Product Specifications
| Prod Model: |
MY-V030 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Clamping Force: |
0.50~0.78 Mega Pascal |
| Grinding Diameter: |
O18-O75(Mm) |
| Operation Noise: |
<=60dB |
| Maximum Operation Linear Velocity Of Gri: |
15m/S |
| Rated Voltage: |
220V/50Hz~110V/60Hz |
| Electric Power: |
350W |
| Ambient Operation Temperature: |
5°c~40°c |
| Humidity: |
20~80%Rh |
| Appearance Size: |
710×430×615(Mm) |
| Main Motor Power: |
250W |
Product Description
SPECIAL FEATURES:1. Body is characteristics
2. Screening and grinding is finished together once without need for platen.
3. It has double functions with platen and without platen.
4. It has large size of liquid crystal screen for English and Chiese display, easy to operate
5. Parameter such as pupil is distance, height, axial position and etc. Are amendable with unnecessary to locate center manually.
6. The minimum diameter of lens blank can be displayed.
7. Any functions of platen machine are kept.
8. Grinding time for one lens 3 minutes.
9. Operation life of main grinding wheel 3 10000 lenses(Hardness below 5level).
10. Build-in counter and display function.
11. Characteristics of system and main part
12. Automatic tracked grinding system is adopted to insure the best pressure angle, axial force and radial force.
13. Diamond wheel at international level is made of imported materials and new 5+1 process.
14. Digital smart computer is adopted for controlling geometrical size of lens and amending its geometrical shape.
15. Parameters such as sharp side type, grinding force and speed, clamping force and etc are adjustable freely for insuring lens quality.
16. Potential technical space for improving performance and expanding function is reserved is order to add special funtions
SpecificationClamping force: 0.50~0.78 mega pascal
Grinding diameter: Φ 18~Φ 75(mm)
Fineness of ground side: BVIIgrade(The highest domestically)
Shaping degree of ground side: Face 96%; Appearance99%(amendable freely)
Operation noise: 60dB
Maximum operation linear velocity of grinding wheel: 15m/s
Diameter arrangement of grinding wheel: Φ 100mm~Φ 125mm
Width of grinding wheel group: 60mm~100mm
Grinding wheels for PC: Φ 101mm× 16mm
Grinding wheels for glass: Φ 101mm× 15mm
Grinding wheels for V-molding and re-beveling: Φ 101mm× 21mm
Grinding wheels for polishing: Φ 101mm× 11mm
Rated voltage: 220V/50Hz~110V/60Hz
Main motor power: 250W
Electric power: 350W
Ambient operation temperature: 5° C~40° C
Humidity: 20~80%RH
Appearance size: 710× 430× 615(mm)
