Wenzhou Cicel Vacuum Machine Co., Ltd. >> Vacuum Coating Machine for Fashion Sunglasses, Sport Glasses, Reading Glasses Frame Color Coating

Vacuum Coating Machine for Fashion Sunglasses, Sport Glasses, Reading Glasses Frame Color Coating

Vacuum Coating Machine for Fashion Sunglasses, Sport Glasses, Reading Glasses Frame Color Coating
Price: US $ 45000-150000/Set
Min Order: 1/Set
Pay Type: L/C,T/T

Product Specifications


Prod Model: CCZK-ION
Machine Type: Magnetron Sputtering
Chamber Size: Can Be Customized According to Details Requirement
Application: Sanitary Ware,Car Wheel,Hard Ware,Cutleryetc
Coating Color: Golden, Rose Gold,Black,Blue,Rainbow Color,etc
Coating Film: Tin, Tic, Ticn, Tialn, Crn, Cu, etc
Sputtering Target: Titanium, Chrome,Zirconium,Titanium Aluminium ,etc
Gas: Nitrogen,Argon,Oxygen,Acetylene
Voltage: 380 V or as Request
Package: Wooden Package or as Request
After Sales: Free Training & Oversease After Sales Available
Type: Coating Production Line
Coating: Vacuum Coating
Substrate: Stainless Steel ,Glass, Metal, Ceramic, Crystal

Product Description

vacuum coating machine for fashion sunglasses, sport glasses, reading glasses frame color coating

What is Magnetron sputtering vacuum metalizing?

One form of PVD coating technology is magnetron sputtering. The vacuum chamber of the PVD coating machine is filled with an inert gas, such as argon. By applying a high voltage, a glow discharge is created, resulting in acceleration of ions to the target surface from the target. Often an additional gas such as nitrogen or acetylene is used, which will react with the ejected material (reactive sputtering).
Magnetron sputtering uses magnetic fields to increase the plasma density in front of the target. Resulting in increased efficiency, higher sputter rates and improved ion bombardment during the growth of the coating. The coatings are mostly used for tribological and decorative applications.
How Magnetron Sputtering Vacuum metalizing is done?

      Mainly Process includes

Parts are sprayed with a basecoat
Parts are racked, racks put into the chamber, the chamber is then sealed.
Argon gas is introduced into the chamber in a continuously flowing manner.
Electricity creates an active Argon plasma field in front of the cathode. (The cathode is an assembly with contains magnets and provides a mounting for the target-a plate of the material which will be deposited.)
The magnets are located behind the target.
The positively charged (ionized) Argon atoms are accelerated by passing through a magnetic field (created by magnets are located behind the target.)
The positively charged (ionized) Argon atoms are accelerated by passing through a magnetic field (created by magnets inside the cathode).
The positive atoms are attracted to the negative charged cathode which contains the target.
The targets is bombarded with each ion particle, they individually break off an atom of the target materials with each collision (target hit continuously).
Continuous (and directed) sputtering of the release target atoms are "shot" onto the surface of part
The basecoat material /paint provides a smooth surface for the atoms to be deposited together and build up on the part.
The part is top coated

Why sputtering vacuum metalizing?

      Sputtering / PVD can be used with plastics, metal, or glass- on pieces utilized in almost any        industry, to create tough- wearing and decorative coatings, with excellent results.
Applications
      Magnetron Sputtering Coating Machine for Applications of:
Hardware coating--decorative vacuum metallizing
Solar Control Reflective Glass
Low-E Glass
Sputtering Aluminum Mirror
Automobile Mirror
Auto car wheel
Plastic/metal cutlery
With the various coating technology, customizing product design and state-of-the-art manufacturing, CICEL is devoted to provide the advanced and economy total solution for glass coating application. CICEL is able to design the professional coating equipment for customer's specialized application, develop variety coating process together and provide the continuous technical supporting and upgrading to our customer


Support Service & Philosophy

At CICEL, we stand behind our systems with a dedicated service team who can diagnose and provide support when required, allowing you to maximize the return on your investment. Some of the parts and services that we offer include:
Reply your enquiry within 24 working hours
Experienced sales engineer will give your professional suggestion according to your details requirements
Offer customized design machine and overseas after-sales training. Buyer's engineer can come to our factory for machine and process training before delivery, also our engineer will visit customer's factory for professional training and installing the machine .
Supply replacement parts and consumable item for machine
Retrofits and Upgrades
After-sales Maintenance
Technical Assistance and Consulting
Our dedicated service team is available 24/7 to provide superior service and to meet the needs of our customers.  From the initial installation and training to providing maintenance on existing equipment, we are here for you.
Contact us for more information on PVD vacuum Coatings machine or to request a quote


Innovators in Physical Vapor Deposition (PVD) Coating Machine and Systems

For almost decade years, Cicel vacuum machine Col, Ltd. has been an industry leader in vacuum coating equipment. We provide PVD coating machine, magnetron sputtering vacuum coating equipment, plastic vacuum metalizing machine, optical electron beam coating machine, automatic UV spray line, etc. All of our vacuum coating machine and UV spray line has passed the EU CE certificated.

We are committed to developing long-term relationships with our customers from abroad and domestic, and strive to provide the highest possible levels of satisfaction through our innovative vacuum machines and services.

To learn more about our vacuum metalizing machines and services, please just feel free to contact us at anytime.
