| Price: | US $ 100-200/Ton |
|---|---|
| Min Order: | 1/Ton |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | PPS sheet |
|---|---|
| Color: | Natural,Black,Khaki and So on. |
| Thickness: | 1mm-100mm |
| Certificate: | ISO9001 SGS RoHS FDA |
| Advantage: | Guarantees in Three Months |
| Size: | Customized Size |
| Item: | for PPS Rod |
| Shape: | Customized |
| Material: | PPS |
PPS(Polyphenylene sulfide)
1.Description:
PPS(Polyphenylene sulfide) is a semi-crystalline high performance thermoplastic with optimised tribological properties for demanding bearing and friction requirements. The molecular structure of PPS is comparatively simple, and the main molecular chain is alternately arrayed by benzene rings and sulfuratoms, lots of rings and sulfur and sulfuratoms supplies PPS with the rigidity resistance as well as the pliancy resistance. The inner symmetrical molecular structure makes PPS easily crystal, non-polarity, good electrical resistance and low water absorption and so on. Guangzhou ONE-STOP Engineering Plastics Factory has studied and applied this material in many industries for many years.
2. Characteristics:
3. Applications:
The preferred using fields of PPS Parts that made by Guangzhou ONE-STOP Engineering Plastics Factory
are: Mechanical and automotive engineering, nuclear and vacuum technology, transport and conveyor technology, pump technology, textile, packaging and paper processing machinery, precision and chemical engineering, plant construction, aircraft and aerospace industry.
Popular applications for the use of this product are:
Color:Natural,Black,Khaki and so on.
PPS Sheet Size:500X1000X(Thickness:1-100mm),600X1200X(Thickness:1-100mm)
PPS Rod Size:Φ6-Φ200X1000mm
PPS Tube Size:(OD)30-800X (ID)20-600X length(500-1000mm)
The Data Sheet of PPS:| Property | Item No. | Unit | Value | |
| Mechanical Properties | 1 | Density | g/cm3 | 1.43 |
| 2 | Water absorption (23ºC in air) | % | 0.03 | |
| 3 | Tensile strength | MPa | 75 | |
| 4 | Tensile strain at break | % | 5 | |
| 5 | Compressive stress (at 2% nominal strain) | MPa | 55 | |
| 6 | Charpy impact strength (unnotched) | KJ/m2 | 25 | |
| 7 | Charpy impact strength (notched) | KJ/m2 | 3.5 | |
| 8 | Tensile modulus of elasticity | MPa | 3700 | |
| 9 | Ball indentation hardness | N/mm2 | 180 | |
| 10 | Rockwell hardness | -- | M84 | |
