Product Specifications
| Prod Model: |
JTL-series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product: |
Taps Faucets Bathroom Ware PVD Coating Machinery |
| Brand: |
Hcvac |
| Technology: |
Ion Coating+Sputtering Coating |
| Structure: |
Vertical, Single Door |
| Control System: |
Manual Autoamtic All-in-One |
| Operating System: |
PLC Touching Screen |
| Coating Film: |
Tin, Ticn, Crn, Tialn, Tinbu, Ticrn, Zrn etc |
| Coating Color: |
Gold, Rosegold, Silver, Black, Blue etc |
| Chamber Material: |
Stainless Steel |
| Size: |
Customized |
| Type: |
Coating Production Line |
| Coating: |
Vacuum Coating |
| Substrate: |
Glass, Metal, Ceramic, Alloy, Crystal, Mosaic |
| Certification: |
ISO9001, CE, TUV, SGS |
Product Description
Taps faucets bathroom ware PVD coating machinery PVD gold/rose gold/copper/blue/black The machine is mainly design for sanitary ware/bathroom fitting parts. It's equipped with several big size electrical arc evaporation sources and magnetron sputtering coating system, to deposit high performance metal decorative film on brass, zinc alloy, stainless steel, plastic and other metal parts surface. It can get all types of metal color series on substrate. The coating film includes TiN, Zr,T iCN, ZrCN, CrN, CrCN, brass, bronze, chrome etc. Color series includes AF, SN, BN, VF, BV, G, BX, TB, AF, SN, 96CB, CB, TXB, VS, S, BS, BRZ, BGD, PGD and so on. It can get different colors by adjusting coating technics. It is largely used in the sanitary ware/ Kitchen ware field.
The bis size cathodic arc evaporation source new target and the arc power supply, arc spot is stable. It is not easy running arc, the current is low and ionparticles is small. Applied to metal, ceramics, glass and other materials of the surface coating of hard metal film and metal compounds film. Pumping speed faster, vacuum stability, and superior quality film, widely used in hardware, watches, glasses, tools, dies, metal, glass, ceramics, building materials, and other surface treatment industry.
HCVAC decorative PVD films are routinely used as a replacement for electroplated chrome. They can be applied directly over almost any substrate material and can be deposited in a wide variety of colors. The process parameters to deposit each color are stored in software recipes with different process steps. Once the coating process has started, all of the relevant process parameters are continuously monitored and controlled by the on-board computer software.
The coatings provide improved properties such as hardness, wear-resisitance, corrosion-resistance, and fracture/fatigue performance without unwanted changes in component bulk properties. This advanced technology coating process replicates the original surface finish, eliminates re-polishing after coating, and will not chip or flake off.
Mode
Dimension | LH-800 | LH-1250 | LH-1416 | LH-1618 |
| 800*1000mm | 1200*1500mm | 1400*1600mm | 1600*1800mm |
| Coating mode and main confirguration |
Eight multi-arc targets |
Twelve multi-arc targets |
Fourteen
multi-arc targets |
Twenty
multi-arc targets |
| Power source | Electric-arc power, Filament power, Pulsed bias power supply |
| Process gas control | Mass flowmeter + Electromagnetic ceramic valve |
| Vacuum chamber structure |
Vertical side opening door, pump system postposition, double water cooling |
| Vacuum system | Molecule pump +Roots pump +Mechanical pump(5.0*10 -5 Pa)
Diffusion pump +Roots pump +Mechanical pump(5.0*10 -4 Pa) |
| Workpiece baking temperature |
Normal temperature to 350 centi-degree PID control, radiation heating. |
| Workpiece motion mode | Public rotation Frequency control: 0-20 rotation per minute |
| Measure mode | Number display composite vacuum gauge: from atmosphere to 1.0*10 -5 Pa |
| Control mode | Manual/Automatic/PC/PLC + HMI/PC four choice of control mode |
| Remark | We can design the dimension of the equipment according to customer's special technique requirement. |
