Pellet Making Machine Granulator Pelletizer
| Price: |
US $ 30000-150000/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal |
Product Specifications
| Prod Model: |
ACET pelletizing line |
| Capacity: |
60-1100kg/H |
| Screw Diameter: |
35-95mm |
| Control System: |
PLC Screen |
| Delievery Time: |
45 Working Days |
| Screw: |
Double-Screw |
| Automation: |
Automatic |
| Computerized: |
Computerized |
| Certification: |
UL |
| Raw Material: |
PE/PP/Pet |
Product Description
Parallel Twin Screw Pelletizing
Product Description:
ACET series parallel twin screw extruder pelletizing line is a kind of high-efficiency mixing, melting, extruding equipment, which is especially adopted into pelletizing. ACET pelletizing line combines crushing, compressing, plasticization and pelletizing.
Usage of Parallel Twin Screw Extruder:
1. Masterbatch:
PE/PP/ABS/EVA+Pigment+additives
2. Filling and modification:
PE/PP/EVA+Calcium carbinate/ Titanium white powder
3. Blending and modification:
PE/PP/PS/PA+EPDM
4. Glass fiber (carbon fiber) reinforcement:
PP/PBT/ABS/PA66/PC/POM/PPS/PET+Glass fiber( carbon fiber)
Main Downstream Machine for Strand Pelletizing:
| No. | Machine List | Function |
| 1 | Screw Loader | Waste film feeding |
| 2 | Co-Rotation Extruder | compressing, plasticization |
| 3 | Hydraulic Screen Changer & Extrusion Mould | Dirt filtering |
| 4 | Water Cooling Tank | Cooling the strand |
| 5 | Strong-Air Dryer | Strand drying |
| 6 | Pelletizer | Strand pelletizing |
| 7 | Vibrator | pellets size screening |
| 8 | Packing System (Blower & Silo) | Granule packing |
Main Downstream Machine for Water Ring Pelletizing:| No. | Machine List | Function |
| 1 | Screw Loader | Feed Flakes |
| 2 | Co-Rotation Extruder | Compressing, plasticization |
| 3 | Hydraulic Screen Changer | Dirt filtering |
| 4 | Water-Ring Pelletizer | Pelletizing, Granulation |
| 5 | Water Bath & Water Container | Granules cooling & water circulation |
| 6 | Centrifugal Dryer | Pellet dewatering |
| 7 | Vibrator | Pellets size screening |
| 8 | Packing System (Blower & Silo) | Granule packing |
Technical Data for Granulating Machine:| Model | Dia of Screw(mm) | L/D Ratio | Motor Power(KW) | Capacity(kg/h) |
| ACET35 | 35 | 40 | 18.5-22 | 60-90 |
| ACET50 | 50 | 40 | 45-55 | 120-180 |
| ACET65 | 65 | 40 | 90-110 | 250-350 |
| ACET75 | 75 | 40 | 132-160 | 400-550 |
| ACET95 | 95 | 40 | 280-315 | 800-1100 |
About Jiangsu Active Technology Machinery:
JiangSu Active Technology Machinery Co.,Ltd is a company, which is specialized in pelletizing line. There are two pelletizing line, single screw pelletizing line and Co-rotation parallel twin screw extruder pellitizing line. ACTIVE has top-ranking Research and Development technology system and rich experienced technician team.
Our vision is to offer you the best and the most appropriate pelletizing line, to offer you the most reliable technically and commercial service support.
Guides before Quotation:
1. What is your formulation for this pelletizing?
2. What is the capacity you want?
3. What is the usage of your final product?
Pre-Sale and After-Sale Service:
1. Provide all the machines for the complete production according to customer's requirements.
2. Provide complete service for factory layout and other information to help customer to build the factory.
3. Provide the raw material to the customer if need.
4. Provide good service for machine installation and training, until the customers can run the machines and make stable production.
5. Provide after-sell service for all the life, except one year quality guarantee.
6. Provide good quality, good price and good service to customer for long-term cooperation. We are the professional and trustable supplier for turnkey projects. Let us do win-win business together.
JiangSu Active Technology Machinery Co., Ltd is a leading supplier of plastic extrusion and recycling equipment.
We have provided a wide range of products like Extrusion and services to our customers from more than 80 countries and regions. We are constantly keep on improving our products together by the science, technology and "Human Element". Our vision is to be a top plastic equipment supplier in the world, base on the spirit of this principle, we are not only made our best to meet the market demand, as well also continue to strengthen our competitiveness. Through seamlessly customer contacts, with years of experience in technology, R & D capabilities, manufacturing process and mold technology to meet the various needs of customers. We are proud that through the cooperation of customers, our products keep innovation on paced at the speed of various demands.
Our pursuit of professional products has a plentiful of industry experience to serve customers for the purpose, in the design and manufacture of products has reflects the suitability of customer and market demand.
WIN-WIN Business, let's shake hands!
