Product Specifications
| Prod Model: |
RJ1290 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
Small Power |
| Drive Type: |
AC Servo Drive |
| Engraving Machine Type: |
Laser Engraving Machine |
| Control: |
CNC |
| Current: |
AC |
| Laser Type: |
CO2 |
| Usage: |
Plastic |
| Certification: |
SGS, CE, ISO 9001 |
Product Description
laser cutter cutting machine for acrylic fabric MDF(RJ1290)
Applicable Materials:
The non-metal materials like double-color board, organic glass,crystal, wood, paper, leather and rubber etc.
The industries like advertising logo-making, crafts& gifts, crystal, relief sculpture, leather &cloth, embroidery and decoration.
wood, bamboo, jade, marble, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic,
glass and other nonmetal materials.
Applicable industries:
advertisement, arts and crafts, leather, toys, garments, model, building upholstery, computerized
embroidery and clipping, packaging and paper industry.
Feature:
Carbon dioxide laser as an energy source, combined with electronic, mechanical, computer technology
developed. Laser head and the workpiece does not contact, do not scratch the surface, the kerf, high
precision, is the ideal choice for a variety of processing industries.
| NO. | Model | RJ1390 |
| 1 | Laser medium | CO2 |
| 2 | Working area | 1300*900mm |
| 3 | Working table | blade table |
| 4 | Laser power | 120W |
| 5 |
Power Supply |
220V/50Hz, 110V/12Hz |
6 | Min line width | ≤0.15mm |
| 7 | Positon accuracy | 0.01mm |
| 8 | Laser output control | 0-100% set by software |
| 9 | Min. engraving size | Chinese: 2.0mm*2.0mm, English letter: 1.0mm*1.0mm |
| 10 | Repetition accuracy | 0.01mm |
| 11 | Cutting speed | 0-40000mm/min |
| 12 | Engraving speed | 0-60000mm/min |
| 13 | Highest scanning precision | 4000DPI |
| 14 | Guide rail | Hiwin from Taiwan |
| 15 | Transmission method | Belt Transmission |
| 16 | Drive system | Leadshine driving system and stepper motor |
| 17 | Cooling system | Water-cooling |
| 14 | Control system | DSP off-line |
| 18 | Control software | Coreldraw, Photoshop, AutoCAD, Tajima |
| 19 |
Graphic format support |
PNG,JPG,DXF,PLT,AI,TIFF, BMP, SVG,ect |
| 20 |
Working environment |
0-45ºC |
21 |
Operating Humidity |
5-95% |
Optional parts :
various laser power
up-down table
red point
auto focus
rotary device
FAQ:
Q. Can the machine engraving and cutting?
A. Yes, even on the same Job, you can do setting with different colour in the software and also can making holes.
Q. is the machine must work with computer?
A. Must connect with computer with USB cable when you change the settings of machine. for the design files,
you can transfer the file with USB memory stick to the machine, Or can download it to the machine directly
with USB cable from computer.
Q. Can the machine be split so it can fit into my doors?
A. no, it can't.But when your order,you can tell us your door width,We will custom make the machine
according to your condition.
Q. How long the laser tube is working well?
A. It is about 10000 hours,but it is also depend on your work and maintain.
Q. Do you avaliable spare parts?
A. we can provide all of spare parts of any model we listing.
Q. I have heard the mirrors need cleaning?
A. Yes they do but not after every job, once a week is normally enough
Q. Can I put larger materials in the machine?
A. Yes, the machine has doors which can be opened to accommodate larger materials
Q. How about the after sell service?
A. 12 Months for the whole machine Free tech support for the whole life of the machine, and 24 hours telephone support. Camera of MSN support by MSN or skype online when you need.
Warranty :
1).Life time free maintenance service.
2).One year free warranty
3).Free training course at our factory with professional engineers.
4).We provide the consumable parts at agent price when you need replacement
5).24 hours online service each day, free technical support with different languages.
6).We provide door to door technical support to agents, if necessary.
Jinan Ruijie Mechanical Equipment Co., Ltd. Was established in 2002. We are well known for our superior quality and service in the field of engineering and manufacturing of CNC and Laser Equipment that includes: CNC Router, Laser Engraving and Cutting Machine, Laser Cutting Machine, Laser Engraving Machine, Cutting Plotter, Plasma Metal Cutting Machine, Woodworking CNC Router, Marble CNC Router and so on.
Jinan Ruijie Mechanical Equipment Co., Ltd. Imports the high quality manufacture technology to improve our products for our customers.
Our company is famous for high quality and better after-sale service as the competitive price.
Our products are widely used in the following industry, such as Woodworking, Advertising, Artmaking, Model, Electric, CAD/CAM Industry Model, Clothing, Package Printing, Marking, Laser Sealing and so on.
Our company has set up more than 20 sale and service departments around China which can offer our customers the service of design, fixing, training, maintenance and so on. As the sale in China, our products exports around the world including Southeast, Middle East, Africa, European and U. S. A.
Our company managing idea is improving the high quality products for customers.
We are searching the distributors around the world. Hope we can cooperate for the world market.
