| Price: | US $ 2000/Piece |
|---|---|
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | 6090 |
|---|---|
| Power(W): | 2.2kw |
| Weight: | 700kgs |
| Operating System: | Nc-Studio/DSP |
| Warranty: | 1 Year |
| Table Structure: | T-Slot Table |
| Driving System: | Servo Motor/Stepper Motor |
| Command: | G Command |
| Guide Rail: | Square Rail |
| Lathe Bed: | Pipe-Welding |
| Service: | Offering Oversea Service |
1.2.2 kw water cooling spindle(top brand in China),with high precision and strong power.
2.It is good at engraving on brass, aluminum, plastic, acrylic, wood, MDF and other similar materials. with fast speed and high accuracy, and it can meet the demand of all the needs of engraving.
3.It is equipped with the international leading NC studio control system (DSP for choice), which could memorize the breakpoint if it happens accident so that to guarantee to process in the other day..
4.With T-slot working table, holding the materials with clamps, you can do variety of high-precision works.
Advantages:
1.Advertising/artwork/woodworking/cutting
2.CE, SGS,ISO
3.Customized:Yes
4.High sensitivity
5.High efficiency
6. Warranty: 1 year
7. Engineers Available to Service Machinery Overseas
8.Door-to-door technical service and 24 hours technology online support
Application Industry and Materials:
Advertising industury: Cnc router can engrave all kinds of signage,logo products, trademarks, nameplates, badges, decorative gift, embossed
medals, certificates, souvenirs, photo frames, furniture decoration, PVC plates, PCB boards
(drilling and engraving),Double color boards,acrylic etc.
Woodworking Industry:Cnc router can be used for solid wood furniture,mahogany furniture,
MDF paint doors,solid wood doors,composite doors,cupboard doors and windows,beside
cabinets,folding screen etc.
Artwork industry:
in the wood, bamboo, organic board, double color plate, crystal and other materials on a variety of exquisite patterns and text engraving.
Parameter:
Certificate | CE |
Effective working area | 600(X)mm*900(Y)mm*120 |
Max.thickness of the materials | ≤120mm(the distance between Z-axis and the bottom of the working station) |
Moving type | Gantry moving |
Materials | Cast iron machine bed, cast aluminium gantry |
Dust proof system | For X YZ-axis |
Water cooling system | Small water pump |
Working table | Aluminum T Slot table |
Guide rail | Linear square guide rail |
Transmission | Ball screw for X Y Z-axis |
Driving mode | Stepper motor ( XY Z-axis: 86BYGH450A, 4.0N.M) |
Spindle motor | 2.2kw water cooling, ER20 |
Spindle speed | 0-24000rpm |
Cutters diameter | 3.175mm, 4mm, 6mm, 8mm,10mm,12.7mm |
Voltage | AC 220V, 50/60Hz, single phase or AC 380V,50/60Hz, three phases |
Empty traveling speed | 0-8000mm/min |
Engraving speed | 0-6000mm/min |
Machine accuracy | 0.03-0.05mm |
Diagonal error | 0.03-0.05mm |
Resetting accuracy | 0.03-0.05mm |
Control system | Mach3 control system |
Motor wire | High soft specially for Numerical Control( 4*0.75) |
Spindle wire | Shielding high soft (3*1.5) |
Carving Instructions | G code *Uoo *mmg *plt HPGL |
Compatible software | Artcam, Type3, Ucancam, etc |
Software when delivery | Artcam (2D/3D) |
Running environment temperature | 0-45 ºC |
Relative humidity | 30%-75% |
Auto tool calibration | Yes, for Z-axis |
Tools | 15 pcs |
Accessories | Water pump(1), tools(15) power line, USB line, fixtures(4), user manual, software CDs, Mach3, collets(3), spanners(2), collets(6),brush(1), water tank(2),limit swiches (3),etc. |
