Product Specifications
| Prod Model: |
HST Acrylic sheet |
| Markets: |
North America,South America,Eastern Europe,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
1220 X 1830mm, 1220 X 2440mm, 2050 X 30 |
| Thickness: |
1~50mm |
| Product Color: |
Red, Clear, Yellow, Black, Opal etc |
| Main Material: |
Pure Raw Lucite |
| Production Line: |
From Taiwan Acrylic |
| Models: |
From UK |
| Application: |
Advertising and Decoration |
| Place Of Origin: |
Zhejiang China (Mainland) |
| Light Transmission: |
High Light Transmission(92%) |
| Density: |
1.2g/cm3 |
| Material: |
PMMA From Lucite |
| Color: |
All Color |
Product Description
What is Acrylic?
Acrylic sheet is named PMMA sheet, Plexiglass or Organic glass sheet. The Chemical name is Polymethyl methacrylate. Acrylic holds the physical properties among plastics due to the excellent transparency which sparkling &transparent like crystal, it is praised as "Queen of Plastics" and is very delighted by the processors.
The term "acrylic" is used for products that contain a substance derived from acrylic acid or a related compound. Most often, it is used to describe a clear, glass-like plastic known as poly(methyl) methacrylate (PMMA). PMMA, also called acrylic glass, has properties that make it a better choice for many products that might otherwise be made of glass.
Product Features:1. Clear, Transparency rate can go to over 95%.2. Various color available, long-time lasting.3. Highly glossy, easy clean4. Easy to mould. No-toxic acrylic sheet5. Bright, insulated, chemical en durability, anti-bump, easily processed, a virulence, anti-wallop, recycled.6. Good at anti-UV. Color fades less than 30 & in 3 years outdoor may show color difference for different batch.7. Density of acrylic sheet: 1, 200kg/cbm8. Can be used for vacuuming, engraving, silk-screen printing, polishing, processing, etc.Specification of Acrylic SheetSpecification: 1000X2000mm,1220 X 1830mm, 1220 X 2440mm, and 2050 X 3050mm1000 X 2000mm 1270 X 2490mm, 1270 X 1880mm, 1250 X 2470mmCan be made as your customizedThickness: From 1mm to 50mmColors: Clear, opal, red, blue, yellow, green, brown. More customized color is welcome!Production Packing & Inspecting.: Raw material: 100% virgin material of LUCITE or Mitsubishi for acrylic sheet.
The acrylic sheet was made from the MMA monomer, which was manufactured by worldwide famous factories, after thermal treatment in high temperature drying room for 5-6 hours. It is an excellent product which complies with SGS.
The penetration rate of visible light is 92%. It is well processed and has stable quality.
Our acrylic sheet conforms to the environmental protection standard, already though SGS authentication and CE. With quality inspecting before packing, If these are more than 3 spots, it will be canceled.
Packing of Cast Acrylic Sheet
Both sides covered with kraft or PET film, several sheets per pallet
Bulk cargo packing
2 tons per tray, use wooden pallets on bottom, with packaging film packages all around ensure transportation security.
Full container load packing: 18-20 tons of a 20 foot container with 10 tray.
Product Application:
1.Advertisement: Light Box,Signboard,Signs,Display Rack;
2.Lighting: Daylight Lamp,Ceiling Lamp,Lampshade;
3.Civilian Goods: Bath Room, Art Work, Cosmetics, Bracket,Aquarium;
4.Construction:Show Window,Noise Barriers,Daylighting Shade, Telephone Booth;
5.Vehicle: Door and Window of Car and Train;
6.Medical: Infant Incubator, Many Kinds of Medical Apparatus;
7.Industrial: Instrument Surface Panels & Protecting Covers.| Mold Size | Art. No. | Product Size with glue tape | Product Size without glue tape |
| 1270*2470 | T | 1220*2420 | 1220*2440and 1220*1830(Standard size)
Cut-to-size services also are available which is according to the demand of customers. |
| 1300*1900 | Q | 1250*1850 |
| 1070*2070 | Q1 | 1020*2020 |
| 1300*2500 | L | 1250*2450 |
| 1330*2550 | L1 | 1280*2500 |
| 1330*2550 | LM | 1280*2500 |
| 1330*2550 | LM2 | 1280*2500 |
| 1370*2610 | L2 | 1320*2560 |
| 1370*1770 | S | 1320*1720 |
