series etc. In welding production, jewelry laser welding machine is the most popular. As for cutting, one type is for precise working and the other kind is for large breadth working. By now, our production and technology have been admitted and praised unanimously in the group of domestic and overseas clients. Hopefully we can be your trustworthy partner.
Our servicesPre-sales services*Inquiring and consulting support*Sample testing support*View our factoryAfter-sales services*Training how to install and use the machine*Engineers available to service machinery overseas*Two years warranty*Free partsWhy choose us?&We are laser equipment supplier, purchase from us at factory price&Specialized laser application team&Skilled workers with three to ten years experiences in laser industry&Fast responding to your requests&Quick delivery to your company&Two years warranty and with lifetime service&Ba able to train your operator or technicians through online or face to face &Free parts changePacking & Payment
FAQDear, in order to recommend the best suitable machine with the best quality and price for you, please kindly contact me with below questions, our professional services will satisfy you!
Q: Are you a factory or a trading company?
A: We are factory manufacturing packaging machines and we provide perfect OEM and after-sale service.
Q: How can I know your machine works well?
A: Before delivery, we do test the machine working condition for you.
Q: How can I know your machine is designed for my product?
A: You can send us samples of your product and we test it onmachine.
Q: How can I pay my order?
A: We accept T/T, Western Union paying methods. For those orders less than 1000USD, we accept PayPal to pay.
Q: Do you have a CE/FDA certificate?
A: For every model of machine, it has a CE/ FDAcertificate.
Q:If we do not know how to use the machine,can you teach us?
A:Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if you are busy ,we will have our professionall engineer to your country,you only need pay for some fee,like tickets, hotel and meal.
Q:When the machine can't work well,What should I do?
1. The Engineer is online for 24-hours, they can check the problems and then give you solution way very soon.
2.All our machines have two years' warranty, If there is any problems of machine parts under "normal use",new machine parts will be sent by air and customer pay for the shippemnt cost only.
3.Please rest assured that operation CD and manual will be offered along with machine,ensuring you can operate the machine easily.Please contact for more details
