Product Specifications
| Prod Model: |
MCD-2012 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Metal Detector |
| Installation Mode: |
Built in |
| Usage: |
Metal |
| Detection Zones: |
8 Zones |
| Character: |
with Big Color Touch Screen |
| Alarm Way: |
Audio Alert & LED Location Lamp Work at Same Time |
| Warranty: |
12 Mouths |
| Use: |
Body Security Checking |
| Application: |
Industry |
Product Description
Introduction:
1. The detecting door possesses a LCD (liquid crystal display) with Chinese and English operation menus and direct operation guide, which makes it easier to set the operation parameters, the English operation interface is especially suitable for foreign sites, additionally, all of the parameters can be set by the remote controller
2. The detecting door is highly creative and made of PVC advanced synthetic materials, with aseismatic design, both the top and bottom of the door body are equipped with waterproof casing which can prevent water, fire and erosion etc
3. Possess six lapped metal detecting areas, adopt the current digital pulse technology, interactive transmitting and receiving, and fix the position of metal articles accurately
4. Two sides of door posts contain LED lamps by which you can directly see the position of prohibited articles hidden on the human body, the visual angle reaches as much as 360 degress, which is clear and bright improving the work effciency to great extent
5. Each detecting area has 200-level adjustable sensitivity programs, in older to detect different prohibited articles, you can pre-set the sensitivity relevant to the possible position, volume weight, and size of metal articles, and get rid of the belt clamp, key, ornaments and coin etc, at the max sensitivity, the detect the clip-sized matal
6. The detecting door is equipment with a powerful DSP signal processing digital filtering system which adopts the most advanced electromagnetic compatibility technology in the word nowadays to achieve an excellent resistance to electromagnetic disturbance, touch and impacts.
Technical parameters:
Power supply: AC 100 to 240V, 47/63Hz
Power: < 30W
Signal Frequency: Auto
Operation Temperature: -20° C ~ 55° C
Through rate: More than 60 persons / per minute.
Waterproof level: IP56
Weight: About 65kg
Delivery weight: About 95kg.
Overall size: 2230 mm (height)*820 mm (width)* 630 mm (depth)
Tunnel size: 2000 mm (height) *700 mm (width)* 560 mm (depth)
In accordance with: EN60950, WN50081-1, And EN50082-1, EMC, EC
CE Certificate; National standard GB15210-2003
Technical parameters:
Power supply: AC 100 to 240V, 47/63Hz
Power: < 30W
Signal Frequency: Auto
Operation Temperature: -20° C ~ 55° C
Through rate: More than 60 persons / per minute.
Waterproof level: IP56
Weight: About 65kg
Delivery weight: About 95kg.
Overall size: 2230 mm (height)*820 mm (width)* 630 mm (depth)
Tunnel size: 2000 mm (height) *700 mm (width)* 560 mm (depth)
In accordance with: EN60950, WN50081-1, And EN50082-1, EMC, EC
CE Certificate; National standard GB15210-2003
Shenzhen MCD Electronics Co., Ltd is a large-scale security equipment manufacturer, which intergrets R&D, manufaturing and marketing together. Founded in 2005, MCD mainly concerntrated ondeveloping Metal Detector, Electronic Article Surveillance(ESA) devices, Food Packaging Testers, X-ray Package Checkers, Under Vehicle Inspection Equipments, Explosion-proof equipments ect.
Our products include Walk Through Metal Detector Doors, Underground Metal Detectors, Handheld Metal Detectors, ESA for supermarkets and libraries, Needle Detection Machines, X-ray Inspection equipments, Under Vehicle Inspection Mirrors, ect. Our products have been widely used in airports, embassies, army, prisons, prosecutions, government angecies, customs, ports, large public events and exhibitions, as well as places need valurable security.
Cooperating with many well-known foreign companies equiped us with strong technology strengthes, speedy products development. With strict management regulations, our products strictly produced under the ISO9001: 2008 standard. With more than 3000 square meters production workshop, full flow operation, full-equiped production and testing equipments, we promise to offer the best products for our clients.
Under thesolid strength of the company, excellent R&D team, impressive stability and performance product asour R&D purposes and offering most affordable price to clients as our early design purpose, we have estabilished, mutual beneficial, win-win and long-term cooperation relationshipwith our clients. With the effort of all our staff, our company has developed into a leader manufacturer in safety testing equipment industry just in a few years.
