| Price: | US $ 12000/Set |
|---|---|
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | JK06RD |
|---|---|
| Name: | Drying Machine for Fruit Vegetable Food / Drying E |
| Items: | Drying Oven |
| Control System: | Touch Screen Operation |
| Dehymidify: | 25.0L/H |
| Heating Capacity: | 21.0kw |
| Cooling Capacity: | 18.0kw |
| Max.Temperature: | 75 Degree |
| Noise: | 75dB(a) |
| Material: | 304 Stainless Steel / Steel |
| Function: | Heating Cooling Dehydration |
| Type: | Dehydrator |
| Voltage: | 380V |
| Customized: | Non-Customized |
| Power: | 8.5kw |
| Single dryer + drying chamber | ||||
| Model | Unit | JK03RD | JK06RD | JK12RD |
| power input | KW | 4.8 | 8.5 | 15.0 |
| power supply | V/PH/HZ | 380V/3PH,50/60HZ | 380V/3PH,50/60HZ | |
| 220V/1PH,50/60HZ | ||||
| Rated current | A | 9.6A(380V),22A(220V) | 17.0 | 30.0 |
| Heating capacity | KW | 10.5 | 21.0 | 42.0 |
| Cooling capacity | KW | 7.8 | 18.0 | 50.0 |
| Dehumidify | L/H | 12.0 | 25.0 | 50.0 |
| Max. temperature | ºC | ≤75 | ≤75 | ≤75 |
| Working condition | ºC | 0-43 | 0-43 | 0-43 |
| Max.exhause pressure | MPa | 3.0 | 3.0 | 3.0 |
| Noise | dB(A) | 75 | 75 | 75 |
| Power consumption/H | KWH | 4.8 | 8.5 | 15.0 |
| Electric heater | KW | 3.0 | 6.0 | 12.0 |
| Blowing type | / | HORIZONTAL BLOWING 360° | ||
| Dimension of dryer | MM | 1675×860×1280 | 1760×1060×1280 | 2120×1360×1590 |
| Weight | KG | 180 | 285 | 480 |
Recommend Drying Machine+Drying Chamber
| Dryer material | Galvanized steel (Stainless steel for option) | ||
| Drying chamber material | Polyurethane Two sides: steel | ||
| Heating source | 75% air source + 25% electric | ||
| Brand name | KINKAI | ||
| Model number | JK03RD JK06RD JK12RD | ||
| Recommend dryer + drying chamber size | Description | Product Capacity | Drying Chamber size |
| One unit JK03RD dryer + drying chamber | 300Kg / batch | 4000*2000*2200mm | |
| One unit JK06RD dryer + drying chamber | 600Kg / batch | 6000*2800*2200mm | |
| One unit JK12RD dryer + drying chamber | 1500Kg / batch | 6000*3000*2200mm | |
| Two units JK03RD dryers + drying chamber | 1200Kg / batch | 7000*2200*2200mm | |
| Two units JK06RD dryers + drying chamber | 1500Kg / batch | 10000*2800*2200mm | |
| Two units JK12RD dryers + drying chamber | 3500Kg / batch | 10000*3000*2200mm | |
Features of KINKAI Drying Machine
1. Energy saving&Environmental protection.
Adopt close dehumidify+circulating drying type,saving operating cost;Without waste gas and waste heat pollution,low noise.
2. Running Stable,operating easily.
PLC+Touch Screen,running stable,operating easily;Adopt PLC control,can setting different drying curve, Suitable for drying different materials.
3. Second waste heat recovery technology(patent).
Adopt air to air heat exchanger dehumidify and recovery waste heat at the same time, saving energy more than 40%.
4. Exact control temperature and humidity.
According to different material setting different drying curve, the heat pump dryer can control the drying chamber temperature between 20-80ºC.
5. Recovery volatilized component.
Some kinds of material contain volatilized component,In drying processing,hot and wet air will become condenser water then drain,collect the condenser water so that collect volatilized component.
Packaging & Shipping
A. Technical service
1, We calculate the capacity and recommend the best models.
2, We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.
3, We supply the spare parts and technical support in & after the warranty time.
4, We supply the training course to your workers at our factory if you need.
B. After-sales service
1, Technical support for your installation, operation and maintenance.
2, One year's warranty, and you can pay for extended warranty.
3, Spare parts and technical support at most economic prices after the warranty.
