Dust Isolation Commercial Roll-up Shutter High Speed Door
| Price: |
US $ 1100-1200/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
Product Specifications
| Prod Model: |
HZ-HSD300 |
| Drive System: |
1.German Sew 2.China Sej / Snma |
| Door Curtain Thickness: |
0.8/1.0/1.2/1.5mm |
| Installation Base: |
Concrete, Panel, Brick, Steel Structure |
| Command System: |
Radar Sensor, Magnetic Loop, Remote Control |
| Safety Device: |
Photocell Sensor(Korea Autonics) |
| Opening Frequency: |
1000-1500times/Day |
| Motor Power: |
0.75kw-2.2K/50-60Hz |
| Quantity Warranty: |
12 Months |
| Perspective Window: |
1.2mm PVC Transparent |
| Open And Close Speed: |
0.6-1.8m/S |
| Type: |
Rolling |
| Open Style: |
Rolling |
| Certification: |
SGS |
| Position: |
Interior |
| Surface Finishing: |
Finished |
| Material: |
Stainless Steel+PVC Fibar |
| Opening Type: |
Automatic |
| Special Function: |
Self Contol |
| Color: |
Yello/Orange/Grey/Blue/Green |
Product Description
High Speed Doors
Product Description
Product Use:
Hongfa Dust Isolation Commercial Roll-up Shutter High Speed Door,fit for clean room,especifically for space-constrained logistics channel design, built-in motors do not take up installation space, meet specific site needs. The door curtain was formed by the lighter fabric and the steel pole (Wind resistant). The Wind resistant pressure is strong( wind resistant pole: It is on the request about door openings' wind pressure to deploy), good looks, run smooth. Vermins-proof and dust-proof, heat preservation, protect the workshop's working environment.
Applications:
>Internal/External with greater wind pressure's door openings
>Heavy, Light industry, in heat preservation, vermins-proof and dust-proof, high demanding environments.
>Material channel, underground parking channel.
Technical parameters:
Internal/External rapid rolling door
1. Appearance: Cold rolled steel with electrostatic spraying door 140 × 150 mm, cold rolled steel electrostatic spraying door cover.
2. Power performance: Germany SEW brake motor, power 0.75- 1.5KW, power supply 220V/380V, brake voltage is 220V.
3. Control system: Imported microcomputer frequency conversion to control of electric box (Mitsubishi CPU).
4. Control voltage: Safe low-voltage 24VDC.
5. Opening speed: Open 0.8-1.5m / s / off 0.6-1.2m / s (frequency conversion can adjust the speed).
6. Door curtain material: Imported high-density polyester fiber and the surface coating processing, thickness 0.8mm- 1.5mm, variety colors can be chose.
7. Tensile strength: 5700/5100N/5cm, tear strength 900/80N.
8. Fire-proofing level: German standard MZD / NBL fire resistant.
9. Usage temperature: -10° C +70° C / super cold resistance region -40 ° C.
10. Transparent window: Import PVC transparent crystal soft plate, thickness 1.5mm, rectangle or oval.
11. Wind resistant material: Wind resistant press steel wind resistant pipe.
12. Wind resistant capability: 15m / s (50PA standard 3 × 3).
13. Sealability: The bottom of the door curtain U-shaped balloon bags can tight fitting with the uneven ground, the seal strip on the both sides of the door can vermins-proof and dust-proof.
14. Security Configuration: Standard infrared opto-electrical protection, pressure balloon, warning lights, anti- collisioncolumn, power failure hand crank.
F A Q1. What's the payment details?Deposit before production, and balance before shipment.2. What's the delivery time?For common order, about 7 days only.3. What about the warranty for the doors?We provide 12 months warranty for all doors and accessories.When the product quality appear.4. Do you provide OEM Service?Yes. OEM & ODM Service is ok for us.5. What's the MOQ?We accept 1 set as sample order.6. How about the package?Plywood case or Cardboard, suitable for sea freight or air freight, as your request.
Shenzhen Hongze Automatic Door Co., Ltd. is a high-tech company that engages in the development of world-class advanced automatic doors. Our main products include quick rolling door, industrial accumulation door, industrial rolling door, PVC rolling door, rapid rolling door, fire-resisting rolling door, industrial lift door, automatic induction door, automatic vertical hinged door, medical automatic door, stainless steel automatic door, electric folding gate, crystal rolling door, electric roller shutter of various materials, and parking lot series.
Our company introduces and absorbs the state-of-the-art technologies of the automatic door industry of the world whilst accumulating rich experience in design, production and engineering installation. The overall appearance, quality, performance and service life of our products are comparable to world-famous brands, whereas our prices are much lower than those of similar imports. All these are aimed at offering our customers excellent, low-priced products in the real sense.
Hongze has been persistently offering users all-round, diversified service of wide level. Meanwhile, we have been elaborately bringing about a rich corporate culture to serve as a faithful, honest and harmonious tie among enterprise, customers and employees.
Adhering to the principle of "proceeding from details and trivial matters", we try to embody our meticulous effort in all the links and shall spare no effort in bringing about the best products and perfect service.
Over the years, we have been guided by the principle and concept of "guarantee by brand, breakthrough by technology, supported by service". In the future, we shall do our utmost to provide our customers with related engineering consultation, scheme design, technical guidance, installation and debugging, after-sales repair and other service.
