Product Specifications
| Prod Model: |
ST007 |
| Metals/ Materials: |
Tungsten Carbide, Tungsten Alloys, High Speed Stee |
| Tolerance: |
+/-0.001mm |
| Equipment: |
EDM Machines, Cutting Machine and Drilling, CNC Ma |
| Type: |
Tunsten Punch |
Product Description
Precision workshop: Tungsten carbide, dies, punch, cutting tools, customized parts
Our products: carbide dies, rollers, punches, bushings, cutters, blades, nozzle and customized machine parts.
Tolerance: +/-0.001mm
Equipment: EDM machines, Cutting Machine and drilling, CNC machine, Precision grinding machine etc.
GRADE |
ISO CODE |
COBALT CONTENT |
DENSITY |
HARDNESS |
TRS |
(%) |
g/cm3 |
HRA |
N/mm2 |
K10T |
K05-K10 |
4.5-6.0 |
14.95-15.05 |
92.7 |
1800 |
YG8 |
K30 |
8 |
14.80 |
89.5 |
2200 |
YG6 |
K20 |
6 |
14.95 |
90.5 |
1900 |
YG6X |
K10 |
6 |
14.95 |
91.5 |
1800 |
YL10.2 |
K30 |
10 |
14.50 |
91.8 |
2400 |
YG13X |
K30-K40 |
13 |
14.30 |
89.5 |
2600 |
YG15 |
K40 |
15 |
14.00 |
87.5 |
2800 |
YL20.8 |
K40 |
15 |
14.00 |
88.5 |
3800 |
PureTungsten
As a high performance materials, pure tungsten has high melting temperature, high density, low vapor pressure, low thermal expansion combined with good thermal conductivity, sufficient electrical resistance, high modulus of elasticity.
Tungsten sheets and disk are available with alkali washed or ground finish. Tungsten bar and rod stock are available with ground surfaces and as sintered or swaged condition. Large ranges of custom crucibles and single crystal ingots are offered.
Pure tungsten Products is widely used for Furnace parts, Semiconductor Base Plates, Components for Electron Tubes, Emission Cathodes for Electron Beam Evaporation, Cathodes and Anodes for Ion Implantation, Tubes / Boats for Sintering of Capacitors, Targets for X-ray Diagnostics, Crucibles, Heating Elements, X-ray Radiation Shielding, Sputtering Targets, Electrodes.
Maufacturing facility
COD-pressure sintering furnace
COD-pressure sintering furnace combine with vacuum dewaxing, vacuum and
pressure sintering integration features; maximum pressure can up to 100bar;
most effective loading length up to 3 m long. COVtype vacuum sintering furnace
has dewaxing and sintering in vacuum functions; can remove wax for pressure
molding, extrusion or injection molding parts efficiently .
Informations for ZZ sintec metals
If you are finding materials with long life and high hardness,
If you are finding materials resisting high temperature and corrosion,
If you are finding factory to produce any custom-tailor tools or parts,
Zhuzhou Sintec New Material Co., Ltd has a lot to offer!
Based in Zhuzhou, the most biggest collecting and distributing center in the world,
we can easily absorb economical raw materials; advanced techniques,equipment;
and skilled management methods.
That's why, during past twenty years, Sintec has been supplying leading carbide tools,
precision parts for more than 20 countries in North America, Europe, South America,
Southeast Asia.
Sintec Will be adhering to the "quality products, quality service, good reputation"
spirit, to think what you are thinking, to do what you wanna us to do; final goal is
Zhuzhou Sintec New Material Technology Co., Ltd has more than twenty years experiences in manufacturing, our company originate from a professional workshop of the high temperature sintering technology the products, tungsten carbide, refractory metals like Tungsten, Molybdenum, Niobium; And the ceramics products like silicon carbide, silicon nitride.
To meet the growing of business and offer fully service to our clients, we set up another new machining workshop Sintec Metal Fabrication in 2012, equipped with the EDM machines, WEDM, center-less grinder, cylindrical and internal grinder, high precision universal grinder, surface-grinding machine, CNC lather, CNC milling machine, experienced the manufacturing of tungsten carbide molds, tools, cutters, inserts and other customized wear parts. With the growth of manufacturing experience, we can also machining the parts that made by the various materials like tool steel, high speed steel, refractory metals, ceramics, stainless steel, high-temperature alloy, corrosion resistant alloy and the powder metallurgy metals
Based in Zhuzhou, the biggest production base of tungsten carbide in the world and the traditional industrial town of China, we can easily absorb professional materials, advanced techniques, various equipment; And skilled management methods. With successful cases to service for the industrial files of mold manufacture, machinery, aviation, oil and gas, automobile, medical industry and other civil products development filed, we had exports the products to more than 20 countries in North America, Europe, South America, Asia and Australasia.
Main Products:
Tungsten Carbide, Titanium Carbide raw materials, tools, molds, punchs, dies, cutters and wear parts
Refractory metals: Tungsten alloy, Pure tungsten, Molybdenum plates, rods, wires
Ceramics, Silicon Carbide, Silicon Nitride, Zirconium oxide balls, seal rings, nozzels, bushings
CNC machine parts, Tool steel, HSS, Stainless steel, High-temperature alloy, Corrosion resistant.
Materials and processing solution and supports for new design parts and products researching.
