Product Specifications
| Prod Model: |
Irregular Shape clear tempered Glass |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Standard Size: |
2134X3300mm; 1830X2440mm; 2134X3660mm; etc |
| Type: |
Tempered |
| Technique: |
Tempered Glass |
| Thickness: |
3-22mm |
| Shape: |
Flat |
| Usage: |
Daily Products |
Product Description
Irregular shape glass/tempered glass/toughened glass/strengthened glass are made by forming compressive stress on the surface of the glass and heating the glass up to its intenerating temperature and then make the glass uniform cooling quickly. During the process of cooling, the exterior part of the glass is solidified because of the rapid cooling, while the interior part of the glass shrinks because of slow cooling, then forming compressive stress on the surface of the glass and tensile stress inside the glass, thus improving the intensity and heat stability of the glass.
Safety performance: Irregular shape glass/tempered glass/toughened glass will appearance hurtles obtuse angles when breakage.
Strength performance: Four times more than ordinary glass.
Heat stability performance: Three times more than ordinary glass, could bear the temperature change about 200° C.
Standard: EN 12150; ASTM 1048; BS 6206: 1918; GB 15763.2-2005; AS/NZS 208: 1996
Heat strengthened glass adopt the similar process, but the cooling course is longer than tempered glass. So the compressive stress is not so big like tempered glass and the flatness is more perfect.
Safety performance: Not easy to breakage, and could remain in frame when breakage.
Strength performance: Twice than ordinary glass
Heat stability performance: Could resist heat effectively, and avoid heat breakage
Standard: EN1863-1; ASTMC 1048-976
Curved tempered glass adopt the similar process with tempered glass, but before the cooling process, using the external power bent the glass to a proper radian according the requirement, its wind pressure resistance is better than flat tempered glass and other kinds glass for the special shape. Curved tempered glass/bended glass/bent glass widely use in esthetics architecture field for the beautiful appearance.
Safety performance: Glass will appearance hurtles obtuse angles when breakage.
Strength performance: Four times more than ordinary glass.
Heat stability: Three times more than ordinary glass, could bear the temperature change about 200 ° C.
Applications:
Irregular shape glass can be used in the constructions, automobile, train, ship, furniture, automatic door, escalator, microwave oven, refrigerator, etc. And irregular shape glass is made by heating annealed glass in a furnace to 690 degree. Progressing from the annealing furnace, then the glass cooled quickly with jets of cold air, inducing compressive stress to the surface while the center remains tensile.
Irregular shape glass is extensively used in shower door glass, fencing glass, revolving door glass, high quality furniture glass and architectural situations.
Specifications:
Max. Size: 2600mm*2440mm
Min. Size: 300mm*300mm
Min. Radius: 450mm
Thickness Range: 4mm-25mm
Competitive Advantage:
Irregular shape glass/ Tempered glass/Toughened glass has a very good performance of anti-curve, anti-impact intensity, 3 to 6 times better than normal glass. Irregular shape glass/Tempered glass/Toughened glass can afford pressure over 95MPa on the surface. Irregular shape glass/Tempered glass/Toughened glass has high stability even under temperature change of 200-300 centi-degrees, while normal glass can only afford change of 70-100 centi-degrees. Irregular shape glass/Tempered glass/Toughened glass becomes small sand shape if tempered glass is broken under big force, which guarantees safety and less loss.
Our irregular shape glass is most famous in glass industry of China. We process irregular shape glass at high accuracy with good quality. Irregular shape glass can be further processed into insulated glass, tempered and laminated glass, etc.
Beijing Northglass Technologies Co. Ltd, a leader in glass industry, has been engaged in the research, development, processing glass since 1987. Produce range includes: Laminated safety glass, tempered safety glass, low e insulated glass, reflective glass, silk screen printed glass(ceramic frit glass, enamalled glass), tempered glass, curved tempered glass, hot curved glass, heat strenghened glass, fire proof glass, bullet proof glass, ultra clear glass(low iron glass), etc for curtain wall shower doors, windows, facades and furniture applications.
By far, we have asset USD50 million. Our head quarter is in HongKong, and our 3 fabrication companies are in China mainland having more than 1, 000 employees, of whom over 46% is specialized techical personel. Our company covers more than 390.000sqm. We have massive elites working at each process of working, among whom, professional technicians are over 26% and employees with Bachelor's degree are over 93%.
Our glass pass Australian CSI certificates, US IGCC SGCC certificates, European CE certificates and Chinese national certificates. Now we are working with customers in over 100 countries. To help customer to better achieve their success is our aim. Welcome you work with us, and establish long term cooperation!
