Product Specifications
| Prod Model: |
6090 |
| Structure Type: |
Desktop |
| Laser Technology: |
Laser Control Fault Cutting |
| Laser Type: |
CO2 |
Product Description
Product Description
AC-1325 Hot Sale China Factory Supply Laser Cutting Machine With CE SGS
Performance Features
1) Lathe bed structure ensures the stable operation while carving and cutting at high speed
2) Beam is drawn out of high hardness alloy aluminum material and driven by a large power subdivision server-motor
3) Laser unit served by special radiator and protected without water makes it stable and safe with a longer life span
4) It matches accessories such as rotation platforms, double laser units
5) Operation handle can be chosen
6) It can also be made according to customer's demandsParameter| Model | YG-6090 CO2 laser cutting machine |
| Working area | 600x900mm |
| Laser power | 80W/100W/130W |
| Laser type | CO2 sealed laser tube,water-cooled |
| Cutting speed : | 10000mm/min |
| Power supply | 220V±10% /50HZ , 110V±10%//60HZ |
| Min. shaping character | Letter 1.0 x 1.0mm |
| Graphic format supported | BMP, PLT, DST, DXF, AI,CDR |
| Software supported : | CorelDraw, PhotoShop, AutoCAD |
| Laser Output Control | 1-100% software setting |
| Highest Scanning Precision | 2500DPI |
| Resolution ratio | <0.01mm |
| Location precision: | <0.01mm |
| Working temperature: | 5°C-40°C |
| Operating humidity | 5%-95%(without condensed water) |
| Optional parts | Up-down worktable, Red light pointer, Auto focus, Rotary device |
| Type | AC-4060 | AC-6090 | AC-1290 | AC-1490 | AC-1610 | AC-1613 | AC-1325 |
| Laser power: | 40w | 60w | 80w/100w/120w /150w | |
| Engraving Area (mm) | 400*600 | 600*900 | 1200*900 | 1400*900 | 1600*1000 | 1600*1300 | 1300*2500 |
| Gross power | 1200w | 1200w | 1600w/1800w/2000w |
| Laser type: | CO2 Laser tube |
| Cutting depth: | acryl 0-20mm |
| Engraving speed : | 0-1000mm/s |
| Cutting speed: | 0-600mm/s |
Resetting positioning
accuracy: | <0.01mm |
Maximum forming
character: | English:1.5 x 1.5mm |
| Power supply: | 220V±10% 50HZ or 110V±10% 60HZ |
| Software supported: | ArtCut, CorelDraw, PhotoShop, AutoCAD |
Graphic format
supported: | PLT, DXF, BMP, JPG, GIF, PGN, TIF |
Engraver for Curve
surfaces: | we can provide rotary system so as to engrave on curse surfaces |
| Water Cooling: | Yes |
Maximum Height of
Materials to Engrave: | 280mm(by motor) |
| Assistant Equipment: | Water pump | Exhaust Fan | Aluminum alloy
worktable | Air compressor |
| Optional Spare Parts: | RF Laser Tube | Rotary System | Cooling water system | Red dot pointer |
Recommended Spare
Parts/Consumables | Laser Tube and Lens |
Material Cut Engrave
Acrylic, Plexiglass, Pmma, Perspex, Organic board, Double color plate Yes Yes
Plastic, PP, PET, PC, PMMA, PS, PES, PA, Plastic Foils&Films, Polycarbonate, polyester or polyimide membrane keyboards YesYes
Wood, Bamboo, Veneer, MDF, Blasa wood, Plywood YesYes
Leather, Pig leather, Cow Leather, Sheep leather YesYes
Textile, cotton, silk, felt, lace, synthetic & technical textiles, aramid, polyester, fleece YesYes
Foam & Filter, Mats Polyester (PES), Polyethylene (PE), Polyurethane (PUR)
Neopren® YesYes
Paper, Cardboard, Chipboard, Press Board YesYes
Stone, Ceramic, Granite, Marble, Natural stone, Pebble stone, Slate NoYes
Rubber stamps, Synthetic & Silicone Rubber, Natural rubber, Microporous foam
Silicone rubber, Synthetic rubber YesYes
Glass, Pressed glass, Float glass, Crystal glass, Mirror glass NoYes
Guarantee&Aftersales Service
(1)Guarantee for two yearS
(2)24-hour technical support by email or phone
(3)English manual and video CD for machine using and maintaining
(4)Jinan saicheng machinery Co., Ltd provides free operation training service in Hongye factory.
Miss Iris
JINAN SAICHENG MACHINERY CO., LTD
(jinan acrossin imp&exp trading co., ltd)
+86 18615216576 +86 531 67811996
http://acrossin.en.made-in-china.com/
www.scygjx.com
Our company manufacture CNC machinery.
High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
We are belong to JINAN ACROSSIN IMP&EXP TRADING Co., Ltd,
We are a subsidiary corporation of it.
JINAN SAICHENG MACHINERY Co., Ltd is established in 2007, and be good at CNC router field in Chinese market, and get good feedback, Perfect quality and best Aftersale. Our products include woodworking CNC router, stone CNC router, laser machine, plasma machine, we can Produce many kinds of CNC router following client requirement.
JINAN ACROSSIN IMP&EXP TRADING Co., Ltd is a group company, it is established in 2006, scope of business include Machinery parts, building hoist, tower crane, and ball screw, and CNC machinery.
The continuously improving performance of our machines wins great trust of our customers. Our products are not only sold in Chinese maekrt, but also exported to Europe, north and south America, central and west Asia and other regions.
Of cause, we can produce every kind of CNC router, and We accept orders according to our customers' requirements.
