Structural Steel

Structural Steel
Price: US $ 3000/Ton
Trade Terms: FOB,CFR,CIF
Min Order: 1/Ton
Pay Type: L/C,T/T,Paypal,Western Union

Product Specifications


Prod Model: 316,,304L,316,316L,317L,321,347H,310S,S31803,904L
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: 8mmodx0.5mm-3000mmodx45mm

Product Description

Exquisite technology,Premium Quality are the reason to choose DAPU!





 Products details:

Name

 Structural steel

Items

Square tubes, round tubes, oval pipes, special shaped pipes,

empaistic pipes, fittings

Standard

ASTM GB, EN, JIS, DIN, AISI..

Material Grade

201: Ni 0.8%~1%

202: Ni 3.5%~4.5%

304: Ni 8%, Cr 18%

316: Ni 10%, Cr 18%

316L: Ni10%~14%

430: Cr16%~18%

Outer Diameter

9.53mm--159mm

Thickness

0.3mm - 3.0mm

Length

6m or as customers' request



Tolerance

a) Outer Diameter:  +/- 0.2mm

b) Thickness: +/- 0.02mm

c) Length: +/- 5mm

Surface

180G, 240G, 320G Satin / Hairline

400G, 600G Mirror finish

Application

handrail,railing, staircase, weldmesh screen,door,window, balcony,fence,bench,furniture,etc

Test

Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT









Chemical Composition of Material

  Material



Composition

201

202

304

316L

430

C

≤0.15

≤0.15

≤0.08

≤0.035

≤0.12

Si

≤1.00

≤1.00

≤1.00

≤1.00

≤1.00

Mn

5.5-7.5

7.5-10

≤2.00

≤2.00

≤1.00

P

≤0.06

≤0.06

≤0.045

≤0.045

≤0.040

S

≤0.03

≤0.03

≤0.030

≤0.030

≤0.030

Cr

13-15

14-17

18-20

16-18

16-18

Ni

0.7-1.1

3.5-4.5

8-10.5

10-14



Mo







2.0-3.0





Mechanical Property

Material Item

201

202

304

316

Tensile Strength

≥535

≥520

≥520

≥520

Yield Strength

≥245

≥205

≥205

≥205

Extension

≥30%

≥30%

≥35%

≥35%

Hardness (HV)

<105

<100

<90

<90



  Our Advantage



(1): High quality stainless steel tube with reasonable price
(2): Wide excellent experiences with after-sale service
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely
(5): Trial order can be done in one week
(6): Samples can be provided as your requirements.

We are professional manufacturer of stainless steel products, including stainless steel decorative pipes,industrial stainless welded pipesspecial-shaped pipes, stainless steel

sheet and  Structural steel etc. Main materials are: 304,304L,316,316L,321,317L,347H,S31803,2205,904L and so on.


Surface Finish :

Surface finish

Characteristics and application

No.2B

The surface brightness and flatness of no2B is better than no2D. then through a special surface treatment to improve its mechanical properties,No2B could nearly satisfy comprehensive uses.

No.3

Polished with abrasive belt of git#100-#200, have better brightness with discontinuous coarse stria, used as inner and external ornaments for building, electrical appliances and kitchen utensils etc.

No.4

Polished with abrasive belt of grit #150-#180,have better brightness with discontinuous coarse stria, but thinner than No3, are used as bathtub buildings inner and external ornaments electrical appliances kitchen utensils and food processing equipment etc.

HL

Polished with abrasive belt of grit #150-#320 on the NO.4 finish and has continuous streaks, mainly used as buildings ornaments elevators, door of building, frontal plate etc.

BA

Cold rolled, bright annealed and skin-passed, the product have excellent brightness and good reflexivity like mirror, kitchen apparatus, ornament etc.

8K

The product have excellent brightness and prefer reflexivity can to be the mirror.

Products:
we are professinal in producing Stainless steel seamless pipe and welded pipe, and we also  supply other stainless steel products: stainless steel fitting, flange, plate, coil, bar, and others.

Certificate:
ISO9001-2000 , PED, SGS and
the Manufacture License of Special Equipment People's Republic of China.

Production capacity :
The company's annual production capacity is 15000 tons stainless steel welded pipe, and 8000 Tons seamless stainless steel Pipe.


Inspector equipment:
The company has a professional testing center, with advanced testing equipment at home and abroad: eddy current flaw detector, ultrasonic flaw detector, direct-reading spectrometer , X-ray detector ,pressure unit, universal pressure test apparatus, and crystal physics and chemistry equipment. In strict line with GB, ASTM(ASME),EN,DIN,JIS and other international standards pipe respectively








Huzhou Dapu Stainless Steel Co., Ltd, is a company specialized in producing and marketing stainless steel pipe products. The company is jointly established by two companies which are professional manufacture of stainless steel welded pipe and stainless steel seamless pipe respectively. Company has professional production equipment and advanced testing equipment. We also have passed certificated by ISO9001-2000 and PED, and have obtained the Manufacture License of Special Equipment People's Republic of China.

The company annual production capacity is 15000 tons of stainless steel welded pipe, and 800 Tons of seamless stainless steel, in strict line with GB, ASTM(ASME), EN, DIN, JIS and other international standard. The company has a professional testing center, with advanced testing equipment at home and abroad: Eddy current flaw detector, ultrasonic flaw detector, direct-reading spectrometer, X-ray detector, pressure unit, universal pressure test apparatus, and crystal physics and chemistry equipment.

Specification group form that produce stainless steel welded pipe: Single slit(Φ 8mm-Φ 630mm), wall thickness(0.5mm-25mm), girth(Φ 630mm-Φ 3000mm), wall thickness(3mm-45mm)

Specification group form that produce stainless steel seamless pipe(Φ 6mm-Φ 610mm), wall thickness(0.6mm-30mm).

Main material: 304\304L\316\316L\321\310S\317L\347H\S31803\2205\904L, etc. The produce are widely used in petroleum, chemical, paper, machinery, medicine, shipping, heat exchanger and other field.

If a single business is more than $100, 000, we will provide one third party inspection for our customer.

Company concept: "Quality to win markets, improvement to win progress". Welcome customers all over the world come to our company to give guidance for development.
