Price: | US $ 0.66/Piece |
---|---|
Min Order: | 500/Piece |
Pay Type: | L/C,T/T,Western Union,Paypal,Money Gram |
Prod Model: | AC-E17227 |
---|---|
Keywords: | RFID Epoxy Tag |
Chip Option: | MIFARE |
Memory: | 1k Bytes |
Applications: | Access Control |
Crystal drop card, also known as Epoxy card has the appearance of fine fashion, easy to carry, extremely long service life advantages, is the perfect substitute of the traditional membership card. Integration of commercially available crystal glue process, Epoxy ard with a high degree of transparency, and highly bending, anti-yellowing cyclefar more than the market level. The crystal card internal package ID chip package TK28, TK41, H4100; MF1, F08, the I code sli etc. the 13.56M's IC reader chip, are widely used in public transport, patrol, access control, time and attendance, card and other application areas.
Description:
1. Chip: S50, FM1108, etc…
2. Frequency: 13.56MHZ
3. User memory : 1Kbytes
4. Protocol Standard: ISO 14443A
5. HF Read range:1-5cm (Related to the chip ,antenna and reader)
6. Read/Write Endurance: 100,000 times
7. Operating Temperature :-20°C to + 55°C
Physical Features: | ||||
Material | Epoxy | Dimensions | 30mm | |
Working Temperature | -20°C-75°C | Storage Temperature | -40°C-85°C | |
NFC Features: | ||||
Standard | ISO 14443A | |||
Chip Type | S50, FM1108, etc… | |||
Memory | 1Kbytes | |||
Frequency | 13.5mhz | Read Range | 1-5cm (Related to the chip ,antenna and reader) | |
Other Features: | ||||
Data Storage | > 10 years | |||
Re-write | 100,000 times | |||
Installation | Adhesive or hanging with a string | |||
Customization | Printing,URL encoding, Serial numbers,Web links, Designing,etc | |||
Application | Access control,Payments,Information collection and exchange , | |||
Custom setting,WIFI, Alarm, Business card,etc. |
Applications:
1. Access control
2. Anti-fake security
3. Time and attendance management
4. Tickets
5. Casino token
6. Membership
7. Public transportation
8. E-payment
9. Animal tracking
About us: Shenzhen A.N.G Technology CO., Ltd located in Shenzhen, is a high-tech manufacturer specialized in production Radio Frequency Identification Smart Card, NFC Label and Card Reader.Chip Model | Type | Frequency | Memory | Endurance | Data Retention | Protocol |
MF S50 | Contactless | 13.56MHz | 1K Byte | 100,000 | 10 year | ISO14443A |
MFS70 | Contactless | 13.56MHz | 4K Byte | 100,000 | 10 year | ISO14443A |
MF Desfire D21 | Contactless | 13.56MHz | 2K Byte | 500,000 | 10 year | ISO14443A |
MF Desfire D41 | Contactless | 13.56MHz | 4K Byte | 500,000 | 10 year | ISO14443A |
MF Desfire D81 | Contactless | 13.56MHz | 8K Byte | 500,000 | 10 year | ISO14443A |
MF Ultralight | Contactless | 13.56MHz | 64 Byte | 100,000 | 5 year | ISO14443A |
MF PLUS S2K/4K | Contactless | 13.56MHz | 4 Byte | 200,000 | 10 year | ISO14443A |
I-Code SLI | Contactless | 13.56MHz | 1024 Bits | 100,000 | 40 year | ISO15693 |
FM11RF08 | Contactless | 13.56MHz | 1K Byte | 100,000 | 10 year | ISO14443A |
FM1208 Series | Contactless | 13.56MHz | 8K Byte | 100,000 | 10 year | ISO14443A |
EM4200/4305 | Contactless | 125KHz | 100,000 | 10 year | ISO11784/785 | |
T5577 | Contactless | 125KHz | 330 Bits | 100,000 | 10 year | ISO11784/785 |
Alien | Contactless | 860~960MHz | 512 Bits | 100,000 | 10 year | ISO18000-6C |
SLE4442/5542 | Contact | 256 Byte | 100,000 | 10 year | ISO7816 | |
SLE4428/5528 | Contact | 1 Byte | 100,000 | 10 year | ISO7816 |
