Product Specifications
| Prod Model: |
ZHK100B-Black Crystal |
| Frame Size: |
12mm |
| Frame Material: |
Aluminum |
| Gain: |
0.8 |
| View Angle: |
160 Degree |
| 4K: |
Yes |
| 3D: |
Yes |
| Anti-Light: |
Best |
| Fabric Color: |
Dark Grey |
| Suitable Projector: |
Long Focus Projector |
| Certificate: |
Ce / RoHS / UL |
| Material: |
Soft PVC |
| Style: |
Frame Screen |
| Format: |
16:9 / 4:3 / 2.35:1 |
Product Description
XY Screens Ambient Light Rejecting Narrow Bezel Projection Screen with Strip Light
Fabric Parameter:
Model
Name: | Black Crystal | Color: | Front: dark grey
Back: silver |
| Material: | PVC fabric+black crystal coating | Moisture
Resistant: | Yes |
| Gain: | 0.8 | Cleanable: | Yes |
Viewing
Angle: | 160 degree | Roll
Width: | 2.5m |
Hole
Diameter: | / | Application: | Advanced, Top theater |
| Thickness: | 0.31 mm | Fabric
Feature: | Normal throw, Ambient light rejection, Low Gain |
Available
Products: | Ultra Thin Frame Projection Screen, Fixed Frame Projection Screen, Motorized Projection Screen, Fast Fold Projection Screen |
Product Features:Black Crystal is made of PVC, which is coated with special anti-light material, which absorbs ambient light and lamplight. This product has great anti-interference feature. There is a layer of crystal in the middle of the surface, which effectively improve the brightness and contrast.
Package Size:| Ratio | Size | Viewing Size | Total Size | Package Size | Frame Width
(mm) |
| Width(mm) | Height(mm) | Frame Width
(mm) | Frame
Height
(mm) | Length*Height*Width
(mm) |
| 16:9 | 80" | 1771 | 996 | 1795 | 1020 | 1983*342*148 | 12 |
| 90" | 1992 | 1120 | 2016 | 1144 | 2204*342*148 | 12 |
| 100" | 2213 | 1245 | 2237 | 1269 | 2425*342*148 | 12 |
| 110" | 2435 | 1369 | 2459 | 1393 | 2647*342*148 | 12 |
| 120" | 2656 | 1494 | 2680 | 1518 | 2868*342*148 | 12 |
| 135" | 2988 | 1681 | 3012 | 1705 | 3200*342*148 | 12 |
| 140" | 3099 | 1743 | 3123 | 1767 | 3311*342*148 | 12 |
| 150" | 3320 | 1867 | 3344 | 1891 | 3532*342*148 | 12 |
| 160" | 3542 | 1992 | 3566 | 2016 | 3680*342*148 | 12 |
| 170" | 3763 | 2116 | 3787 | 2140 | 3754*342*148 | 12 |
| 180" | 3984 | 2241 | 4008 | 2265 | 2596*240*264 | 12 |
| 200" | 4427 | 2490 | 4451 | 2514 | 2847*240*264 | 12 |
| 4:3 | 100" | 2032 | 1524 | 2056 | 1548 | 2244*342*148 | 12 |
| 120" | 2438 | 1828 | 2462 | 1852 | 2650*342*148 | 12 |
| 150" | 3048 | 2286 | 3072 | 2310 | 3260*342*148 | 12 |
| 180" | 3657 | 2743 | 3681 | 2767 | 3869*240*264 | 12 |
| 200" | 4064 | 3048 | 4088 | 3072 | 3399*240*264 | 12 |
| 2.35:1 | 120″ | 2804 | 1193 | 2828 | 1217 | 3016*342*148 | 12 |
| 135″ | 3155 | 1342 | 3179 | 1366 | 3367*342*148 | 12 |
| 150″ | 3505 | 1491 | 3529 | 1515 | 3717*342*148 | 12 |
| 180″ | 4206 | 1790 | 4230 | 1814 | 2300*240*264 | 12 |
| 200″ | 4674 | 1989 | 4698 | 2013 | 2534*240*264 | 12 |
Company Introduction: Guangzhou Xiong-Yun Audio-Visual Equipment Co., Ltd.(XY Screens) is one of the mid-to-high end projection screen manufacturers in the world, mainly producing Fixed Frame Projection Screen, Motorized Projection Screen, Portable Outdoor Projection screen, Engineering Screen, Projector Bracket, HDMI cable etc. Our products are extensively used in business and daily life, such as home theater, training and education, cinema and presentation of large projects. XY Screens has set up a standard production base of 15,000 square meters located in Nansha District, Guangzhou, China, with an annual production capacity of 200,000 sets of products. Our products sell well all over the world: China, Europe, the United States and other countries across the world. Since its inception, XY has always remained customer-oriented by putting customer satisfaction first and making high-quality projection screens that can deliver better user experience.
Contact Us:
August Liu
Tel: 0086 18826401386
FAQ:Q1. Are you a factory?
Yes, we have two factories in Guangzhou China. Welcome to visit us!
Q2. How many types projection screen do you produce?
Our factory mainly produces motorized projection screen, fixed frame screen, fast fold screen, tripod projection screen, manual screen, etc.
Q3.What types of projection screen fabric do you have?
We supply various fabrics, including front fabric, rear fabric, silver fabric, grey fabric, ambient light rejecting fabric, acoustic transparent fabric, etc.
Q4.What is the MOQ?
The sample in stock is 1 pcs; price can be negotiated if bulk order.
Q5.Can you customized the size?
Yes, the size can be customized from 60 inch to 500 inch.
Q6.Does all types projection screen have warranty?
Yes,one year will be given for all types of projection screen.
Q7.Can I customized my logo or package?
Yes, both will be accepted! Our factory welcome OEM&ODM orders!
Guangzhou Xiong-Yun Audio-Visual Equipment Co., Ltd. (Hereinafter referred to as "XY") is one of the high-quality projection screen manufacturer in the world. XY have production experience of over 10 years with a high reputation and cognition degree in the industry, which mainly offers projection screens to Europe, the United States and other countries. XY's projection screens are widely used in home theater, school, bank, government agencies, museums, weather stations, five-star cinema, military, auditorium, office, hotel, conference room and etc. The screens can be customized according to special requirements of customers.
In 2013, XY screens (French brand) entered into China and authorized Guangzhou Xiong-Yun Audio-Visual Equipment Co., Ltd. (a high-tech enterprise) to produce XY projection screens. XY quickly established a Dealer System in more than 100 cities. XY provide products, technology, training, marketing, retail concept, comprehensive services and support for the Dealers. With more than 15, 000 m² Workshop and advanced devices, the authorized factory can manufacture over 200, 000 screens each year.
XY is mainly focusing on home theater projection screen, business and education projection screen, film club / film KTV screen, large cinema screen, large project projection screen, portable outdoor fast fold screen, projector mounts, HDMI cable and other products. The products sell well in all over the world.
XY always attaches great importance to talents, so it has established a completed training system to improve the employees' working skills and professional knowledge.
Because of the continually improvement of human resource and production equipment, the manufacturing capacity and brand awareness have been improved in the meantime.
As an innovative enterprise, since its founding, XY has obtained dozens of patents. We continually explores and studies on screen material, the characteristics of optics and acoustics, etc. With Integrity and Profession, our company always supplies high quality products and maintains good partnership with our customers.
XY will be indomitable to promote the development of China smart home, audio and video entertainment, and will make a positive contribution in the future.
