Product Specifications
| Prod Model: |
CX-IPH |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
ISO,CE,SGS |
| Experience: |
More 20 Years |
| Max Temp: |
130c |
| Quality: |
World Class |
Product Description
PH Meter(PH controller, PH analyzer)
Brief introduction of CX-IPH-1205 Industrial pH meter1.The clear display, simple operation and high measuring performance provide it with high cost performance.
2.It can be widely used for continuous monitoring of PH of water and solution in thermal power plants, chemical fertilizer, metallurgy, environmental protection, pharmacy, biochemical engineering, foodstuff, running water and many other industries.
| CX-IPH-1205 Industrial pH meter |
| Measuring range | 0~14.00PH, -l999~+1999mV, 0~99.9ºC |
| Resolution | 0.01PH, 0.1mV, 0.1ºC |
| Accuracy | ±0.05pH, ±l mV, ±0.3ºC |
| Display mode | LED (nixie tube) display, high brightness, eye-catching and highly readable, long viewing distance |
| Temperature compensation | automatic: 0 - 99.9 ºC, manual: 0 - 99.9 ºC |
| Input impedance | >1012Ω |
| Protection grade | IP65 |
| Isolated current output | 4~20 mA(load <750 Ω) |
| Alarm relay | AC220V, 3A, isolated output of alarming signals |
| Communication interface | RS485 or 232(optional) |
| Power supply | AC220V, 50Hz ±1Hz, DC24V |
| Working conditions | ambient temperature: 0-60ºC; relative humidity ≤90% |
| Power-down memory | > 10 years |
| Weight and dimension | 96 x 96 x 110 mm; dimension of the hole: 92 x 92mm ,0.8kg |
| Installation mode of secondary meter | Drilling type |
| Installation mode of electrode | Flow-through/immerged/flanged/pipe-based |
Brief introduction of CX-ORP-0209 ORP pH meterCX-ORP-0209 series microcomputer industrial control instrumentation is used to test the solution ORP value of precision instruments, and its full-featured and stable performance. Simple operation, making industrial enterprises in the field of test and control pH ideal instrument.
LCD (liquid crystal) display, using high-performance CPU chip, high-precision AD conversion technology and SMT technology, to complete multi-parameter measurement, temperature compensation, range conversion, instrumentation, high precision, good repeatability.
Current output and alarm relay coupled with optical isolation technology, anti-jamming performance, to achieve remote.Isolated output alarm signal, alarm upper and lower limits can be set arbitrarily, alarm hysteresis revoked.
CX-ORP-0209 series instruments can be equipped with various types of ORP electrode.
| CX-IPH/ORP-0209 Industrial ORP Meter |
| Measuring range | -1999 ~ +1999 mV |
| Resolution | 1mV |
| Accuracy | 1mV, ± 0.03 C |
| Stability | 3mV/24h |
| ORP standard solution | 6.86 4.01 |
| control range | -1000 ~ +1000 mV |
| Automatic Temperature Compensation | 0 ~ 100 C (pH) |
| Manual Temperature Compensation | 0 ~ 80 C (pH) |
| Signal output | 4 ~ 20 mA output isolation protection |
| Communication Interface | RS485 optional |
| Control Interface | ON / OFF relay output contacts |
| relay hysteresis | freely adjustable |
| Current output load | maximum allowable load is 750 |
| Signal Input impedance | ≥ 1 × 1012Ω |
| Insulation resistance | ≥ 20M |
| Signal Input impedance | ≥ 3 × 1011 |
| Operating voltage | 220V 22V, 50Hz 0.5Hz |
