Polycarbonate Transparent Roller Shutter Door

Name: Polycarbonate Transparent Roller Shutter Door
Brand: china-crystals.com
SKU: 713465625
Availability: InStock
Rating: 4.6 (123 reviews)

Price:	US $ 899-999/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Product Specifications

Prod Model:	ST-transparent door
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Opening Pattern:	Vertical
Colour:	Transparent
Connecting Pipe:	Aluminum Alloy
Frame:	Aluminum Alloy
Frame Thickness:	1.5mm
Impact Strength:	1400j/2
Tansparency:	85~90%
Open Command:	Remote Control & Manual
Size:	to Your Requirement
Material:	Glass
Type:	Rolling
Position:	Commercial
Surface Finishing:	Finished

Product Description

Polycarbonate transparent roller shutter door

Features:

--Almost transparent - display can be seen when shop is closed

--High security - near steel strength

--Virtually indestructible - Fabricated from extruded aluminum, robust weather and rust proof with polycarbonate glazing making the shutter almost indestructible.

--Ideal for shopping malls and high profile shops

--Custom made - to fit every opening perfectly

--Electrically operated for fast easy roll up and roll down operation.

Curtain specification:

-- import high viscosity polycaronate meterial

-- Impact strength:1400J/m2

-- Elongation at break:250%

--Transparency:88%

-- Bending strength:78 Mpa

-- Rockwell hardness(HRR):60

Motor data:

--Rated voltage220VAC

--Power: 180W

--Rated current:1.5A

--Rotated speed4.8r/min

--Max lifting height:6m

Characteristic	Unit	Typical value(rolling shutter pads)
Impact strength	J/m*m	1400
Luminous transmittance	%	88
Specific weight	g/cm3	1.2
Resistance to heat	°C	-40~120
Heat transfer coefficient	W/m2 °C	2.3 ~ 3.9
Anti-pull strength	N/mm2	>60
Crooked strength	N/mm2	100
Temperature of deflection under load	°C	140
Soundproofing effect	10mm	Weaken 20db

Located in panyu district, Guangzhou City, Guangodong province. Established in 2004, with registered capital Guangzhou Shuotian industrial door Co., Ltd, Specialized in designing and manufacturing different kind of auto roller industrial doors, Roller Shutters, Swing doors etc.

We are professional company in south of chain engaged in high speed doors's producing, marketing and installation. In recently years the continuous efforts and accumulated experience made the company won a good reputation. With its superior technology, high quality and the honesty of price, The company been estabilished with many famous enterprise with long term cooperation. And our doors been export to over 30 Countries in past 7 years.

The high speed doors are speedy, safety, durable and economic They can totally meet the strict require from different industrial condition, Such as electronics, pharmacy, food industry, Chemistry industry, logistics etc, and widely used with those application.
