Product Specifications
| Prod Model: |
MIFARE 1K smart card |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Materials: |
PVC, Pet, ABS, Paper etc |
| Protocol: |
ISO14443, ISO15693 etc |
| Chip Types: |
MIFARE Classic 1K, MIFARE Classic 4K |
| Working Frequency: |
125kHz, 13.56MHz, UHF |
| Options: |
Logo Printing, Numbering, Encoding etc |
| Color: |
Red, Bule, Yellow, etc |
| Craft: |
Logo, Photo, Name etc |
| Delivery Time: |
7 Days |
| Card Surface: |
Frosted, Matte, Finish |
| MOQ: |
300PCS |
| Function: |
Information |
| Material: |
PVC |
| Frequency: |
High Frequency |
| Type: |
MIFARE 1K smart card |
| Application Field: |
Hotel Locks, Payments, Transportations etc |
Product Description
MIFARE Classic®1K smart card with 1 Kbytes EEPROM read/write memory and is compatible with existing MIFARE® infrastructures. Operating in accordance with ISO 14443A, MIFARE® 1K functions at a distance of up to 10 cm with true anti-collision properties and without the need for a battery.
Smart card MIFARE Classic®1K is a great solution for access control, identification, Payments,
Transportations, NFC etc.
We supply blank MIFARE Classic®1K smart card and pre-printed card.
Description :
- IC manufacturer: NXP founded by Philips
- Wafer die: MF 1 IC S50
- Unique serial number (4 Byte and 7 Byte)
- Function: Read/Write protect by password
- Memory: 1K-Byte EEPROM(16 sectors)
- Frequency: 13.56MHz
- RF protocol: ISO 14443A
MIFARE Classic®1K Card Key Features:
- Card dimensions: 86 x 54mm
- Thickness: 0.84mm
- Material: PVC, PET
- Surface: lamination (gloss/mate)
- Chip: MIFARE Classic® 1K (NXP original)
- Frequency: 13.56MHz
- RF Protocol: ISO 14443A
- Data storage time: minimum 10 years
- Operating temperature: -20 to +60°C
- Stockage temperature: -20 to +65°C
- Package: 200pcs per Inner Box; 5000pcs per Carton, each Carton gross weight is 35kgs
Applications:
- Access control
- Membership Loyalty System
- Time attendance
- Hotel locks
- Payments
- Transportations
- NFC
Optional produce:
Printing:
- Logo/Graphics/Photo
- Serial Number
- DOD Number
- Barcode printing
- Overlay Foil
- Signature Panel
- Name Personalisation
- Photo Personalisation
Magstripe:
- LoCo300
- HiCo2750
- Magstripe Encoding
Various:
- Hologram
- Security Printing
- Chip Encoing
Chip available:
-MIFARE Classic®, MIFARE Utralight®, MIFARE® DESFire® 2K/4K/8K, MIFARE Plus® etc
13.56MHz MIFARE® 1k Printing PVC RFID Card
Material | PVC,PC,ABS,PET |
| Size | Stander size(credit card size):85.5*54mm or customized |
| MOQ | 500 or negotiable |
| Printing | CMYK or panton colour,offset printing/silk printing |
| Surface finishing | Glossy/matte/frosted/transparent |
| Numbering | Embossed/engraved/flat/laser printing/jet dot number |
| Craft | Scratch panel/Signature panl Magnetic strip (hi-co/loco),
encoded as requested
Gold/Silver/Laser stamping hot stamping
Printing serial number, Logo printing invisible UV printing
Barcode and QR codes, variable codes available |
| Production time | 7-8 working days ( It depends on exact quantity. ) |
| Payment terms | Western Union, T/T, paypal |
| Delivery | by express by sea or by air |
| Packing | 200pcs/box, 25boxes/carton |
| Box size: 22.5*9.3*6cm |
| Carton size: 47*23.5*30cm |
| Weight: 5000pcs 35KG |
| Application | Hotel,Bank, School, Goverment, Enterprise, hospital,supermarkets , Cinema,Games,Gift, home appliance, Leisure, Food and Beverage and other places |
|
|
|
