Product Specifications
| Prod Model: |
Custom-made |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
Optical Glass |
| Type: |
Sapphire Ball |
| Shape: |
Custom-Made |
Product Description
For good mechanical properties and hardness( Mohs 9), sapphire and ruby are often used for the bearing of many meters, clocks, parts of abrasion-resistance. V-shape and U-shape bearing are widely used in flowmeters, ammeters, water meters.
Specification
Outside Diameter: 0.80~10.00mm, max deviation of outside diameter: H7~h9
Height H: 0.60 ~ 5.00mm, max deviation of height: ± 0.01
Cup depth h: 0.20 ~ 0.80mm, max deviation of cup depth: 0 ~ 0.06
Curvature radius SR: 0.60 ~ 5.00mm, max deviation of curvature radius: ± 0.03
Taper: 60° ~ 120° Max deviation of taper: ± 5°
Technical Index
Material: Synthetic sapphire/ruby single crystal a-Al2O3, natural agate, crystallite glass and ceramic, etc.
|
Attribute |
Specification |
|
Diameter (Φ mm) |
1.0~250.00 |
|
Thickness (mm) |
≥ 0.1 |
|
Diameter Tolerance (mm) |
± 0.05 |
|
Thickness Tolerance (mm) |
± 0.02 |
|
Clear Aperture |
> 95% |
|
Parallelism |
10 sec. |
|
Surface Quality |
80/50~10/5 |
|
Flatness (per 25mm@633nm) |
1λ ~λ /4@any 25.4mm area |
|
Bevel (face width x 45° ) |
< 0.25mm |
Nanjing Co-Energy Optical Crystal Co., Ltd. is one of the most professional suppliers of optics and optical components in China and our products range from different windows, lenses, prisms, mirrors, filters, beamsplitters, IPL Light guides and filters, tips and rods and so on. Our processing material varies a lot, from different optical glass, fused silica to crystal, i. e, Sapphire, CaF2, BaF2 and Germanium and Silica and more.
Pur products, which are strictly produced according to USA military specification MIL-O-13830A and ISO 10110 with advanced inspection devices, well quality control systems, ensuring our products in good quality and best performance in their own applications.
Most of our products are exported to USA and European companies, which are widely used in laser industry, biotechnology industy, communication and defense. Co-Energy makes every effort to provide high qualified components and devices at lower price. We have developed a series of specialized optical fabrication techniques for polishing in line with the highest international standards.
Co-Energy sales team is a group of energetic young people who have rich experiences of working. Our sincere attitude for quality and service prepared ourselves very well serving for the internation markets.
