Product Specifications
| Prod Model: |
HSGP-2KD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engraving Machine Type: |
Laser Engraving Machine |
| Control: |
Automatic |
| Current: |
AC |
| Laser Type: |
Diode |
| Brand Name: |
Holy Laser |
| Max.Marking Scope: |
150X200X80mm |
| Factory: |
Yiwu |
| Maximum Engrave Speed: |
120.000dots/Min |
| Machine Weight: |
50kg |
| Focus Diameter/Resolution: |
0.02nm/800dpi |
Product Description
Introduction about our laser engraving machine HSGP-2KD:
This economic crystal engraving machine, is a high resolution laser engraving machine, is really a fine processing machine with advantages of high frequency and strong stability, which is definitely suitable for fine model engraving processing centers, and suitable for glass/crystal engraving gift shops, craft shops, photo printing shops, wedding photography, souvenirs, personalized gifts shops, etc.
Specifications for 3D Laser Engraving Machine (HSGP-2KD):
1. Max. Working area: 150*200*80mm, suitable for qyt produce and also suitable for more large size crystal and glass
2. Fast speed: 2KHZ(120000dots/min), for one cube size: 50*50*80mm, only need 2 minutes. For one keychain, only need 7 sec.
3. Maintainence free. (no need headache for change sapre parts or adjust machine)
4. CE, FCC, FDA, SGS, TUV certification proved. Don't worried about quality.
5, Graphic Format Supported: AI, PLT, DXF, BMP, DST, DWG, LAS, DXP, jpg, etc.
After-sale service:
1. One year guarantee period for product quality. (man made damaged is negotiable).
2. Lifetime maintenance and spare parts supply.
3. Free design of fixtures as customers required.
4. Free training for machines installation and operation of the staffs.
Factory Profile:
1. Supported by the Yiwu City government
2. Cooperate with the Zhejiang University, update for technology
3. We are the manufacturer, our price are more competitive.
4. With 14 years history on reseaching and producing all kind of laser machine
5. Our company welcomes AGENTS all over the world
Type |
HSGP-2KCD |
laser / laser wavelength |
semiconductor diode/ 532nm |
laser repetition frequency |
2000hz |
marking speed |
120,000dots/min. |
max. marking scope |
150*200*80mm |
focus diameter/resolution |
0.02nm/ 800DPI |
working |
with high speed scanner+X+Y+Z (5 axis) |
positioning accuracy |
10μm |
continuous working time |
24 hours |
coolinf/quality warranty |
air cooling |
lifetime |
>25,000hours |
gross power/noise |
1.5W/ 50db |
power requirement |
single phase 220V or 110 V (+/- 10%),
50Hz or 60 Hz |
software |
self reseach software for 3D, 2Ddots cloud,
and for control machine |
suitable materials |
Crystal , glass, hard plastic, acrylic, metal, etc. |
working environment |
temperature15-30°C |
Zhejiang Holy Laser Technoloy Co., Ltd, is a factory Located in YiWu City, ZheJiang Province. We specialize in: 3D laser machine, Large size glass engraving machine, Laser marking machine, Laser cutting machine, etc.
We are here because we are qualified for serving you by the bellow advantages:
1, We can supply machine in 7-10days once you confrim the order.
2, We supply complete service: Machine, design, crystal and LED base factory info. Design for free, technology support for all liftime, training for free.
3, We have our own factory garden that more than 1600squre meter. Wihch suport by government in yiwu economic development zone.
4, All our productions with CE, FCC, FDA, SGS, TUV certification s. Cause suitable for all city in the world.
5, We also have our son desiner team which have more than 15 years experience. Can supply you 2D or 3D desing with your special photo or supply beautiful design in tock.
You are always welcome to visit our factory in any time, , you are here not just our customer, most important is we are friends.
