Abdominal Diagnostic Machine Ultrasound Scanner PC Based Ysd4200.
| Price: |
US $ 900-1600/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
Product Specifications
| Prod Model: |
YSD4200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Digital PC Platform: |
Yes |
| Outlook Design: |
Laptop |
| Screen: |
12.1 Inch |
| 3D Reconstruction Function: |
Support |
| Scanning Mode: |
Convex / Linear / Micro-Convex |
| Export Range: |
The Whole World |
| USB: |
Yes |
| Production Capacity.: |
100 Unit in Stock |
| Display Mode: |
B, B+B, 4b, B+M, M |
| OEM: |
Acceptable |
| Classification: |
Imaging Diagnostic Equipment |
| Type: |
Ultrasound Scanner |
| Certification: |
ISO13485 |
| Group: |
Middle-aged and Old |
Product Description
Main Feature:1.Dual interface
2.Can directly matche video,laser,ink jet printers to print report,no need any software,and image is real.
3.Can directly connect various kinds of probes with different elements,different specifications and different applications.
4.Equipped with lithium battery,which can be used more than four hours when the power is off.
5.Advanced and reliable pure digital PC platform,backlit silica gel keyboard.
6.Net weight:2.9kg,packaged by metal suitcase,light and easy to carry.
7.High definition 10.4/12.1 inch medical liquid crystal display.8.with 3D reconstruction function
Teachnical data: | Scanning mode | convex / linear / micro-convex |
| Probe | convex, linear, transvaginal, rectal |
| Monitor | 12.1 inch high resolution LCD |
| Operation panel | user-friendly, convenient and flexible with back-lit silica gel keyboard
& track ball operation |
| Display mode | B, B+B, 4B, B+M, M |
| Scanning depth | more than 240mm |
| Resolution | lateral≤2mm, axial≤1mm |
| Blind zone | ≤3mm |
| Geometry precision | lateral≤5%, axial≤5% |
| Gray scale | 256 |
| Electronical focusing | 2 focuses combination randomly |
| Cine loop | 256 frames, realized in automatic successive playback and manual
single step forward, backward playback |
| Permanent image storage | 8 |
| Magnification | ×0.8, ×0.8, ×0.90, ×0.95, ×1.0, ×1.05, ×1.10, ×1.20, ×1.30, ×1.40,
×1.50, ×1.60, ×1.80, ×2.0, ×2.2, ×2.5.(16 kinds) |
| Body mark | 140 |
| Probe interface | 2 |
| Pseudo color | 8 |
| Image processing | up/ down, left / right, black / white convertion, edge enhancement,
gamma correction, frame correlation, pseudo color processor
( need external color display) |
| Measurement | distance, perimeter, area, volume, heart rate, gestational week,
FW, AFI, EDD , maternity table, heart package etc |
| Note | date, time, name, sex, age, doctor, hospital, comment, Chinese/ English conversion |
| Output interface | PAL-D, SVGA (SVGA color monitor), USB port |
| Main power supply | AC220V±22V , 50/60Hz |
Standrd Configuration | Standard configuration | YSD4200 main unit, |
| 3.5MHz convex probe, |
| Power Adapter |
| Lithium Battery |
| Aluminum Box |
| Certifications |
| user manual |
| Packing list |
| warranty list |
| Optional | 3D function software |
| Electronic linear array probe |
| Electronic rectum probe |
| Electronic micro-convex probe |
| Electronic high frequency linear probe |
| Electronic convex cardic probe |
| Video printer, laser printer, inkjet printer |
| Foot switch |
| Delivery Time | within 3-5 working days after payment |
| Warranty | 24months |
| Packing size | 490mm×385mm×250mm |
| Gross Weight | 9KG |
Why choose us:we got production and business certification from Chengdu food and Drug Administration
we got business license from Chengdu City Administration of industry and commerce
we got products certificate of registration and have checked in the website of SFDA
we have accepted the onsite check from SFDA every quarter
we finished the training of laws and regulations in medical equipments field
We have well-established system about material purchasing, employee training,store management,after-sales service process.etc
We adheres the beliefs of "Support Healthy Life", and our company spirits are quality, service,trust,thanksgiving;
our certificates:
Chengdu Yushengda Technology Co., Ltd. Is a hi-tech limited company engaged in developing, producing and selling medical ultrasonic diagnosis apparatus. The company has high-qualified professional stuffs in researching, producing, marketing and management. There's a brand-new manufacturing plant and advanced suit of equipment for producing and inspecting the products. It Can produce 5, 000 sets of ultrasound scamner and more than 10000 hospital bed per year.
The YSD series of B-mode ultrasonic diagnosis devices adopt super-scale integrated electro circuit and new SMT technic. The quality of products is stable and credible. It has passed the medical ultrasonic quality monitor and inspection center. The technical and safe standards are all conformed to the GB10152-1997. Since 2003, it was awarded "high-quality, keeping regulation, good faith" honored enterprise of Sichuan.
The spirit of the company is"unity, sincerity, factualness, innovation". We all try our best for"true feelings to customer, diligent permanently for innovation, improving continuously for quality, creating brand by sureness", which makes more satisfaction to customers. The company has been carried out the quality managing system of YY/T0287-2003, won the certificate of medical device quality managing system. The products are sold to domestic markets and overseas markets, such as Europe, Africa. The products are becoming more and more popular.
We'll stick to our policy and work harder all the time in order that we can provide more and better products, and making contributions to the development of national medical devices and people's health!
