Product Specifications
| Prod Model: |
JGTF-002 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Thickness: |
2mm-19mm |
| Size: |
1524X2134mm, 1830X2440mm, 2140X3300mm, 2140X3660mm |
| Product Name: |
Clear/Coated/Reflective Tempered Furniture Window |
| Type: |
Single-Surface Glass |
| Structure: |
Solid |
| Moh's Hardness: |
7 |
| Shape: |
Plate |
| Function: |
Mechanics and Mechanical Function |
| Transparency: |
Transparent |
| Processing Method: |
Phase & Crystallization |
| Preparation Process: |
Fusion Method |
| Usage: |
Window |
| Application: |
Furniture |
Product Description
Experience:
More than 20 years production and technology experience and 10 year's exporting experience.
Certificate:
CE, ISO9001, AS/NZS2208: 1996, SGS. EN12150. GB11614-2009
Clear float glass
Thickness: 2mm-19mm
Sizes: 1524x2134mm, 1830x2440mm, 2140x3300mm, 2140x3660mm, 2250x3300mm, 3660x2140mm, 3660x2250mm etc.
Extra/Low Iron clear glass
Thickness: 3mm-19mm
Sizes: 1830x2440mm, 2140x3300mm, 2140x3660, 2250x3300mm, 2250x3660mm etc.
Tinted/Colored float glass
Colors: Euro Bronze, Golden Bronze, Euro Grey, Mist Grey, Dark Grey, French Green, Dark Green, Lake Blue, Dark Blue, Ocean Blue, Pink etc.
Thickness: 3mm-12mm
Sizes: 1524x2134mm, 2140x3300mm, 2250x3210, 2250x3300mm, 2140x3660mm, 2250x3160mm etc.
Reflective Glass
Colors: Euro Bronze, Golden Bronze, Euro Grey, Dark Grey, French Green, Dark Green, Lake Blue, Dark Blue, Pink, Silver etc.
Thickness: 3mm-10mm
Sizes: 1524x2134mm, 2140x3300mm, 2250x3210, 2250x3300mm etc.
Laminated glass
PVB Color: Clear, Green, Blue, Bronze, Grey, Milk white etc.
Glass Color: Clear, French Green, Dark Green, Ford Blue, Dark Blue, Bronze, Euro Grey etc. Float glass and reflective glass are available.
Thickness: 3+0.38+3mm, 4+0.38+4mm, 5+0.38+5mm, 6+0.38+6mm, 3+0.76+3mm, 4+0.76+4mm, 5+0.76+5mm, 6+0.76+6mm etc. Till to 42.3mm
Sizes: 1830x2440mm, 2140x3300mm etc.
Tempered/Toughened glass Thickness: 3-19mm.
Size: Max. 2440*3600mm, Min. 200*300mm
Color: Clear, blue, green etc
Mirror
Types: Silver Mirror, Aluminum Mirror, Copper and Lead Free Mirror, Safety Mirror, Solar Mirror and Beveled Mirror etc.
Thickness: 1.5mm, 1.8mm, 2mm, 2.7mm, 3mm, 4mm, 5mm and 6mm etc.
Sizes: 1524x2134mm, 1830x1220mm, 1830x2440mm, 2140x3300mm, 2250x3300 etc.
Patterned/Figured glass
Thickness: 3mm, 3.5mm, 4mm, 5mm, 6mm, 8mm etc.
Sizes: 1220x1830mm, 1524x2134mm, 1830x2440mm, 3300x2140mm etc.
Colors: Clear, Bronze, Blue, Amber, Grey, Green, Blue etc.
Patterns: Aqualite, Bamboo, Beehive, Chinchilla, Crystal, Diamond, Flora, Karatachi, Masterlite, Millennium, Mistlite, Morgon II, Moru, Nashiji, Rain and Wanji etc.
| AEON GLASS Online Coated Reflective Glass Performance Data |
| Description | Thickness | Visible Light Transmittance | Visible Light Reflectance | UV Light Transmittance | Direct Sunlight Transmittance | Direct Sunlight Reflectance | Total Solar Transmittance | Shdowing Coffecient (SC) | RHG | K Value (Summer Daytime) | K Value (Winter Night) |
| Euro Bronze | 6 mm | 20.45% | 16.32% | 2.03% | 29.70% | 14.85% | 43.08% | 0.48 | 0.463 | 5.243 | 5.808 |
| Euro Grey | 6 mm | 21.26% | 15.36% | 3.05% | 28.01% | 13.37% | 42.15% | 0.47 | 0.457 | 5.243 | 5.808 |
| Dark Grey | 6 mm | 20.82% | 14.09% | 3.50% | 27.39% | 12.71% | 41.83% | 0.47 | 0.455 | 5.243 | 5.808 |
| Light Blue | 6 mm | 25.33% | 31.63% | 3.54% | 26.14% | 21.17% | 38.85% | 0.44 | 0.419 | 5.243 | 5.808 |
| Dark Blue | 6 mm | 18.79% | 11.79% | 10.23% | 38.68% | 17.19% | 49.32% | 0.55 | 0.517 | 5.243 | 5.808 |
| French Green | 6 mm | 26.43% | 34.12% | 2.76% | 20.76% | 18.66% | 35.37% | 0.40 | 0.390 | 5.243 | 5.808 |
| Dark Green | 6 mm | 25.40% | 24.35% | 4.06% | 26.15% | 15.15% | 40.30% | 0.45 | 0.438 | 5.243 | 5.808 |
| Silver White | 6 mm | 42.75% | 38.11% | 9.47% | 52.31% | 28.29% | 56.99% | 0.64 | 0.578 | 5.243 | 5.808 |
| | | | | | | | | | | | |
| Made by AEON Industries Corporation Ltd, Qingdao, CHINA, internal information, for reference only. | | | | | |
Rizhao Jinbo Industry Co., Ltd is established in 2006. We own the advanced flow-line equipment, professional engineer, earnest attitude, best service for the clients, so eight years passed, we grow up to become the leader of glass manufacturing industry in China. Our factory covers an area of over 40, 000 square meters, and we own more than 54 sets equipment, including in 4 processing lines for glass cut, 2 processing lines for tempered glass, 5 processing lines for insulated glass, 3 processing lines for laminated glass; And high-pressure autoclave, thermal, drilling machine, something extra.
We believe that the sole competitiveness comes from the high quality. We have been dedicated in the research and development of advanced manufacture techniques and therefore our quality could been improved to a higher level.
Our experienced and professional sales team will surely offer the essential support and pre- and after- sales service necessary to ensure that all customer requirements are met promptly and efficiently.
Our Leading products are including in Low-E glass, coated glass, tempered glass, insulating glass, laminated glass, curved steel glass, fire glass over various combinations of glass and composite products.
Over the past year, our total capacity breakthrough 4 million square meters. All of our customers are located all over the world and are very satisfied due to our excellent price-quality ratio.
FROM China, FOR WORLD. WE'LL JUST BE THE CARRIER OF THE GLASS!