| 1710*2710 | R | 1660*2660 |
| 2050*3050 | W | 2000*3000 |
| 1600*3100 | Y | 1550*3050 |
| 2100*3100 | M | 2050*3050 |
| 2110*3110 | M1 | 2060*3060 |
|
| 1. Excellent transparency. |
| 2. Good mechanical performance. |
| 3. Good electrical insulation. |
| 4. Stable and durable. |
| 5. Non-toxic. |
| 6. Superior impact resistance. |
| 7. Crack resistance. |
| 8. Superior weather resistance. |
| 9. UV light resistance. |
| 10. Chemical resistance. |
| 11. Stable color under outdoor exposure. |
|
| 1. Indoor decoration board, partition board in office and house. |
| 2. Product design. |
| 3. Engraving and signboard. |
| 4. Making gift items. |
| 5. Making kitchen and sanitary application. |
| 6. Door and window cover. |
|
| Thickness (mm) 2 ~ 50 |
| Dimensions (mm) 1020x2020 1220 x 1830, 1220 x 2440, 2050 x 3050,1250x1850 |
| Color clear, milky, opal, black, red, blue, yellow, green |
Our Acrylic Average Physical Properties:
Specific gravity | 1.19-1.20 |
Hardness | M-100 |
Absorptivity of water (24h) | 0.30% |
Tension | |
Coefficient of Rupture | 700kg/cm2 |
Coefficient of Elasticity | 28000kg/cm2 |
Bending | |
Coefficient of Rupture | 1.5kg/cm2 |
Coefficient of Elasticity | 28000kg/cm2 |
Transmittance (parallel rays) | 92% |
Full rays | 93% |
Heat Distortion Temperature | 100oc |
Coefficient of Linear Expansion | |
Ultimate Temperature of Continuous operation | 80oc |
Thermoforming Ranges | 140-180oc |
Insulation Strength | 20V/mm |
The specification of products
Part size, thickness and weight |
Thickness Size(m) | 2mm | 3mm | 4mm | 5mm | 8mm | 10mm | 20mm | 30mm |
1.25*2.45 122 244 | 7.35kg 7.14 | 11.0kg 10.7 | 14.7kg | 18.0kg 17.8 | 28.2kg | 35.0kg | 73.0kg | 110kg |
1.25*1.85 | 5.6kg | 8.6kg | 11.4kg | 13.8kg | 21.6kg | 26.7kg | 55.6kg | 86kg |
1.50*2.10 | 7.6kg | 11.2kg | 14.7kg | 18.2kg | 29.2kg | 36.0kg | 70.5kg | 112kg |
1.60*2.20 | 8.5kg | 12.8kg | 17.0kg | 21.0kg | 32.2kg | 40.2kg | 84.5kg | 128kg |
1.60*2.60 | 10.0kg | 15.0kg | 20.0kg | 35.0kg | 40.0kg | 50.0kg | 100.0kg | 150.0kg |
2.05*2.30 | 11.4kg | 17kg | 22.9kg | 28.5kg | 45.6kg | 57kg | 107.5kg | 170kg |
2.05*3.05 | 15kg | 22.8kg | 29.8kg | 37.0kg | 56.5kg | 68.5kg | 150kg | 228kg |
Why you choose us:
1. We are professional manufacturer with many years of experiences.
2. We have advanced facilities for production, most of the products are
welded by automatic machine.
3. We have SGS and ASTM certificates which can assure the quality of our products.
4. We have many years of export experiences, our friendly and professional sales
team can off er favorable services.
5. We have strong engineering team that can give best solution for your projects .
Established in 1998, Haiyan Huashuaite Plastics Electric Appliance Co., Ltd. is a leading Chinese producer of polycarbonate, PC sheet, PVC foam sheet and PVC profiles. All of our products are manufactured in line with ISO9001, ROTHS and SGS requirements and feature numerous advantages over traditional building materials including age resistance, impact resistance and durability.
Our company employs 250 staff members, including 58 technicians, and has always focused on the application of technology to improve product quality and development. Furthermore, we have 7 imported polycarbonate sheet production lines, 30 PVC profile extrusion lines from Germany and Italy. And 1 cast acrylic sheet line from England.
with quality viewed as the life of our enterprise, we utilize our team of quality inspectors and advanced apparatus to maintain the quality of our products throughout our entire production process. Moreover, our products are currently being used in major projects including Daqing Oil Fields and 2008 Beijing Olympic Games fields and gyms.
Haiyan Huashuaite Plastics Electric Appliances Co., Ltd. Continuously strives to enhance our good reputation whilst perfecting our products, management techniques, processes and level of customer service. If you are interested in any of our products, or are searching for a supplier to fill your OEM order, please contact us to discuss your requirements.
