Product Specifications
| Prod Model: |
FL-168 |
| Lamp: |
Halogen 6V/10W |
| Display: |
7TFT LCD |
| Photometric Range: |
0.000-3.000 ABS |
| Cuvette: |
Crystal Flow Cell with Volume 32UL |
| Storage: |
Port for SD Card, Great Capacity Available Through |
| Type: |
Urine/Hematology Analyzer |
| Certification: |
CE |
| Classification: |
Biochemistry Analyzer |
| Group: |
Human |
Product Description
Professional design assures your convenient operation and accurate measurement.
Friendly man-machine conversation interface based on built-in Windows CE. NET
Touch screen, external keyboard and mouse supported
Multi-language version such as Chinese, English, Russian, Spanish etc.
Built-in thermal printer and external printer based on USB interface, supporting on-line printing, multiform reports.
Measure methods include End-point, Two point, kinetic, reagent blank sample blank, immunity nephelometery, and multiplicate selectable calibration methods, such as multi-standards, linear or non-linear calibration curves etc)
Perfect QC function including multifold QC graph, QC parameters calculation, dual-level QC and out of control alarm.
Power-on self-test and malfunction alarm
Real-time display absorbance curve.
Prolonged light source and filter useful-life by intelligent light source protection
Communicate with PC by RS232 or Ethernet, supporting remote software upgrade
Product Description
7" LCD display
Touch Screen
Colorized windows interface.
Double-channels test, you can also use single-use cuvette available to eliminate
crossed pollution.
Advanced optics test system, built in 8 filters (340, 405, 505, 546, 578, 620, 670
and one optional filter available)
| Resolution | 0.001Abs |
| Photometric range | 0.000-3.000 Abs |
| Lamp | Halogen 6V/10W |
Optics system
| 340-670nm, 7 filters built-in: 340,405,505,546,578,620,670 nm, precision for 340 nm ±2 nm,
width of half-wave 10nm; precision for other wavelength ±1 nm,
width of half-wave 8nm;
User can add a wavelength according to needs.
|
| Stability of absorbency | Changes less than 0.005 Abs within 1 hour |
| Temperature control | Room temperature, 25ºC, 30ºC, 37ºC±0.1ºC
|
| Cuvette | Crystal flow cell with volume 32μL |
| Repeatability | CV≤0.5% |
| Cross pollution | ≤1% |
| Linear of absorbency | r≥0.999 |
| Storage | Port for SD card, great capacity available through SD card |
| Ports | Port for RS232, Ethernet and SD card, 4 USB ports |
| Display screen | 7TFT LCD display |
| Printer | Built in Thermal printer, and supports laser printer and ink-paint printer available based on PCL print language and USB port.
|
| CPU | High speed embedded processor |
| Weight | 7 kg |
| Power supply | AC100~240V,50/60 Hz |
| Dimension | 420mm(W)×310mm(D)×152mm(H) |
| Power input | 110VA |
| Working environments | Temperature:10ºC - 30ºC; relative humidity:≤70%;
atmosphere pressure:86KPa -106KPa
|
Temperature for storage
and transportation | -20ºC - 55ºC |
