Laser Engraving Machine for Glass; 2D and 3D Patterns Inside Engraving

Product Specifications

Prod Model:	HSGP-3015
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Laser System:	Diode Pump Laser 532nm
Point Distance:	0.07-0.02nm
Max. Speed:	4, 500dots/S
Total Power:	1800W
Processing Surface:	1500mm*3000mm*110mm(X*Y*Z)
Power Supply:	AC100-240V, 5A
Material:	Crystal; Glass etc.

Product Description

Introduction

HSGP Series is a series of large size laser engraving machines which were designed by Holy Laser according to the state environmental protection policy used for the cold working process of glass or crystal products. In the past the pickling and corrosion process of glasses will do badly harm to the environment. But now in contrast the laser engraving technology will do no harm to the environment and the engraved products will also be more vivid. Both 3D and 2D patterns are able to be engraved in glasses and crystals by the laser engraving technology; it will surely bring us a revolution of the glass further processing industry. The HSGP series do have a lot of different sizes that can fit our customers' personalized requirements.

Features

Widely application;available for  large size of glass manufacturing with a  high speed; depth relief is also available. Both 3D and 2D patterns can be engraved in a extremely high detail.

Environmental friendly: during the engraving there will be no pollution; no dust; no poisoned gas; no use of water and no need of chemical dyestuff

Power saving: among all the large size manufacturing equipments, the laser engraving machine may cost the least energy. About 2KW per hour

Long using life: there will be no contact between the products and the engraving equipment. It helps the equipment got a long using life.

Continent operation: with the help of the air float device, glasses can be easily moved without scratching of the surface.

Easy to operate: it can help saving the labor cost. According to the different sizes of products, only one or two people can operate more than 5 equipments.


HSGP-3015
Laser system	Diode pump laser 532nm	Operating temperature	15ºC-30ºC
Diode lifetime	About 25,000h	Operating humidity	Less than 85%; no dewing
Point distance	0.07-0.02nm	Operating environment	Clear; no corrosive gas
Dia. of Dots	40-80μm	Operating system	Windows XP; Win7 32 bit
Max. speed	4,500dots/s	Power supply	AC100-240V, 5A
Resolution	1,500dpi	power supply instability	<10%
Batch processing	Yes	Power frequency	50/60HZ
Positioning accuracy of X,Y,Z axis and the screw	0.02mm/300mm	Ground wire	National standard of machine room
Repeated location accuracy of X,Y and Z axis	<3μm,300mm	Material	Crystal; glass etc.
Total power	1800W	Controlling system	Galvanometer + axis X,Y and Z
Processing surface	1500mm*3000mm*110mm	Moving controller software	Holylaser3DHolylaser Holylaser engraving controller software. Holylaser modelization and dotization software
Cooling system	Air cooling	Software	Holylaser engraving software Holylaser dotization software

Aplication:
Focus on the business of adviertising, building partition decoration, household appliance, pictorial art viewing, industrial glass processing design, etc.

After-sale service:
1.One year guarantee period for product quality. (man made damaged is negotiable).
2.Lifelong maintenance and spare parts supply.
3.Free design of fixtures as customers required.
4.Overing training for machines' installation and operation.
5.Free engraving examples are provided for our customers.
Large size docoration glass 3d laser engraving machine (HSGP-L)

Description:
Our large size decoration glass laser engraving machine is suitable for glass, crystal subsurface engraving in large size, refined engraving images And letter;
Suitable for 3D laser glass and 3D laser crystal mass production decoration,
Household appliances and art viewing, industrial glass design.
Welcome for large engraving area customized.


Products Characteristic:
1. High accuracy, during 5mm to 80mm.
High flatness, less than 0.3mm
2. Strong software: Can make dots as much as a billion.
No gap bettwen every layer.
3. Humanization design, very convenient to use: Fifty PCS universal wheels, air cylinder to control the work table to make the glass easy to move.

Max Series:
Suitable for glass, crystal subsurface engraving in large size;
Larger engraving size can be customized;
Refined engraving images and text;
Suitable for 2D laser glass & 2D laser crystal mass production.
Focus on the business of household fitting, advertising, building partition decoration, household appliances and art viewing, industrial glass design, etc.

Aplication:
Focus on the business of adviertising, building partition decoration, household appliance, pictorial art viewing, industrial glass processing design, etc.


After-sale service:
One year guarantee period for product quality. (man made damaged is negotiable).
Lifelong maintenance and spare parts supply.
Free design of fixtures as customers required.
Free training for machines installation and operation of the staffs.
Free samples marking of customer provided.

Laser machine Parameter:

Item	HSGP-L
Engraving area	1300*1500*80mm	1830*2500*80mm
Engraving speed	260000-300000 dots/min.
Dia. for dots	40-80μm
Mass production	large working area can be customized
Laser medium	Laser diode
Laser wave length	532nm
Cooling	Air cooling
Working temperature	15-30°C
Power supply	220V or 110 V (+/- 10%)
application	Suitable for advertising, building partition  decoration, household appliances, pictorial  art viewing, industrial glass processing  design, etc.
