Desktop Laser Engraver, Desktop Laser Carving Machine (YH-4030)

Product Specifications

Prod Model:	YH-4030-40w
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Engraving Machine Type:	Laser Engraving Machine
Control:	CNC
Current:	AC
Laser Type:	CO2
Usage:	Plastic

Product Description

All of types have been passed CE certification.

Features:
1) New software:
A) Realizes seamless connection with BMP, PLT and various graphic processing software such as Photoshop, AutoCAD and CorelDraw
B) Has direct original graph output function and meets site design requirements of users
C) Can define carving sequence freely and realize all or partial output for
One time easily
2) Carving materials: Normal non-metal materials such as organic glass, Wood, leather, cloth, plastic, rubber plate for printing, double-color plate, Glass, synthetic crystal, jean, cardboard, dense plate and marble
3) Carving performances:
A) High speed cutting and smooth operation
B) Isn't limited by work efficiency of traditional laser processing
C) Uses perfect mechanic combination so as to ensure overall stability of Equipment and make curve cutting without any SAW tooth, shake or Noise
4) Functions:
A) Supports array output and fixed point output
B) Quicker speed and can greatly improve working efficiency
C) Newly adds 3600 carving slope function and has more powerful Functions
D) Large power smoke emission system
E) Large power water cooling system
F) Special control software
G) Air pump and automatic water cooler (optional)
H) No-water alarm
I) Cooling water display
J) Automatic alarm and cutting off the operation of laser during circular Water failure to protect laser
K) Automatic smoke emission
L) Smoke emission system starts automatically when carving machine Operates
M) Smoke emission system closes automatically when carving machine Finishes
N) Elevation platform
O) Electric controlled automatic elevation platform has easy and flexible Operation
P) Strong and stable mechanical structure designs digital controlled motion to be permanent stable and not need adjustment.

Specifications:
1) Laser power: 60W
2) Engraving speed: 0 - 54, 000mm/min
4) Cutting speed: Acrylic 0-20mm; Other depths depend on other materials
5) Operating humidity: 8 - 95%
6) Cooling mode: Water-cooling and protection system
7) Cutting accuracy: 0.1mm
8) Maximum forming character:
A) Chinese: 2.5 x 2.5mm
B) English: 1.5 x 1.5mm
9) Locating accuracy: < 0.01mm
10) Power supply: AC 200V+-10%
11) Operating temperature: 0 - 45 degree
12) Circular water temperature: 5 - 30 degree
13) Driving way: Constant flow and subdivision
14) Slope angle: 360
15) Graphic format supported: BMP, HPGL, JPEG, PLT, DST, DXP, DXF, DWG, CDR, and AI
16) Driving system: Stepper
17) maximum height of workpiece to be put on working area can be 3cm.


Strong Service Support:
10 year's exporting experience help you with professional documentaries, shipping matters, importing guidance and timely follow-up notice. Make you whole process worry-free!

12 months warranty! Online skill training till you can operate! Professional technician provide with lifelong support to make you feel worry-free to use, buy and profit!
